Simplebus Color
86Pages

Simplebus Color technology allows up to 240users to be connected with just 2 wires, including the power supply. Simplebus Color makes it possible to realize any type of system, from two-family homes to the largest residential complexes, with maximum simplicity and efficiency. > Simplebus Color happily connects external units which are up to 350 metres from the monitor. Simply by adding a line amplifier, it is possible to make systems which carry audio-video signals from the external unit to monitors as far as 600 metres away! >

Infinite plant solutions > By using the Simplebus Color technology,systems with an unlimited number of main and secondary entrances can be realised, together with a porter switchboard where necessary. Furthermore, several simultaneous secondary entrance communication is possible without engaging the main entrance units. Fully intercommunicating system > Simplebus Color allows up to 8 branches of both door entryphone and video entry phones to be made intercommunicating, preventing the conversation between them interfering with the main and secondary external units.

Maximum distances and characteristics of the conductors Connection of the equipment is of the non-polarised type. Use of conductorswith characteristics other than those prescribed, does not guarantee reaching certain installation distances or good quality of the video signal,so only cables described in the following tables should be used. MAX distancebetween Mixerand internal unitMAX distancebetweenArt. 4833Cand MixerArt. 4888CMAX Distancebetween externalunitand Art. 4833CType of cable >

The principle of rationality and versatilitycharacterising the Simplebus Color system is also confirmed in its technical-structural aspects: the power supply unit is contained in 12 DIN modules and can therefore easily be inserted in a standard 12-module switchboard. Only one person and a fewseconds are all that is needed to programme the door entry phone, the monitor and the entrance panel, simply by setting the position of the dip- switch for each code. > With Simplebus Colortechnology, simply add the camera module to the external unit and replace the telephone with the monitor. >...

INTERNAL UNITS POWER SUPPLIESACCESSORIES >

Standard made of extruded aluminium provided with aluminium rain roof and basefor fixing to the floor by means of the expansion bolts provided. > Housing made of aluminium which allows the Powercom entrance panel to beinclined by 45а. Once in the wall, the housing, angles the entrance panel laterally towards the user for easier and more practical use. No. ModulesArticleDimensions 13649/1183x130x100 mm23649/2183x242x100 mm33649/3183x354x100 mm > Module preset for audio speaker unit, with stainless steel front and blue LED fornameplate label illumination. To be completed with the relative...

3324 Plain module > Dimensions 112x89.5x22 mm 3325 PTT module > Dimensions: 112x89.5x22 mm 3326 Module illuminated from the rear > Module illuminated from the rear with LED for various signals.Dimensions: 112x89.5x38 mm 3328 Powercode coded access module > Powercode electronic digital key module with keypad illuminated with blue LEDs. Byentering a number with 1 to 8 figures on the keypad, two relays (10 A) are activated, which allow electric locks or other devices to be operated. 12 V AC/DC power supply. Dimensions: 112x89.5x40 mm. 3335 Powerlock proximity reader module > Proximity reader...

3344 Name directory/information module > Module illuminated from the rear with blue LED, complete with label for writing thenames and codes of the users (12 max). Dimensions: 112x89.5x38 mm. 3346 System engaged signalling module > Complete with flashing blue LED for visual indication of the engaged state. Thetransparent label is supplied blank to insert the wording in all languages. Dimensions: 112x89.5x38 mm. 1602 Audio speaker unit for Simplebus system. > Audio speaker unit for Simplebus system with terminal board and double amplifier,watertight loudspeaker and electret microphone, the...

1026 Electronic card key for Art. 3335 > Electronic proximity key in credit card format. 5 cm reading distance. To be used with Art. 3335 1027 Electronic key fob for Art. 3335 > Electronic proximity key. Key ring type format and dimensions. 5 cm readingdistance. To be used with Art. 3335 1028 Programmer for Art. 3335 > Optional programmer for enabling / disabling the electronic keys for Art. 3335.Supplied by batteries not provided. Only required if you want to disable fobs ӓ, or to change the time of the door opener. Can only be used with Art. 3335. 1249/A Software > Software on CD ROM to...

Made of 1.5 mm thick galvanized sheet, complete with specialspacers for joining and templating several boxes. No. ModulesArticleDimensions 13160/1130x130x58 mm23160/2130x242x58 mm33160/3130x354x58 mm > Made of die-cast aluminium and painted using special powderpaints resistant to external environments. Dark grey colour. No. ModulesArticleDimensions 13161/1143x143x18 mm23161/2143x255x18 mm33161/3143x367x18 mm > Made of die-cast aluminium and painted using special powderpaints resistant to external environments. Steel grey colour. No. ModulesArticleDimensions 13161/1A143x143x18...

3064/A 4-pushbutton module > Module made of double 2.5 mm stainless steel plate, completewith 4 traditional pushbuttons for the Simplebus digital system. Has an EEPROM memory on board to memorize the call code. Dimensions: 106x106x56 mm 3070/A Stainless Steel electronic call module forSimplebus system > Made of double 2.5 mm stainless steel plate, complete with 12stainless steel pushbutton keypad illuminated from the rear, 16- character alphanumerical display for showing the call codes and interactive messages with the user (engaged, etc.). Also carries out the electronic coded key function...

3183 Vandalcom series module for signalling system engaged forComelbus and Simplebus digital systems > Made of double 2.5 mm stainless steel plate, it is used to indicate the engagedstate of systems with traditional entrance panels. Complete with flashing LED for visual indication of the system state. The white translucent card is supplied blank for writing any instructions. Dimensions: 106x106x56 mm 3186 Stainless steel information / nameplate module > Module made of double 2.5 mm stainless steel plate, complete with white label forgeneral information (house n, etc.) and pre-printed label...
