Planux

Product catalog summary

Introduction and Concept Evolution

PlAnux is an advanced video door entry system developed by Comelit, leveraging over 50 years of expertise in security and automation. It combines innovative technology with elegant architectural design, focusing on versatility, user-friendliness, and aesthetic customization. The system features a "Sensitive Touch" monitor and customizable colored cover plates to suit various interior styles.

Design and Aesthetic Options

The product line offers three color collections—Classic (black and white), Prestige (soft, elegant tones), and Trendy (vibrant modern colors)—allowing users to personalize their living spaces with devices that reflect their style preferences.

Key Features and Functional Specifications

  • Video recording and storage on an SD card, supporting up to 100 mini-videos of 10 seconds each for missed calls.
  • 3.5" color touch-screen monitor with intuitive full-screen navigation.
  • Full-duplex hands-free audio communication ensuring face-to-face conversation quality.
  • "Sensitive Touch" illuminated control keys that activate upon hand movement for enhanced usability.
  • Polyphonic ringtone customization with seven selectable tones stored on the SD card.
  • Multiple installation options: flush-mounted, surface-mounted, or desktop base with matching accessories.
  • Menu personalization including renaming, programmable keys, and priority function ordering.
  • Accessibility features such as Induction Loop amplification for hearing aid users.

Control Interface and User Interaction

The system includes ten control pushbuttons managing audio volume, door lock release, menu navigation, privacy mode, and a doctor mode that disables automatic door lock activation. The interface is designed for simplicity and intuitiveness, with menu structures similar to advanced mobile devices to facilitate easy customization and function selection.

System Architecture and Wiring

PlAnux employs Simplebus Color two-wire technology, ensuring high performance and superior color definition. It supports up to 100 users and includes components such as audio-video inputs, risers, and electronic name directories. Installation flexibility is enhanced by various mounting accessories including flush-mount boxes, surface housings, wall brackets, and desktop bases.

Product Variants and Accessories

  • Monitors: Available in Absolute Black and All White, including the Planux Memo version with video memory and touch-screen control.
  • Accessories: Desktop bases with RJ45 cables, flush-mount boxes, surface housings, tilt accessories for adjustable viewing angles, and plasterboard mounting kits.
  • Customization: Colored module holder frames and interchangeable cover plates to match interior decor.

Installation and Usage Recommendations

For simplified use, PlAnux can be configured to provide only entry call and door lock release functions by excluding other features and using a specific bezel. Privacy and doctor modes allow control over call ringtone and door lock activation, enhancing security and user control.

Summary of Technical Parameters

  • Monitor dimensions: 145x145x33 mm (desktop base and mounting accessories vary).
  • Display: 3.5" color screen with On-Screen Display (OSD).
  • Power supply: Requires additional power units; options include individual transformers or centralized power supplies supporting multiple monitors.
  • Communication: Full-duplex hands-free audio with conversation privacy.
  • Storage: Supplied with a 2 GB SD card for video recording and ringtone customization.

Product Specifications

The SIMPLEBUS COLOR system includes a central power supply unit (art. 1536) capable of powering up to 8 monitors, measuring 145x145x33 mm and available in Absolute Black. A bracket (model 6214C) designed for the PLANUX MEMOVIDEO monitor supports floor door calls and call repetition, with dimensions 96x106x17 mm.

Company Contact Information

Comelit Group provides extensive global support with offices in Italy, Belgium, Germany, Spain, France, the Netherlands, China, Russia, Singapore, Greece, UAE, the UK, and the USA. Contact details include addresses, phone/fax numbers, websites, and emails for sales, technical support, and service inquiries.

Key Points and Recommendations

  • Centralized power supply units are recommended for installations with multiple monitors (up to 8) to ensure reliable operation.
  • The 6214C bracket is essential for proper wiring and functionality of the PLANUX MEMOVIDEO monitor within the SIMPLEBUS COLOR system.
  • Accurate adherence to specified dimensions and color options is critical for installation planning and aesthetic integration.
  • Users should contact the appropriate regional Comelit office for technical support, sales, or service needs.

Conclusion

PlAnux by Comelit is a cutting-edge video door entry system that integrates advanced technology, customizable design, and user-friendly operation. Its modularity, aesthetic versatility, and rich functionality make it suitable for diverse residential and commercial applications, enhancing security and convenience while complementing modern interior design.

See more

Catalog excerpts

Planux-2

With over 50 years’ experience and commitment to constant innovation, Comelit designs and manufactures the best Video Door Entry, CCTV, Security and Domestic Automation systems. Despite its international dimensions, Comelit retains a level of entrepreneurial vitality and attention to customers more typically associated with a genuinely glocal company. Comelit products are sold in over 70 countries worldwide through an extensive technical and sales network. Their quality is guaranteed by leading-edge technological research, ongoing optimisation of functional and application processes and pure-bred...

 Open the catalog to page 2
Planux-3

Sensitive Touch: the sensitive revolution A touch of magic before your very eyes: just move your hand in front of the screen and the control keys illuminate for easy use and recognition. You can control all the functions with the utmost ease and a simple movement of the hand that never fails to charm and surprise. When a call comes in, the display and keys of Planux illuminate automatically with Comelit’s unmistakeable blue courtesy light, and the “audio” and “door lock release” function keys start flashing. Giving you better control of the situation, day and night. 4 5

 Open the catalog to page 3
Planux-4

Colours to suit every life style Absolute Black Classic Charm, originality and personality are the hallmark of every version. The range comes in three lines of colours - Classic, Prestige and Trendy - each reflecting a different way of living and looking at the world. With Planux every living space takes on the personality of its owner. All White Wengé The classic version, in All White and Absolute Black, is for lovers of timeless perfection. Prestige The Prestige line, embellished with soft but intense colours, is for customers who want a touch of originality and prestige. Green Valley 6 Blue...

 Open the catalog to page 4
Planux-5

The touch-screen door entry monitor with video memory service Attractive, simple and intuitive, Planux Memo represents the evolution of door entry monitor systems, the point at which style, innovation and design converge. Planux Memo can record up to 100 mini-videos of 10 seconds each if a call goes unanswered; these messages can also be stored on the SD Card and viewed as desired. The touch-screen colour door entry monitor offers simple and instant whole-screen navigation via the various menus. It is available in two elegant versions, Absolute Black and All White, and is a unique and indispensible...

 Open the catalog to page 5
Planux-6

A monitor measuring just 145x145 mm and a 3.5” colour display in several variants, designed to meet a comprehensive range of aesthetic and personal requirements. No less than 3 versions are available for surface-mounting: traditional, with depth of just 33 mm; flush-mounting, a protrusion of only 8 mm, with tilting monitor and the uniquely elegant and practical desktop version with coordinated base. High technological profile with ultra-flat lines Many installation possibilities, one common advantage: the SimpleBus Color system. Two-wire technology that ensures maximum performance and high definition...

 Open the catalog to page 6
Planux-8

Technology that really makes you feel at home Versatility and personalisation are the guiding principles of Planux. This advanced monitor lies at the heart of this innovative concept of service. Equipped with ten control pushbuttons, including audio volume control, door lock release, menu access and navigation, quick name directory selection, with“privacy” and “doctor” functions for enabling/ disabling the call ringtone and automatic activation of the lock respectively. This innovative approach finds expression in the on-screen display technology. Control, adjustment and function selection are...

 Open the catalog to page 8
Planux-9

Video door entry system with SIMPLEBUS COLOR wiring consisting of: - one audio-video input with digital call module complete with electronic name directory electric door lock ' for use in conjunction with: flush-mount box (art. 6117), wall bracket (art. 6120 - 6121) or desktop base (art. 6112 - 6113) * For the wall-mounted version, add case art. 3316/3; it is no longer necessary to order flush-mount box art. 3110/3. "The module holder frame is available in the following colours: GREY (3311/G), WHITE (3311/W), BLUE (3311/B), ORANGE Video door entry system with SIMPLEBUS COLOR wiring electric door...

 Open the catalog to page 9
Planux-10

6101B | PLANUX monitor in BLACK 6112 | Desktop base with 8 terminals for PLANUX monitor 3.5” COLOUR monitor with OSD. Equipped with “sensitive touch” technology and full-duplex handsfree function. Audio, ringtone, colour, brightness and contrast controls. You can select the ringtone you want from a choice of 7 different tunes. Equipped with door lock release pushbutton with led, audio enable/disable pushbutton with led, privacy or doctor function (selectable from menu) pushbutton, automatic switch-on pushbutton, 2 spare pushbuttons for various uses and 4 pushbuttons for menu access, navigation...

 Open the catalog to page 10
Planux-11

13764T06.09 Comelit Group SpA Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo - Bergamo - Italy Tel. +39 0346 750 011 - Fax +39 0346 71436 - www.comelit.eu - www.simplehome.eu - [email protected] [ F ] Comelit Immotec Siège: Parc d’activités Technologiques EUROPARC 3, Allées des Saules - 94042 CRETEIL CEDEX Tél. +33 (0) 1 43 53 97 97 Fax +33 (0) 1 43 53 97 87 Centre logistique livraisons - commandes 15, Rue Jean Zay - 69800 SAINT PRIEST Tél. +33 (0) 4 72 28 06 56 Fax +33 (0) 4 72 28 83 29 www.comelit.fr - [email protected] [ I ] Comelit Sud S.r.l. Via Corso Claudio, 18 84083 Castel San Giorgio...

 Open the catalog to page 11
