Clipsal
Firetek Surface Mounted Smoke Detectors

Firetek Surface Mounted Smoke Detectors

Product catalog summary

Product Overview: The 755PSMA and 755SMA are surface mount smoke detectors designed for reliability and safety. They feature a smooth, contemporary design with unobtrusive lines and are mains powered for consistent operation. The detectors have a minimized overall diameter and include a Hush button to silence unwanted alarms. A built-in test facility ensures the unit is functioning correctly, and large Hush/Test buttons allow easy operation.

Key Features:

Red and green LED indicators for clear status display.
Interconnect facility for connecting multiple units, ensuring all alarms sound when smoke is detected.
Push-fit detector module with quick-fit terminals for easy installation.
Interlock mechanism prevents operation without a battery, ensuring backup power.
Simple and safe battery access and replacement.
Protected from nuisance tripping with insect barrier mesh and enclosed base.

Specifications:

Primary Power Supply: 220-240V a.c. 50Hz
Secondary Power Supply: 9V d.c. Alkaline Battery Backup
Operating Current: 35mA
Horn Level: 85dB at 3 metres minimum
Interconnect Facility: Up to 40 units over 150 metres
Dimensions: ø135 x 48mm
Complies with Australian Standard AS3786

Installation: The installation process involves removing the protective cover from power terminals, connecting power to in-line terminals, interconnecting other units as necessary, attaching the alarm unit to the ceiling-mounted base, and securing the base with screws. The alarm can be easily released for battery access.

Applications: The 755PSMA is suitable for lounges, living areas, bedrooms, and rumpus rooms, while the 755SMA is ideal for hallways, corridors, studies, and home offices.

Additional Information: The product is listed by ActivFire and complies with AS3786 and AS/NZS3100 standards. It comes with a 5-year limited warranty and is a quality endorsed certified product by SAI Global.

Catalog excerpts

Firetek Surface Mounted Smoke Detectors-1

Ionisation Smoke Detector > Photoelectric Smoke Detector >

Open the catalog to page 1

Firetek Surface Mounted Smoke Detectors-2

MODEL TYPE TYPICAL APPLICATIONS 755PSMA Photoelectric ԕ Lounge Living areas Օ Bedrooms Rumpus755SMA Ionisation Օ Hallway Corridor Օ Study Home offi ce >

Open the catalog to page 2

Firetek Surface Mounted Smoke Detectors-3

contemporary styling and smooth lines will blend in with any decor mains powered, 220-240V a.c. 50Hz 35mA 9V d.c. battery backup (included) quick fi t-off/easy installation ultra reliable operation loud alarm indication: 85dB at 3 metres interconnectable up to 40 units low battery indication (audible and visual) Hush button to silence unwanted alarms built in test facility to check unit function unit cannot be operated without 9V battery fi tted dust cover to prevent contamination during installation complies with Australian Standard AS3786, Smoke Alarms > Contemporary styling, and smooth lines,...

Open the catalog to page 3

Firetek Surface Mounted Smoke Detectors-4

1 2 Catalogue Number 755PSMA 755SMA Primary Power Supply220-240V a.c. 50HzSecondary Power Supply9V d.c. Alkaline Battery BackupOperating Current35mADetector Type Photoelectric Chamber Ionisation Chamber Unit contains no Americurium 241, <1kBq radioactive material (1 microcurie)Horn Level85dB at 3 metres minimumVisual IndicatorsGreen LED for mains power ONRed LED for warning and low battery indicationLow Battery AlarmYes Audible and Visual AlertHush ModeYes Silences unwanted alarms, 10 minutesInterconnect FacilityYes 40 Alarms over 150 metres maximumOverall Dimensions Remove protective plastic...

Open the catalog to page 4
