Firetek 755 Series Smoke Alarms

Firetek 755 Series Smoke Alarms
1 / 16 PagesView full catalog

Firetek 755 Series Smoke Alarms

Product catalog summary
Introduction
In Australia, house fires annually cause over 70 deaths, 1,500 injuries, and significant property damage. The Clipsal Firetek™ 755 Series Smoke Alarms are designed to provide continuous protection against fire and smoke, offering early warnings to minimize damage and save lives.
Product Overview
The 755 Series includes ionisation and photoelectric models, available in surface and flush mount designs. These alarms are mains powered with a 9V battery backup, ensuring operation during power outages. They can interconnect up to 40 units for comprehensive coverage.
Design and Features
The flush mount model is compact, blending with modern decor. Both models feature a Test/Hush button for easy operation and false alarm control, emit a loud 85dB sound, and have visual status indicators.
Compliance and Warranty
All models comply with Australian Standard AS3786, are ActivFire listed, and come with a five-year limited warranty, endorsed by SAI Global.
Installation Recommendations
Smoke alarms should be installed in multiple home locations, excluding kitchens, bathrooms, and garages. Interconnected alarms provide optimal protection by sounding simultaneously when smoke is detected.
Specifications and Recommendations
Smoke alarms can link up to forty units for early fire danger warnings. Install alarms on ceilings above stairways and interconnect with adjacent rooms. Photoelectric alarms are recommended for extra protection.
Installation Guidelines
Avoid 'dead air spaces' for optimal response. Multiple interconnected alarms ensure the audible alarm is heard throughout the house, as the sense of smell is inactive during sleep.
Escape Plan
Develop a fire escape plan with at least two escape routes from each room, an assembly point outside, and practice regularly. Familiarize family members with the alarm sound and conduct fire drills every six months.
Maintenance and Testing
Regular maintenance is crucial. Test the battery monthly, replace it annually, and replace the smoke alarm unit every ten years. High-quality alarms from reputable suppliers like Clipsal FireTek™ are recommended, and professional installation is advised.
Emergency Procedures
In case of fire, follow the escape plan, check doors for heat before opening, stay low in smoky air, and assemble at the meeting place. Do not re-enter until fire officials permit.
Conclusion
For optimal fire safety, use high-quality, interconnected smoke alarms, maintain them regularly, and have a well-practiced escape plan. Consult professionals for advice on selection, location, and installation of smoke alarms.
See more

Catalog excerpts

Firetek 755 Series Smoke Alarms-2

Tragically, each year in Australia there are over 10,000 house fi res resulting in more than 70 deaths, 1,500 injuries and millions of dollars worth of property damage.These kinds of fi res happen all too frequently, and the fact is, they happen fast. A house can be literally razed to the ground in less than 15 minutes. Thats why itҒs essential for every home to be fi tted with a suffi cient number of appropriate and suitably placed mains powered smoke alarms.Installing a high quality smoke alarm ensures your peace of mind by offering you 24 hour a day protection for your family and home against...

 Open the catalog to page 2
Firetek 755 Series Smoke Alarms-3

Todays modern housing demands electrical accessories that are not only of the highest quality, but look the part too. Designed to blend in with any dҩcor, the stylish new Clipsal Firetek > TM 755 Series Flush Mount Smoke Alarm offers premium protection against fi re danger, but is an incredible 60% smaller than a regular smoke alarm.At last, style and safety have come together to offer you and your family unrivalled protection, with a sleek, unobtrusive smoke alarm design. The smaller diameter of the Flush Mount alarm allows it to fi t in visually with ceiling mounted downlights. Now thats innovative!...

 Open the catalog to page 3
Firetek 755 Series Smoke Alarms-4

Who says smoke alarms cant be stylish? Clipsal FiretekҒs new fl ush mount model offers you and your family maximum protection against smoke and fi re danger but is an amazing 60% smaller than a traditional smoke alarm.Featuring a sleek, modern design that blends into any d٩cor, the fl ush mount smoke alarm offers you total protection without compromising on style. ultra reliable operation easy installation > interconnectable up to 40 units Super low profi le, fully recessed design dust cover to prevent contamination during installation loud alarm indication: 85dB at 3 metres > A combined single...

 Open the catalog to page 4
Firetek 755 Series Smoke Alarms-5

mains powered 220-240V a.c. 50Hz 35mA 9V d.c. battery backup (included) unit cannot be operated without 9V battery fi tted > 5 year limited warranty complies with AustralianStandard AS3786, Smoke Alarms > Approx. 140mm low battery indication(audible and visual)hush button to silence unwanted alarms > Size of typical smoke alarm 108mm status Clipsal Firetek smoke alarms incorporate both audible and visual indicators to notify occupants of the alarm status. During normal operation, a green indicator signifi es power available, whilst a red indicator fl ashes about once per minute showing the battery...

 Open the catalog to page 5
Firetek 755 Series Smoke Alarms-6

Clipsal Fireteksҙ surface mount smoke alarm feature a stylish, state of the art design. The alarm is fully mains powered and features a 9V battery backup in case of power failure so your family is always protected.Audible and visual indicators draw the occupants attention to any alarm condition or to alert the homeowner of a low battery status.The unit is interconnectable (up to 40 units), making it ideal for any domestic or commercial installation. When activated, the alarm sounds at a loud 85db to alert occupants. A large test/hush button can be used to regularly test the unit for normal function,...

 Open the catalog to page 6
Firetek 755 Series Smoke Alarms-7

5 year limited warranty 9V d.c. battery backup (included) unit cannot be operatedwithout 9V battery fi tted mains powered 220-240V a.c. 50Hz 35mAloud alarm indication: 85dB at 3 metres built in test facility to test unit functionultra reliable operation complies with AustralianStandard AS3786, Smoke Alarms low battery indication (audible and visual) > status Clipsal Firetek smoke alarms incorporate both audible and visual indicators to notify occupants of the alarm status.During normal operation, a green indicator signifi es power available, whilst a red indicator fl ashes about once per minute...

 Open the catalog to page 7
Firetek 755 Series Smoke Alarms-8

All Clipsal FireTek smoke alarms are designed to ensure maximum protection in residential and commercial applications. Each model available carries the RCM mark, ensuring electrical safety and EMC compliance (emissions and immunity). All units comply with the latest Australian standards (AS3786 Smoke Alarms) and are ActivFire listed to ensure compliance with the Building Code of Australia (BCA). Units are manufactured to the highest quality standard as endorsed by SAI Global as a Certifi ed Product. Independent auditing ensures manufacturing facilities are compliant with ISO 9001. Clipsal FireTekٙ...

 Open the catalog to page 8
Firetek 755 Series Smoke Alarms-9

Surface and fl ush mount models available Available in photoelectric and ionisation detection technologies for optimum response times Mains powered smoke alarm 220-240 a.c. 50Hz 35mA 9V d.c. battery backup (included) Quick fi t-off/easy installation Loud alarm indication: 85dB at 3 metres Ability to interconnect up to 40 units Low battery indication (audible and visual) False alarm control using Hush button (available on both models) Built-in test facility Unit cannot be operated without 9V battery fi tted Dust cover to prevent contamination during installation Complies with Australian Standard...

 Open the catalog to page 9
Firetek 755 Series Smoke Alarms-10

When choosing a smoke alarm, it is important to know that different models use different methods to detect smoke. There are two main types of smoke detectors: ionisation, and photoelectric types. Each is specifi cally designed to detect different types of smoke, and give the earliest possible warning in the event of a fi re.The amount of warning given depends on the type of combustible material that is burning, and the type of alarm selected for your home. The more warning you get, the more time you have to escape the deadly toxic smoke and fl ames.Ionisation type alarms respond faster to small...

 Open the catalog to page 10
Firetek 755 Series Smoke Alarms-11

Australian Bureau of Statistics >

 Open the catalog to page 11
Firetek 755 Series Smoke Alarms-12

It is recommended additional alarms be installed in the bedrooms, interconnected with those located in passageways and other parts of the dwelling, to ensure that you are alerted by the activation of any alarm. If bedrooms are accessed directly from the living area, install the alarm outside each bedroom 900mm from the doorway. For additional protection, have interconnected alarms in the bedrooms as close as practicable to the centre of each room. Smoke alarm installation locations should be carefully selected in order to maximise their effectiveness and response time. It is also important to...

 Open the catalog to page 12
