Overview: The document outlines the technical specifications and installation guidelines for the Modo Free Plafone lighting system, part of the Modo Free family. These modular lighting fixtures are designed for flexibility and high performance, suitable for environments like showrooms, exhibition areas, and shopping centers.

Specifications: The Modo Free Plafone is made from painted sheet metal and comes in various configurations, including ceiling versions with 70W and 150W metal halide bulbs. The 150W versions feature a 35 mm spacer for heat dissipation. The system also includes fluorescent modules in sizes of 600 mm, 1200 mm, and 1500 mm, equipped with electronic ballasts.

Installation Guidelines: A 150 mm distance must be maintained between the bulb and the feeder for proper heat dissipation. The document specifies the use of recessed housings and diffusers in various sizes to meet different installation requirements.

Performance Data: Detailed photometric data is provided for various configurations, highlighting luminous flux, efficiency, and light distribution characteristics. For instance, the Modo Free 2x55W TC-L Recessed has a total luminous flux of 9600 lm and a maximum value of 154.30 cd/klm.

Accessories: The system supports various accessories, including opal polycarbonate diffusers and electronic transformers, to enhance functionality and adaptability.

Color Options: Fixtures are available in multiple color finishes, such as RAL9010, RAL9005, and RAL7035.
