VERTICAL SHOWCASES Refrigeration solutions with a design focus.

The ultimate vertical customisation Fresh pastry Cold deli products Packed meet Cheese and dairy products Cured meats White wine Frozen pastry Refrigerated wall cabinets at positive and low temperature. The Exclusive cabinets are divided into four families: Exclusive 51P with a depth of 50cm, evaporator positioned on the back panel, positive temperature only and standard flush with the cabinet Zero model doors; Exclusive 74P with a depth of 70cm, positive temperature only and standard flush with the cabinet Zero model doors; Exclusive 74S with a depth of 70cm, positive or low temperature and...

Exclusive 74P Custom dim. mm. 2400x700x3800H | positive temperature with Zero doors coated in satin brass electroplated steel (cod. LGOS) | Gres internal sides and back | standard and shelft4 type shelves with brass finish | no-spot LED strip lighting 3000°K Exclusive 74P dim. mm. 2400x700x2250H | positive temperature with matt black (RAL7021) Zero doors | Sides with glass window | back in Noir Desir Gres (cod. GLNDO) | shelft1, shelft3a, shelft5 epoxy powder coated RAL7021 | no-spot LED strip lighting 3000°K The tanks are monolithic and available in the following standard lengths: 600, 1200,...

Wine Room Exclusive 74P L2400 positive temperature with Zero doors, exterior in electroplated steel satin-finish brass (cod. LGOS), internal sides, back and bottom shelf in natural grey cardoso stoneware (cod. GLPCGN), shelft1, shelft3b, shelft4 type shelves in brass finish, 3000°K no-spot LED strip lighting.

Pastry Shop Exclusive 74S (L1200 low temp.) with Premium doors Exclusive 74S (L1200 positive temp. + L1200 low temp.) with Premium doors Exclusive 74S (L1200 positive temp. + L1200 low temp.) with Premium doors, RAL9003 epoxy powder coated steel exterior, Premium doors with RAL9003 white screen printing and natural satin brass handle (cod. LO10NSLC), sides with glass window, RAL9003 epoxy powder coated steel interior, shelft5 type glass shelves, Ciam touch Pro panel, 3000°K no-spot LED strip lighting, channeling with glass side.

Butcher’s shop Exclusive 74S (L1200 meats + L1200 meats), exterior in vintage bronze electroplated sheet (cod. LGBV), Premium doors with Moka RAL8019 (cod LVP8019) screen printing and handle in vintage bronze electroplated sheet (cod LGBV), solid sides, interior in satin-finish steel (cod AC07S), Standard stainless steel shelves and hook for hanging charcuterie (shelft8 optional), touch control unit, 3000°K no-spot LED strip lighting, channeling with glass side. Exclusive MA (L1200 meat dry aging + L1200 meat), exteriors in vintage bronze electroplated sheet (cod. LGBV), Premium doors with Moka...

Luxury Food Hall Back detail in natural oak wood Detail of internal equipment in electroplated steel Oro24 (cod.LGORO24) and back in polished statuario venato gres (cod. GLBSVL) Exclusive 74P L2400 temp. positive with Zero doors, exterior and doors in Oro24 electroplated steel (cod LGORO24), sides with glass window, back in polished statuario venato gres (cod GLBSVL), standard type shelves and shelft8 in Oro24 electroplated steel (cod LGORO24), touch control unit, 3000°K no-spot LED strip lighting, channeling with glass side. Exclusive 74P L1200 temp. positive with Zero doors, exterior and doors...

Positive and low temperature refrigeration The Exclusive 51P, 74P and MA cabinets have positive temperature version only, while the Exclusive 74S is available in both positive and low temperature versions. Humidity control It is possible to have humidity control on the positive temperature cabinets upon request, especially for fresh pastry and praline applications; this is compatible with both the standard touch control unit and the Touch Pro control panel. Positive and low temperature refrigeration All cooling systems are cataphoretically treated and guarantee maximum hygiene as the copper tubes...

Lighting Light is fundamental for a correct spectacular display of the products, which is why Ciam has chosen to install an elegant indirect lighting system with 3000°K no-spot LED strips. Dimmer to adjust the intensity of the lighting (Option). Electrical components box The electrical system is contained in a hermetically sealed box with quick connectors, simplifying installation and maintenance. 3000°K no-spot strip LED lighting. CIAM CONNECT 1. Connectivity The device allows remote control of the showcase thanks to connectivity with a Sim card that does not require wi-fi or a connection to...

Doors Zero doors with double-glazed glass Double-glazed glass with matt black screen printing, base structure and handle epoxy powder coated in RAL7021. Magnetic lock Heated glazing Positive-temperature refrigerators can be equipped with heated low-emission double-glazed glass, while low-temperature models have heated glazing as standard. Anti-fog film All doors are supplied with an anti-fog film as standard. This prevents the inner surface of the double-glazed glass from fogging up when the door is opened. Zero Doors Premium Doors Slide Doors Double-glazed sliding doors on an aluminium track...

Customisation of colours, materials and finishes Exclusive refrigerated cabinets have been designed for maximum customisation of materials and finishes to meet all stylistic requirements. Customised dimensions on request All Exclusive cabinets can be customised in terms of dimensions on request. Glass sides Instead of a solid side, it is possible to install a double-glazed side on all Exclusive models. Flush mounting (only for Zero type doors) In the case of Zero doors, it is possible to request prearrangement for refrigerator flush with the wall. Channeling modules in continuity All Exclusive...

Shelves Customisation is also possible through the choice of 8 types of shelves, all with adjustable rack and pinion rod systems. The standard finishes and materials are polished steel, matt black epoxy coated steel (RAL 7021) and matt white epoxy powder coated steel (RAL 9010); optional are the RAL colours of your choice, Gres, acrylics and wood where applicable. Indirect lighting is vertical and fitted on the door frame with 3000°K no-spot LED strips. Standard Steel profiles for horizontal bottle display; standard finishes: polished stainless-steel, epoxy powder coated steel RAL 7021 or RAL...
