Product catalog summary

Introduction
The document outlines the adherence to the UNI EN 14411 standard by Rondine S.p.A., which ensures high-quality ceramic tiles through continuous testing and quality control.

Laying Procedures
Before laying tiles, verify shade, size, and material. Use tiles from multiple boxes for color consistency. Ensure the surface is stable, dry, and at an appropriate temperature. Use suitable adhesives and apply them professionally to avoid gaps. For smooth surfaces, avoid marking with pencils or permanent markers. Use diamond cutters for precise cuts, especially with porcelain stoneware. Recommended joint sizes are 3 mm for non-rectified and 2 mm for rectified products. In large rooms, use expansion joints regularly; in small rooms, leave a slight gap between tiles and walls.

Grouting and Cleaning
Test colored fillers before use. Avoid contrast-colored fillers on smooth surfaces due to microporosity. Remove excess grout immediately with water and a sponge. Clean thoroughly with buffered acids a few days after laying to remove residues. Use liquid extractors to remove dirty water.

Maintenance
For polished surfaces, use neutral detergents like Fila Cleaner for daily cleaning and periodic stain-resistant treatments. Avoid products containing hydrofluoric acid as they damage tile surfaces. Proper post-laying cleaning is crucial to avoid residue-related issues.

Product Specifications
Various tile sizes and thicknesses are available, with specific packing and weight details provided. The document includes detailed product codes and pricing information for different tile formats and finishes.

Specifications and Standards
The document references the UNI EN 14411 standard, which defines terms, standards, and criteria for first-choice ceramic tiles. Rondine S.p.A. conducts all tests required by this standard using accredited laboratories and implements internal quality control procedures.

Installation Procedures
Before installation, the installer must check the shade, size, and material choice, ensuring an ideal color mix by taking tiles from multiple boxes. The installer should use appropriate adhesives and follow manufacturer instructions, ensuring the substrate is stable, dry, and not excessively hot or cold. For polished, satin, or honed products, avoid marking the surface with pencils or permanent markers. Use diamond discs and specific equipment for cutting and profiling, especially for porcelain stoneware.

Jointing and Post-Installation Cleaning
Colored mortars or jointing products should be tested before use. For polished surfaces, avoid contrasting colored mortars due to microporosity. After jointing, excess mortar should be removed immediately with a sponge and water. A thorough cleaning with buffered acids is recommended a few days after installation to remove residues. Use a liquid vacuum to remove dirty water.

Recommendations for Cleaning and Maintenance
For daily cleaning of smooth surfaces, use Fila Cleaner, adhering to dilution recommendations. Regular anti-stain treatments are advised to protect tiles from damage. Avoid detergents containing hydrofluoric acid as they can permanently damage tile surfaces. Proper post-installation washing is crucial to remove residues and prevent complaints.

Special Applications and Products
For waterproof grouting, epoxy mortar can be used, following manufacturer instructions. Consult expert tilers for epoxy applications to avoid compromising tile appearance. Rondine recommends FILA Deterdek for cleaning, which is an acid descaling agent without harmful fumes.

Additional Recommendations
For rectangular tiles, stagger them by no more than 6-10 cm. Suggested joint widths are 3 mm for non-rectified products and 2 mm for rectified products. For large spaces, regular expansion joints are necessary, while small spaces require a slight gap between tiles and walls, covered by skirting boards.

Special Production and Ordering
Special trims and decors require a minimum order quantity and are produced in 3-4 weeks. Leveling spacers are recommended for tiles larger than 60 cm to ensure a flat surface and reduce installation time.

Tile Installation Recommendations
Ceramica Rondine recommends using Raimondi levelling spacers, such as the Levelling System and AndalSystem, for tiles with sides over 60 cm. These spacers help ensure a flat surface, maintain tile position, and reduce installation time. A demonstration video is available on the Ceramica Rondine YouTube channel.

Technical Specifications
The document outlines various technical properties and standards for tiles, including frost resistance, stain resistance, and abrasion resistance. Key standards mentioned include UNI EN ISO 10545-12 for frost resistance and UNI EN ISO 10545-14 for stain resistance, with specific class requirements for each property.

Dimensional Tolerances
The permissible deviations for tile dimensions, thickness, straightness, squareness, and planarity are specified. These tolerances are expressed in percentages or millimeters relative to the work size.

Usage Recommendations
Tiles are categorized based on their suitability for different environments, such as residential areas, low or heavy traffic public areas, and outdoor applications. The variation index (V1 to V4) indicates the degree of shade and graphic variation in the tiles.

Company Information
ITALCER S.p.A. is the company responsible for the production and distribution of these tiles, with contact information provided for further inquiries.

Catalog excerpts

CERAMICA RONDINE

Open the catalog to page 1

Dalla tradizionale pavimentazione in cemento industriale nasce l’ispirazione per questo nuovo progetto dal nome “Loft”, firmato Ceramica Rondine. Tutta la grinta del cemento nella sua forma più naturale, miscelata con eleganza in sei colori e in diversi formati: dal 30x60 fino al nuovissimo 100x100. Completa in tutte le sue forme, la serie Loft è funzionale, resistente e di design; vi permetterà di arredare i vostri ambienti con uno stile minimal che non passerà inosservato. The inspiration for this new project called "Loft" was born from the traditional industrial concrete flooring. The natural...

Open the catalog to page 3

Loft Surfaces

Open the catalog to page 4

Loft Dark wall Loft - Dark 20x80 + 40x80 + 80x80 floor Loft - Light Grey 100x100 Loft - Pompei Light Grey 100x100 6

Open the catalog to page 5

wall Loft - Dark 20x80 + 40x80 + 80x80 Canova - Lasa White 60x120 floor Loft - Dark 100x100 + Pompei Dark 100x100 Loft - White 100x100 + Pompei White 100x100 8

Open the catalog to page 6

NATURALE / NATURAL

Open the catalog to page 7

STRUTTURATO STRONG R11 / STRUCTURED STRONG R11

Open the catalog to page 8

dark decoro pompei 100x100 rett. 6 100x100 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER

Open the catalog to page 9

dark sviluppo grafico 100x100 rett. 12 100x100 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 12 80x80 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 24 40x80 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 48 20x80 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 32 60x60 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 64 30x60 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER

Open the catalog to page 10

wall Loft - Light Grey 20x80 + 40x80 + 80x80 floor Loft - Dark 100x100 H20

Open the catalog to page 11

Loft Grey wall Loft - Grey 30x60 floor Loft - Grey 100x100

Open the catalog to page 12

wall Loft - White 20x80 + 40x80 + 80x80 Loft - Grey 20x80 + 40x80 + 80x80 Loft - Light Grey 20x80 + 40x80 + 80x80 floor Loft - Grey Lappato 100x100 22

Open the catalog to page 13

NATURALE / NATURAL

Open the catalog to page 14

STRUTTURATO STRONG R11 / STRUCTURED STRONG R11

Open the catalog to page 15

grey decoro pompei 100x100 rett. 6 100x100 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER

Open the catalog to page 16

grey sviluppo grafico 100x100 rett. 12 100x100 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 12 80x80 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 24 40x80 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 48 20x80 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 32 60x60 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 64 30x60 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER

Open the catalog to page 17

wall Loft 3D - Grey 15x61 floor Loft - Grey Lappato 100x100

Open the catalog to page 18

Loft Light Grey wall Loft - Light Grey 20x80 Loft - Light Grey Lappato 20x80 Loft - Light Grey Strutturato R10 20x80 floor Loft - Light Grey Strutturato Strong R11 40x80 34

Open the catalog to page 19

wall Loft - Light Grey 20x80 Loft - Light Grey Lappato 20x80 Loft - Light Grey Strutturato R10 20x80 Daring - Nut 24x120 floor Loft - Light Grey Strutturato Strong R11 40x80 36

Open the catalog to page 20

light grey NATURALE / NATURAL

Open the catalog to page 21

light grey STRUTTURATO STRONG R11 / STRUCTURED STRONG R11

Open the catalog to page 22

light grey decoro pompei 100x100 rett. 6 100x100 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER

Open the catalog to page 23

light grey sviluppo grafico 100x100 rett. 12 100x100 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 12 80x80 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 24 40x80 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 48 20x80 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 32 60x60 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 64 30x60 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER

Open the catalog to page 24

Loft White wall Loft - Jungle Cold 40x80 floor Loft - White 100x100

Open the catalog to page 25

wall Loft - Jungle Cold 40x80 floor Loft - White 100x100 Loft - White Strutturato Strong R11 100x100 48

Open the catalog to page 26

NATURALE / NATURAL

Open the catalog to page 27

STRUTTURATO STRONG R11 / STRUCTURED STRONG R11

Open the catalog to page 28

white decoro pompei 100x100 rett. GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER jungle cold

Open the catalog to page 29

white sviluppo grafico 100x100 rett. 12 100x100 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 12 80x80 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 24 40x80 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 48 20x80 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 32 60x60 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 64 30x60 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER

Open the catalog to page 30

Loft Beige wall Loft - Beige Esagona 35x30,3 floor Loft - Beige Lappato 80x80

Open the catalog to page 31

wall Canova - Oxford Grey 60x120 Loft - Beige Lappato 40x80 floor Loft - Beige Lappato 80x80 60

Open the catalog to page 32

NATURALE / NATURAL

Open the catalog to page 33

STRUTTURATO STRONG R11 / STRUCTURED STRONG R11

Open the catalog to page 34

beige decoro pompei 100x100 rett. GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER

Open the catalog to page 35

beige sviluppo grafico 100x100 rett. 12 100x100 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 12 80x80 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 24 40x80 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 48 20x80 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 32 60x60 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER 64 30x60 GRAFICHE DIVERSE DIFFERENT PATTERNS DIFFÉRENTS MOTIFS VERSCHIEDENE MUSTER
