Edition 49 catalogue

Edition 49 catalogue

Product catalog summary

Pro-Report Module Overview
The Pro-Report module is a comprehensive reporting tool that facilitates quick and efficient report generation through an automated wizard and a powerful search engine. It supports predefined and scheduled reports, handling data acquisition for time and attendance, including tracking missed clock-ins, lateness, and overtime. Key features include customizable overtime calculations, entrance and exit clocking, and the ability to export reports in various formats.

FrontView Graphic Interface
FrontView is a real-time management tool providing a graphical interface for controlling system components such as controllers, doors, and alarms. It supports Windows operating systems and allows for the import and creation of floor plans, as well as the use of interactive icons for system monitoring.

Card and Visitor Management
The system includes modules for card management, allowing operators to create, delete, and edit cards, and for visitor management, which records and monitors visitor activities. The FrontGuard module provides visual authentication by comparing real-time video with stored images.

Parking and Guard Tour Management
Centaur offers parking management capabilities, including real-time monitoring of parking space usage and the ability to generate usage reports. The guard tour management module supports live interactive tours with checkpoint validation and exception reporting.

CTV900A Controller
The CTV900A is a core component of the Centaur access-control system, supporting up to 2048 doors per site. It features a distributed database architecture for rapid decision-making and supports various communication formats. The controller is equipped with multiple inputs and outputs, and supports lift control for up to 64 floors.

Supplementary Modules
Several supplementary modules are available to enhance system capabilities, including the CAA470A for expanding access control, the CAETHRA for TCP/IP to RS-232 conversion, and the CAA110P for lock control. These modules offer additional inputs, outputs, and connectivity options to optimize site management.

Relay Expansion Modules
The CAA460P and CAA460PNB are 7-relay expansion modules designed for the CTV900A controller. Each module connects directly to the CTV900A expansion bus and can be placed up to 1220 meters away. The modules feature 7 Form C relays rated at 5A/28V DC, with both normally open (NO) and normally closed (NC) outputs. They require a 12V DC input voltage and consume a maximum of 450mA. The operating temperature range is +5°C to +55°C, and they are CE certified and FCC compliant.

RS-485 Network Hub
The CAA370P and CAA370PNB are RS-485 network hubs that allow a "star" type configuration, ideal for large multi-floor sites. These hubs can connect up to four additional RS-485 networks to controllers or expansion modules, providing higher network isolation and reducing wiring costs. They support transmission speeds of 9600 or 19200 bps, require a 12V DC input voltage, and consume a maximum of 100mA. The operating temperature range is +5°C to +55°C, and they are CE certified and FCC compliant.

Proximity Readers
The document details various proximity readers, including the NANO, STAR, and SOLAR series, which operate at 125 kHz and are compatible with the CTV900A and CAA470A controllers. These readers offer Wiegand outputs of 26, 30, or 44 bits, and feature reflective backlighting, audible and visual feedback, and are sealed in epoxy for durability. They are available in different colors and designs, with dimensions and weights varying by model. The readers comply with European R&TTE and EMC standards and are CE certified.

Biometric Readers
The DGIDW and CABAPROXW are biometric readers that support fingerprint recognition. The DGIDW can store up to 400 fingerprints, while the CABAPROXW offers unlimited fingerprint storage on cards or tags. Both readers provide encrypted communication and are compatible with the CTV900A and CAA470A controllers. They comply with European R&TTE and EMC standards and are CE certified.

Environmental and Certification Standards
All products mentioned comply with various environmental and certification standards, including CE certification, FCC compliance, and European R&TTE directives. They are designed to operate within specified temperature ranges and have undergone environmental tests for vibrations.

Overview: The document provides detailed specifications and descriptions of various access control products and systems offered by CDVI. It includes information on fingerprint readers, long-range readers, Wiegand radio receivers, proximity cards and tags, Mifare cards and tags, and internet-based access control systems.

Specifications:

Fingerprint Readers: Capable of storing up to 400 fingerprints per reader. Compatible with USB, RS485, Wiegand, RS422, RS232, and TCP/IP connections.
Long-Range Readers: Operate at 433.92 MHz with a range of up to 15 meters. They can read up to 20 tags simultaneously and are available in standalone versions.
Wiegand Radio Receivers: Available with 26 or 30 bits outputs, suitable for external installation (IP65), and have a range of up to 100 meters in open fields.
Proximity Cards and Tags: Available in various materials such as PVC, leather, and metal, with customizable printing options. Operate at 125 kHz.
Mifare Cards and Tags: Operate at 13.56 MHz, available in metal and polycarbonate materials, with customizable engraving options.

Procedures and Recommendations:

Installation: The document outlines the installation configurations for web-based management of access control, alarms, and lifts, supporting up to 128 doors per controller.
System Management: The TERENA controller is highlighted as the core of the access-control system, with capabilities for managing multiple technologies and providing internet-based control without the need for additional software.

Certifications and Standards:

Products are certified under CE, FCC CFR 47 Part 15, WEEE, and R&TTE certifications, ensuring compliance with international standards.

Key Features:

Internet access control supports up to 128 doors per controller, with data backup on SD card or USB key, and multi-language support.
Various modules are available for lift control, input/output management, and parking status, enhancing the flexibility and scalability of the system.

Output Board Module - DIN Rail Box
This module is designed for managing various peripherals and controls such as heating, air-conditioning, lights, intruder detection, access control, and alarm reporting. It features dimensions of 175 x 87 x 63mm and includes 56 input and output points. The I/O boards are connected via an RS485 bus and controlled by a controller. The input management card memorizes NO/NC switches, while the output management card transmits impulses to relays. The module is housed in a DIN rail modular box and operates on a 12V ac/dc input voltage with specific consumption rates for different cards.

Wiegand Multi-Protocol Proximity Readers
These readers are available in various models and are designed for high-performance access control. They support 125 kHz proximity technology and offer features such as reflective backlighting, audible and visual feedback, and high resistance to vandalism. The readers comply with European R&TTE and EMC standards and are suitable for public buildings, residential, industrial, and commercial applications.

Biometric and Mifare® Readers
The document details various biometric and Mifare® readers, including standalone fingerprint readers and dual-technology readers. These devices offer features like encrypted communication, high-resolution sensors, and the ability to store multiple fingerprints. They are designed for secure access control and comply with relevant European standards.

Environmental and Certification Standards
All devices mentioned comply with European R&TTE directive 99/5/EC and applicable EMC standards. They are designed to withstand environmental conditions such as vibrations and temperature variations, ensuring reliable performance in diverse settings.

Overview: This document provides detailed specifications and descriptions of various access control systems and components offered by CDVI Group. It includes information on standalone controllers, proximity readers, keypads, and accessories designed for public, residential, and commercial buildings.

1. Standalone 2-Door Controllers: The DG502UP is a standalone 2-door controller with features such as 2 relay outputs, support for 500 proximity tags, tamper switch, and audible/visual feedback. It is available with either an aluminum or polycarbonate front panel and keys. The controller is FCC and CE certified, suitable for various environments, and operates within a temperature range of -10°C to +70°C.

2. Proximity Readers: The document describes different types of proximity readers, including polycarbonate and stainless-steel models. These readers are designed for direct connection to controllers, provide audible and visual feedback, and are compliant with European R&TTE and EMC standards. They operate at 125 kHz and are suitable for surface mounting.

3. Hands-Free and Long-Range Readers: The DGLP60 is a hands-free proximity reader with a reading distance of up to 60cm, while the DTRR1434 is a long-range reader with an adjustable range of up to 15m. Both devices are designed for easy integration with access control systems and are certified for compliance with relevant standards.

4. Accessories and Tags: Various accessories such as desktop enrolment units, RF transmitters, and proximity tags are detailed. These components are designed to enhance the functionality and ease of use of the access control systems. The document also highlights the environmental certifications and compliance of these products.

5. Mifare® Controllers: The DGM1D is a standalone Mifare® controller capable of managing up to 100 doors and an unlimited number of users. It supports easy programming and data transfer via PC and is compatible with various Mifare® tags and cards. The controller is designed for robust security applications and offers features like blacklist mode and wireless cancellation of tags.

Conclusion: CDVI Group offers a comprehensive range of access control solutions tailored for different environments and requirements. The products are designed for reliability, ease of installation, and compliance with international standards, ensuring they meet the needs of modern security systems.

Overview: The document provides detailed specifications and descriptions of various Digicode® keypads and access control systems offered by CDVI. These products are designed for securing access in residential, commercial, and industrial settings.

Key Sections:

Specifications: The document lists multiple models of Digicode® keypads, highlighting their materials (stainless steel, cast aluminium, polycarbonate), relay options (2 to 3 relays), and mounting types (surface or flush mount). Keypads are available with backlit keys and offer audible and visual feedback.
Power Requirements: The keypads operate on a free voltage range of 12V to 24V AC and 12V to 48V DC, with varying power consumption depending on the model.
Security Features: Many keypads are designed with high resistance to vandalism, featuring sealed electronics and protective coatings. Some models include Braille keys for accessibility.
Customization and User Codes: Users can program up to 100 or 500 user codes, depending on the model, allowing for personalized access control.
Environmental Resistance: The keypads are tested for environmental resilience, including resistance to salt spray and vibrations, and are certified for use in a wide temperature range.
Smart-Card Access Control Systems: The document introduces smart-card systems compatible with MIFARE® technology, offering solutions for single or multi-door access control.

Product Applications: The products are suitable for various applications, including public buildings, residential complexes, multi-tenant occupancy, industrial sites, and commercial properties.

Additional Features: Some keypads come with remote control options and are compatible with additional security accessories like exit push buttons and door loops.

Overview: The document provides detailed specifications and features of the smart-card access control systems, specifically the DGM1 and DGM4 controllers, designed for use in France. These systems are intended for public buildings, residential multi-tenant occupancy, industrial, and commercial applications.

Specifications:

DGM1 Controller: Manages 1 door with unlimited resident tags, supports up to 101 doors per site, and includes features like blacklist capacity and RS-232 connection. It is suitable for standalone operations and can be programmed using the PCV123 programmer.
DGM4 Controller: Manages up to 20 doors and 20,000 resident tags, supports anti-passback, and includes schedule management and access history functions. It can network up to 5 controllers and is compatible with the DGM1 via PCV123.

Mechanical and Electrical Properties:

Both controllers operate on 12V AC/DC input voltage with varying consumption levels (DGM1: 300mA, DGM4: 500mA).
The DGM1 has dimensions of 78 x 57 x 24mm, while the DGM4 measures 180 x 140 x 65mm.

Installation and Compatibility:

The systems are compatible with BTicino products and support various Mifare® tag brands.
Installation involves using standard cables and connections via RS232 or USB.

Additional Features:

Both systems offer wireless programming and the ability to erase and reprogram tags.
The DGM4 includes a 4-door management system with multiple relays and exit push button inputs.

Applications: These systems are designed to provide secure and reliable access control solutions for various types of buildings, ensuring ease of use and low maintenance.

Overview
CDVI offers a comprehensive range of locking systems designed to enhance site security, including strikes, electromagnetic locks, solenoid bolt locks, and motorized locks. These systems are suitable for various environments such as public buildings, residential areas, multi-tenant occupancies, industrial, and commercial sites.

Door Components and Systems
The document outlines the TELACCESS system, which is a telephone entry system suitable for different types of buildings. It includes core systems, supplementary modules, and door components, allowing for customization based on specific needs. The system supports up to 5 doors and 2 lifts, with a maximum of 56 floors.

Key Features of TELACCESS

Audio entry via telephone line with up to 1000 telephone numbers.
Smart-card access control and lift management capabilities.
Multi-language support and programmable features via PC or remotely.
High resistance to vandalism and CE certification.

Supplementary Modules
Various supplementary modules are available, including reader controllers, lift controllers, and bell modules. These modules enhance the functionality of the TELACCESS system by providing additional control and monitoring capabilities.

Wiegand Multi-Protocol Readers
The document details several Wiegand multi-protocol readers, including proximity readers and dual-technology readers. These readers are designed for high performance and are available in different styles and materials, such as stainless steel and polycarbonate.

Technical Specifications

Operating temperatures range from -30°C to +70°C, depending on the device.
Input voltage typically at 12V dc, with varying consumption rates.
Compliance with European R&TTE directive and applicable EMC standards.

Installation and Configuration
The document provides installation configurations for TELACCESS, detailing the connection of various modules and readers via standard cables and bus interfaces. It emphasizes the ease of mounting and the robust design of the components.

Specifications:
1. Digicode Keypad: Made of cast aluminium, completely sealed in epoxy, dimensions 110 x 75 x 15mm, input voltage 12V DC, max consumption 100mA. High resistance to vandalism, suitable for public buildings, residential, multi-tenant, industrial, and commercial use.
2. Mifare Reader: Stainless steel, 13.56 MHz, dimensions 97 x 76 x 20mm, input voltage 12V DC, consumption 100mA. Complies with European R&TTE directive and EMC standards. High resistance to vandalism.
3. Biometric Readers: Wiegand standalone fingerprint reader, dimensions 120 x 120 x 61mm, memorizes up to 400 fingerprints, input voltage 12V DC, consumption 300mA. Complies with European R&TTE directive and EMC standards.
4. Long-Range Reader: Adjustable range up to 15m, frequency 433.92 MHz, dimensions 90 x 60 x 22mm, input voltage 12-30V DC, consumption 40mA. CE and R&TTE certified.
5. Proximity Cards & Tags: Available in various materials (PVC, leather, metal, polycarbonate), dimensions vary, CE certified.

Procedures:
1. Installation: Surface or flush mount options available for various devices. Connection to panels via Wiegand bus interface.
2. Programming: Enrolment units available for cards, tags, and remote transmitters. USB connection for easy programming.

Standards and Certifications:
1. Complies with European R&TTE directive 99/5/EC and harmonised standards ETS 301 489 and ETS 300-330-1-Ed 2001.
2. Complies with applicable EMC standards: EN 50133, EN 50130-4.
3. CE certification and WEEE compliance.

Recommendations:
1. Use recommended power supplies for optimal performance.
2. Suitable for a wide range of applications including public buildings, residential, multi-tenant occupancy, industrial, and commercial settings.

Key Features:
1. High resistance to vandalism.
2. Completely sealed components for durability.
3. Audible and visual feedback for user interaction.
4. Various output options including 26, 30, or 44 bits Wiegand outputs.
5. Environmental resilience with operating temperatures ranging from -30°C to +70°C.

Specifications:
The TEL9000E and TEL9000 are audio entry systems with dimensions of 230 x 140 x 4mm and 200 x 120 x 40mm, respectively. The flush mount dimensions for TEL9000E are 210 x 120 x 50mm. These systems operate using voice frequency (DTMF) and require only one analogue line of the PABX. They support up to 100 access codes and are made of stainless steel, featuring two request-to-exit inputs and gate management capabilities with an additional MHPT. Programming is done via the keypad, and they allow direct calls to security via an exit push button. The input voltage is 12V AC or 18V DC with a consumption of 250mA.

Applications:
These systems are suitable for public buildings, residential multi-tenant occupancy, industrial, and commercial settings. They are designed to be highly resistant to vandalism and comply with WEEE standards.

Telephone Entry System:
The CIP12DR system can dial up to 12 different telephone numbers and is compatible with analogue or PABX lines. It features 3 relays and supports day and night telephone numbers per button. The system is programmable via a telephone set and operates in tone mode (DTMF). It includes options for standard panels with 1 to 12 buttons and a microphone speaker.

Door Automation:
The Digiway range offers door automation solutions for single and double doors, suitable for doors weighing up to 120kg. These systems feature programming via remote transmitter, LCD display, fire alarm input, and dynamic pause time adjustment. They operate with 230V AC or 16V AC and include a built-in battery for backup. The systems are adaptable for persons with reduced mobility and include various accessories for enhanced functionality.

Accessories:
CDVI provides a range of locking devices and accessories, including exit push buttons, sensors, and long-range readers. The BNONFCHOC domed exit button is designed for easy mounting and features a heavy-duty push button with LED feedback. The DTRR1434R long-range reader supports simultaneous reading of up to 20 tags and operates at a frequency of 433.92 MHz.

Overview: The document provides detailed specifications and descriptions of various RF and infrared devices, primarily focusing on door activation sensors and RF transmitters. It includes technical specifications, installation guidelines, and compatibility information for different environments such as public buildings, residential areas, multi-tenant occupancies, industrial, and commercial settings.

Specifications:

Key Switches and Cylinders: ENAPD 3 N/O output key switches and European semi-cylinder with adjustable key bit are described, suitable for Digiway systems with specific dimensions and chrome-plated finish.
Door Activation Sensors: Three models (DWD1000, DWHR10002, DWSSS1) are detailed with specifications on detection modes (microwave and infrared), installation heights, input voltage, and consumption rates. These sensors are designed for safety and activation during door operations.
RF Transmitters: Various models of 433 MHz RF transmitters are outlined, including their frequency, range, dimensions, modulation, encoding (Keeloq® rolling code), and power requirements. These are suitable for different applications, including sun-blinds and awnings.

Procedures and Installation:

Installation guidelines for door activation sensors and RF transmitters are provided, emphasizing maximum installation heights and input voltage requirements.
Details on the effective radiated power and modulation techniques (AM/ASK) are included to ensure optimal performance and compatibility.

Standards and Certifications:

All devices comply with CE certification and WEEE directives, ensuring adherence to European safety and environmental standards.
FCC CFR 47 Part 15 compliance is noted for RF devices, indicating conformity with US regulations.

Recommendations:

For optimal performance, it is recommended to adhere to the specified installation heights and input voltage ranges.
Consider environmental conditions such as temperature ranges (-20°C to +60°C) for device operation.

Accessories: The document lists complementary accessories such as IR detector sensors and various RF modules, highlighting their compatibility with the main devices.

Specifications:
The document outlines the specifications for various RF and infrared devices, including multi-user stand-alone RF controllers and receivers. Key specifications include:

Frequency: 433.92 MHz
Encoding: Keeloq® rolling code
Modulation: ASK
Input voltage: 12/24V AC/DC or 230V AC
Operating temperature range: -20°C to +80°C
CE Certification and WEEE compliance

Procedures:
The document describes the installation and configuration procedures for RF controllers and receivers. It includes details on self-learning memorization, sequential mode activation, and adjustable time outputs for relays.

Norms and Standards:
The devices comply with FCC CFR 47 Part 15, CE Certification, and WEEE standards, ensuring they meet regulatory requirements for safety and environmental impact.

Recommendations:
Recommendations include using the appropriate power supply for each device, ensuring compatibility with ERONE® transmitters, and optimizing system configurations with CDVI RF accessories.

Key Features:
The document highlights features such as:

Multi-user capability, supporting up to 800 users
Bidirectional communication for certain models
Compact design with various housing options
Adjustable relay output times ranging from 1 second to 10 hours

Applications:
The devices are suitable for various applications, including public buildings, residential multi-tenant occupancy, industrial, and commercial settings. They are ideal for controlling access in car parks, garages, and other secure areas.

Overview: The document provides detailed specifications and descriptions of various RF systems and accessories, primarily operating at a frequency of 433 MHz. These systems are designed for applications in public buildings, residential, multi-tenant, industrial, and commercial settings. Key components include RF receivers, transmitters, aerials, and infrared photocells, all utilizing Keeloq® rolling code technology for secure communication.

Specifications:

Frequency: 433 MHz, with some systems operating at 433.92 MHz.
Encoding: Keeloq® rolling code.
Modulation: AM/ASK.
Input Voltage: Varies by model, including 12/24V AC/DC and 230V AC - 50 Hz.
Memory Capacity: Up to 255 transmitter buttons, depending on the model.
Protection Rating: IP44 to IP65, ensuring durability in various environments.

Key Products:

RF Receivers: Available in configurations with 1, 2, or 4 relays, suitable for different power supplies and applications.
RF Transmitters: DIN rail mountable, with a range of up to 400 meters in open fields.
RF Aerials: Designed for wall mounting with L-brackets, available in various cable lengths.
Infrared Photocells: Offered in flat, adjustable, and vandal-resistant models, with a range of up to 20 meters.

Applications: The systems are ideal for controlling lighting, sun-blinds, shutters, roller shutters, and other automation tasks. They are compatible with ERONE® transmitters and can be used in various occupancy types, including residential and commercial buildings.

Certifications: Products are CE certified and comply with WEEE and R&TTE standards, ensuring safety and environmental compliance.

Recommendations: The document suggests using recommended power supplies and accessories to optimize the installation and performance of the RF systems. It also highlights the importance of selecting the appropriate model based on specific environmental and operational requirements.

Overview: The document provides detailed specifications and descriptions of various infrared photocells and electromagnetic locking devices, suitable for different environments such as public buildings, residential areas, and industrial settings. It includes product codes, descriptions, and technical specifications.

Infrared Photocells: The document outlines several models of infrared photocells, including flat, adjustable, and mini-cells. Key features include compliance with UNI8612 and EN12978 standards, varying detection ranges (5m to 20m), and environmental resilience (IP55 rating, operational temperatures from -25°C to +70°C). The photocells are made of polycarbonate and have adjustable optics for alignment.

Electromagnetic Locks: A comprehensive list of electromagnetic locks is provided, categorized by type (surface mount, mortice, shearlock, etc.) and capacity (ranging from 180 kg to 1500 kg). Each lock type includes specifications such as monitored options, input voltage requirements, and additional features like integrated protection and position switches.

Accessories: The document lists various accessories to complement the installation of photocells and locks, including mounting brackets, armature housings, and extension leads. These accessories are designed to enhance the functionality and ease of installation of the primary devices.

Technical Specifications: Detailed technical specifications are provided for each product, including dimensions, input voltage, and power consumption. The document also includes a comparison table for strikes and locks, highlighting features like fail-secure/fail-safe options, material composition, and compatibility with faceplates.

Compliance and Certification: All products are CE certified and comply with WEEE regulations, ensuring they meet European safety and environmental standards.

Overview: The document provides detailed specifications and descriptions of various electric strikes and accessories suitable for different types of buildings, including public, residential, multi-tenant, industrial, and commercial spaces. The focus is on fail-secure and fail-safe mechanisms, with emphasis on electronic protection and CE certification.

Specifications:

Electric strikes are available in stainless steel, cast steel, bronze, and aluminum, with symmetrical and non-symmetrical options.
Input voltage is primarily 12V AC/DC, with some models supporting 24V AC/DC.
Consumption varies between fail-secure and fail-safe modes, with specific mA ratings provided for each.
Holding force ranges from 500 kg to 875 kg, depending on the model.
Dimensions and mounting options (surface or mortice) are specified for each strike type.

Procedures and Recommendations:

Installation involves using faceplates and strikes that are reversible and can be mounted horizontally or vertically.
Electronic protection is provided by built-in varistors to eliminate back EMF.
Recommended power supplies are specified, and users are advised to refer to the Limited Lifetime Warranty Conditions.

Standards and Certifications:

All products are CE certified, ensuring compliance with European safety standards.
WEEE compliance is noted, indicating adherence to waste electrical and electronic equipment regulations.

Accessories:

Microswitch keeps, adjustable timers, and metal casings are available for enhanced functionality and integration with panic push bars.
Accessories are designed to work with specific strike models and are also CE certified.

Key Features:

Reversible design for flexibility in installation.
Fail-secure and fail-safe options to suit different security needs.
High resistance to force, ensuring robust security.
Variety of materials and finishes to match aesthetic and functional requirements.

Overview: The document provides detailed specifications and descriptions of various electromagnetic locks, including surface mount, mortice, and shear locks. These locks are designed for different applications such as public buildings, residential, multi-tenant occupancy, industrial, and commercial use. The locks are characterized by their holding force, resistance to corrosion, and fail-safe operation.

Specifications:

Surface Mount Electromagnetic Locks: Available in 300kg, 400kg, and 500kg holding forces. They include models with and without monitoring and buzzer features. Dimensions vary by model, with input voltage options of 12/24V DC and consumption rates of 550mA at 12V and 275mA at 24V.
Double Electromagnetic Locks: These locks offer holding forces of 2 x 300kg or 2 x 500kg. They are surface mounted and include monitored versions. Dimensions and consumption rates are specified for each model.
Narrow Surface Mount Electromagnetic Locks: Designed for high resistance to vandalism with a holding force of 180kg. They are monitored and recommended for indoor use.
Mortice Electromagnetic Locks: Available in 300kg, 400kg, and 500kg holding forces. These locks are monitored and include models for both indoor and outdoor use. They feature high resistance to corrosion and easy installation.
Electromagnetic Locks Without Casing: Designed for integration markets with holding forces of 300kg, 400kg, and 500kg. They are mortice locks with no mechanical wear and easy installation.
Electromagnetic Shear Locks: Feature a shearing force of 800kg with a patented self-aligning mechanism. They are ideal for narrow aluminum profiles and include monitored versions.

Key Features:

High resistance to corrosion and vandalism.
Fail-safe operation ensuring doors unlock when power is cut.
No residual magnetism and built-in varistor for electronic protection.
Easy installation with no mechanical wear.
CE Certification and compliance with NF S 61-937 standards.

Recommendations: The document recommends using these electromagnetic locks for various building types, ensuring the appropriate model is selected based on the required holding force and installation environment. Optional accessories are available for enhanced functionality.

Overview: The document provides detailed specifications and options for various retrofit housings and handles designed for different types of buildings, including public, residential, industrial, and commercial spaces. It emphasizes quick installation, high resistance to vandalism, and compatibility with different door materials.

Specifications:

Retrofit housings and handles are available in various sizes and holding forces, such as 2x400kg and 1x300kg.
Electromagnetic locks are available with different voltage options (12/24/48V DC) and consumption rates.
Materials include satin-finished silver anodized aluminum and stainless steel.
Options for RAL color customization and glass door installation are available.

Procedures:

Installation is described as ultra-quick with pre-drilled and pre-assembled sections.
Handles and housings are designed for easy installation on metal, wood, and glass doors.

Standards and Certifications:

Products comply with NF S 61-937 standards.
CE certification and WEEE compliance are noted.

Recommendations:

Recommended power supplies are specified for different voltage requirements.
Options for additional accessories like reinforcement sections, aluminum cable trays, and U-brackets for glass doors are provided to optimize installations.

Key Features:

High resistance to vandalism and robust construction.
Monitored NO/NC options and built-in varistors for electronic protection.
Self-aligning magnetic shearlock with illuminated exit push button available.

Comparison Table:

Includes a comparison of solenoid bolt locks and motorized locks, detailing dimensions, electrical properties, and features like fail-safe and fail-secure options.

Overview: The document provides detailed specifications and descriptions of various solenoid bolt locks, motorized locks, and interlock controllers, suitable for different applications such as public buildings, residential, multi-tenant occupancy, industrial, and commercial settings. It includes information on power supplies and transformers required for these devices.

Solenoid Bolt Locks:

Available in fail-secure and fail-safe models with backsets ranging from 22mm to 60mm.
Features include stainless steel construction, intelligent electronics, built-in interlocking controller function, deadlocking, and a patented self-locking mechanism.
Equipped with optical sensors for latch position monitoring and optional surface mount housing.
Input voltage options include 12V dc and 24V dc, with varying consumption rates depending on the model.

Motorized Locks:

Constructed from treated steel, these locks are motorized and fail-secure, suitable for gates or cellar doors.
Features include quiet operation, robust design, and compatibility with various access control devices.
Available in different configurations such as cylinder only, cylinder with knob, and double cylinders.
Input voltage is 12V dc with low consumption rates.

Interlock Controllers:

The SASIC controller manages two interlock doors and can connect to up to four console panel units or virtual consoles.
Features include visual feedback, call button, and optional RF receiver module for remote control.
Two operating modes are available: with or without closing, allowing for different security configurations.
Input voltage options include 230V ac and 110V ac, with a maximum consumption of 80W.

Power Supplies and Transformers:

Various models of linear and switching power supplies are detailed, with specifications for input and output voltages, regulated and rectified/filtered voltage, and nominal intensity.
Transformers are available for 12/24V ac applications.

Certifications and Standards:

All products are CE certified and comply with WEEE regulations.
High resistance to vandalism is a key feature across the product range.

Specifications:
1. Each door must have an electromagnetic locking device compliant with current standards.
2. Doors can be controlled manually via a break-glass box or by an emergency-exit control device as per NF S 61-937 standards.

Product Certifications:
NF S 61-937 certification numbers include KIS300NE, KIS300NA, and KIS500NA.

Product Range:
- Electromagnetic locks, retrofit housings, handles, and solenoid bolt locks are available.
- Kits include electromagnetic locks with break-glass boxes and fire relay controls.

Electromagnetic Locks:
- Available in 300-kg and 500-kg holding force.
- Surface mount and mortice options.
- Fail-safe operation, releasing access during power failure.
- Integrated electronic protections to eliminate back EMF.
- CE certified and WEEE compliant.

Solenoid Bolt Locks:
- 48V DC emergency exit solenoid bolt locks with 500kg force.
- Fail-safe and robust design, suitable for single or double doors.
- Monitored with optional surface mount housing.

Firedoor Systems:
- Electromagnetic locks for fire-rated doors with fail-safe operation.
- Holding force ranges from 20kg to 50kg.
- Integrated electronic protections and silent operation.

Accessories:
- A variety of accessories including emergency door release units, brackets, and armature plates.
- Adjustable stands for electromagnetic locks.
- Exit push buttons available in various materials and designs, compliant with accessibility regulations.

Environmental and Safety Standards:
- Products are tested for high resistance to vandalism and environmental conditions.
- CE certification and compliance with WEEE regulations ensure safety and environmental responsibility.

Overview: The document provides detailed specifications and descriptions of various exit push buttons, panels, housings, door loops, key switches, and accessories used in public, residential, industrial, and commercial buildings. It emphasizes high resistance to vandalism, environmental certifications, and a wide choice of accessories to optimize site installations.

Specifications: The document lists multiple product codes with their corresponding descriptions, such as illuminated and non-illuminated exit push buttons, pre-wired options, and stainless steel plates. It specifies power requirements, dimensions, and mounting options for each product.

Procedures and Standards: Products are certified with CE and WEEE, ensuring compliance with environmental and safety standards. The document highlights the IP ratings for environmental resistance and temperature ranges for operational reliability.

Recommendations: The document suggests using specific products for different applications, such as public buildings, residential multi-tenant occupancy, industrial, and commercial settings. It also recommends power supplies and accessories to enhance functionality and security.

Key Features: High resistance to vandalism, customizable options, and a variety of finishes and materials (e.g., stainless steel, aluminium, gold-finish) are emphasized. The document also notes the availability of infrared and hands-free exit buttons, as well as energy-saving solutions for hotel applications.

Accessories: A wide range of accessories is available, including door loops, power transfer hinges, and customizable posts for pedestrians and vehicles. The document provides dimensions and installation options for these accessories.

Overview: This document is a comprehensive catalog of RF receivers, controllers, and related accessories, primarily operating at 433 MHz frequency. It includes a variety of products designed for different applications such as public buildings, residential, industrial, and commercial settings.

Key Sections:

RF Receivers and Controllers: The catalog lists multiple RF receivers and controllers, each with specific features such as the number of relays, user capacity, and power specifications. For example, the SEL2641R433IP is a 433 MHz RF receiver with 2 relays and supports up to 85 users.
RF Systems for Roller Shutters: Products like SEL2641R433P4 and SEL2641R433P7 are designed for roller shutters, offering different power capacities (400W and 750W respectively) and features like remote memorization.
Electromagnetic Locks: A range of electromagnetic locks is detailed, varying in holding force from 180 KG to 500 KG, with options for surface or mortice mounting, and additional features like monitoring and relay integration.
Proximity Readers and Keypads: The document includes various proximity readers and keypads, such as the SOLARKPB, which is a dual-technology reader operating at 125 KHz.
Accessories and Mounting Hardware: Includes items like door coordinators, stainless steel posts, and brackets for electromagnetic locks, providing solutions for different installation needs.

Critical Information:

Specifications: Each product entry includes detailed specifications such as voltage requirements, relay count, and user capacity.
Applications: Products are categorized based on their suitability for different environments, including public buildings and industrial settings.
Warranty: The document references limited lifetime warranty conditions applicable to the products listed.

Contact Information: For sales and special requests, contact details for key personnel such as the Operations Manager and Regional Sales Manager are provided.

Catalog excerpts

CDVI Group EN Edition 49 Catalogue cdvi.co.uk Manufacturing Access Control since 1985 * Refer to Limited Lifetime Warranty conditions. cdvigroup.com Manufacturing Access Control since 1985 CDVI Group Products

Open the catalog to page 1

cdvigroup.com 3 BIOMETRIC READERS DIGICODE® KEYPADS SMART-CARD ACCESS CONTROL TELEPHONE ENTRY SYSTEMS RADIO DEVICES & INFRARED CELLS LOCKING DEVICES DOOR AUTOMATION POWER SUPPLIES - TRANSFORMERS FIRE SYSTEMS ACCESSORIES INDEX / ON DEMAND PRODUCTS GENERAL INFORMATION STAND-ALONE ACCESS CONTROL ONLINE ACCESS CONTROL CONTENTS Public Buildings Multi-tenant Residential occupancy Commercial Industrial * Refer to Limited Lifetime Warranty Conditions. P. 98 P. 110 P. 124 P. 132 P. 176 P. 212 P. 166 P. 268 P. 280 P. 290 P. 302 P. 4 P. 68 P. 11

Open the catalog to page 3

4 cdvigroup.com DURATION OF THE OFFER: - This offer is valid from July 1st 2010; CDVI reserves the right to terminate this offer without prior notice. - However, any product already registered up to the date of withdrawal of the offer will remain eligible for the “Limited Lifetime Warranty”. - The warranty applies only to the available products mentioned in the above statement. CONDITIONS: - Hidden defects are guaranteed for an unlimited shelf life (period of time before use). - To be eligible for the “limited lifetime warranty”, the product must be registered at CDVI within one month of its...

Open the catalog to page 4

6 cdvigroup.com This new edition of the CDVI product catalogue has been designed to help you easily understand the products and to assist your choice of the system or product that best meets your needs. A] CHAPTERS: Every chapter is marked with specifi c colours. In the table of contents (Page 3), you will fi nd the chapters and the colour assigned to them to help you fi nd your way around the catalogue. B] THE COMPARISON TABLE: In some chapters you will fi nd a table that summarises all the features of the range to help you select the product you need. C] INSTALLATION EXAMPLES In the preamble...

Open the catalog to page 6

cdvigroup.com 7 HOW TO CONSULT THIS CATALOGUE (CONTINUED) Public Buildings Multi-tenant Residential occupancy Commercial Industrial D] PICTOGRAMS 1 - RELATED TO THE PRODUCT OR SYSTEM ENVIRONMENTS CDVI products are classifi ed according to 5 target environments which are representative of the access control and locking devices market. These pictograms have been placed in the top-left section of the double pages (see below). Public Buildings Multi-tenant Residential occupancy Commercial Industrial Commercial: Administration offi ces, sales offi ces, educational establishments and holiday camps,...

Open the catalog to page 7

8 cdvigroup.com 2 - RELATING TO STANDARDS CE CERTIFICATION 1] Electromagnetic compatibility (Directive 89/336/EC, amended by directives 92/31/EC and 93/68/EC or 2004/108/EC**) Applicable standards: - Product standards: EN 50130-4, EN 50130-5, EN 50133. - Generic standards: EN 61000-6-1,2; EN 61000-6-3,4. - Essential standards: EN 61000-4-2,3,4,5,11 EN 61000-3-2,3. 2] Low-voltage protection and safety (Directive 2006/95/EC) Applicable standards: - Low-voltage safety standards: EN 60950 + applicable amendments. - Standard for exposure to electromagnetic fields: EN 50357. R&TTE CERTIFICATION French...

Open the catalog to page 8

cdvigroup.com 9 I GENERAL INFORMATION GENERAL INFORMATION 3 - PICTOGRAM SHOWING THAT THE PRODUCT HAS HIGH RESISTANCE TO VANDALISM In this catalogue you will fi nd products marked HRV (High resistance to vandalism). This pictogram is applied to products that have a high degree of protection (IK). This degree of protection defi nes the product’s resistance to external mechanical impacts (with the energy required to damage the product). All our products have been subjected to specifi c impact tests (see enclosed chart) in order to defi ne their degree of protection against vandalism: IK code IK01...

Open the catalog to page 9

12 cdvigroup.com COMPARISON TABLE ONLINE SYSTEMS Yes (Free Starter pack) - Yes 64 Yes Yes Multi-language 2048 (max. 131,072) 512 64 128 2048 per controller local or remote Yes Yes Yes - 16000 (max. 1000000) Yes Yes Yes - Yes Yes Yes Yes Yes Yes Yes Yes Yes SQL Yes - - Yes CAA360USBRS Yes CAETHRA Page 14 CENTAUR POWER General features Software Web browsers Anti-passback Number of sites Bank holiday management Interlocking controller function Languages Numbers of doors (per site) Lift management Floors per cab Floor groups Number of events Site management Graphic interface Report generator Time...

Open the catalog to page 12

cdvigroup.com 13 ONLINE ACCESS CONTROL ONLINE ACCESS CONTROL Integrated Yes (Free software) Yes - Yes Yes 1 1 Yes - - - Multi-language Consult us 128 4 (max. 20) Yes - 56 - - - 16000 3000 local or internet local Yes Yes - - - - - - Up to 17000 20000 - - Yes Yes - - Yes - Yes Yes Yes - - - - - - - - - Yes - - - - - SD card or USB key PC Yes Yes Yes - Yes - - Yes Yes - - - - - ONLINE ACCESS CONTROL Page 42 Page 64 TERENA DGM4D WEB INNOVATION * Refer to Limited Lifetime Warranty Conditions. Public Buildings Multi-tenant Residential Occupancy Commercial Industrial

Open the catalog to page 13

14 cdvigroup.com I II III III III FREE STARTER PACK TCP/IP connection. Powerful SQL database. Lift control. Visitor management. Alarm management. Customisable alert management. DVR and IP camera integration. Real-time graphic interface. Local or remote site control. Time & Attendance data acquisition. Supplementary modules to optimise your system. Customisation of events and reports. Parking management. Guard tour management. Counter. SAP Integration. ONLINE ACCESS CONTROL UP TO 2048 DOORS PER SITE (MAX. 131072 DOORS) Public Buildings Example: POWER ONLINE ACCESS CONTROL

Open the catalog to page 14

cdvigroup.com 15 I II III CREATE YOUR SYSTEM TO ORDER IN 3 STEPS ONLINE ACCESS CONTROL CORE SYSTEM Controller The CTV900A controller is the core of the CENTAUR access control system. Software The CENTAUR system has powerful software (Lite, Standard, Professional and Enterprise) to suit your budget and the confi guration of your site. SUPPLEMENTARY MODULES Readers CDVI has a complete range of Multitechnologies® readers (proximity, RF, Mifare® and biometric). Power supplies CDVI provides power supplies that are suitable for all types of confi gurations. Tags, cards and remote transmitters CDVI...

Open the catalog to page 15
