HERITAGE A TRADITION OF INDUSTRY FIRSTS CRAWLER EXCAVATORS E-NHANCED GENERATION ENHANCED QUALITY AND RELIABILITY Stronger than ever, built to last + The reinforced clamp improves the pipe holding force on the boom. + The shape and thickness of the inner reinforcement plate increase the boom’s durability. + The tolerance of the boom and arm cylinder pins has been updated to reduce clatter and play within the bushing. + A new stop valve adjustment mechanism has been added for easier piping-valve connection. + The more compact assembly of the undercarriage recoil spring on the CX130E, also including...

E-SERIES CRAWLER EXCAVATORS ENHANCED VERSATILITY A high degree of customization for every task The new-concept work modes with independent throttle position offer a precise match to the requirements of every task: SP (Super Power) mode for maximum productivity (as in D-Series) with the throttle set at maximum power. P (Power) mode replaces H and A mode in D-Series, with throttle settings from 1 to 10. E (Eco) mode for maximum fuel economy, with throttle settings from 1 to 10. L (Lifting) mode is optimized for object handling with power boost permanently activated and overload warning system,...

PRODUCTIVITY WORK SMART, PRODUCE MORE ENHANCED EFFICIENCY Top performance, high fuel economy CLEANER POWER EU Stage V compliant engines The new-generation E-Series combines the proven energy saving features of the D-Series with new work modes and hydraulic settings to raise the bar on efficiency. The new FPT NEF engines meet Stage V standards with the innovative HI-eSCR2 solution developed in-house, which only uses a Diesel Oxydation Catalyst and an integrated maintenance-free device on the SCR catalyst to achieve this dramatic reduction in emissions. + The SCR-on-Filter is “built-for-life” and...

COMFORT RULES FIRST-CLASS WORK ENVIRONMENT ENHANCED COMFORT Ideal working conditions, every day SAFETY AND MAINTENANCE WORK SAFELY IN ALL CONDITIONS SAFER OPERATION AND ACCESSIBILITY Safety first, inside and outside the cab SUPERIOR VISIBILITY Designed for outstanding visibility + Reinforced cab structure ROPS and FOPS compliant. + Standard FOPS level 2 head protection. + Factory fitted front guard OPG 1 and 2; grill guard available as DIA kit. + Factory fitted travel alarm for greater safety on the jobsite around the machine. + New auto lever lock safety feature immediately stops machine movement...

SAFETY AND MAINTENANCE WORK SAFELY IN ALL CONDITIONS EASY MAINTENANCE “Grounded” and connected services solution + Fuel nozzle with integrated fuel tank float provides better visibility during refilling. + Air cleaner height change for easier put on and off. - Engine oil, fuel & oil filters extended from 500 to 1,000 hours; + Hydraulic oil tank cap with integrated air breather for tool-less refill. + Fan belt auto-tensioner requires no manual calibration. - AdBlue supply module filter was 3,000 hours, it goes up to 4,000 hours; + Newly added sampling valve in pump room for easier hydraulic oil...

MAIN REASONS TO CHOOSE THE NEW E-SERIES BEST MATCH BETWEEN SPEED AND CONTROLLABILITY CASE Intelligent Hydraulics System (CIHS) is synonymous and reference in the market for its fastest cycles times, best energy saving performance and smooth control. ENHANCED QUALITY AND RELIABILITY CASE excavators are known for their balanced design and first-class components. New improvements to arm, boom and undercarriage structure make them even better. SUPERIOR VISIBILITY ENHANCED COMFORT EASY MAINTENANCE + NEW 10” LCD monitor – the biggest in the industry – with 5 configurable buttons and new menu functions...

AFTERSALES PRODUCTS AND SERVICES AFTERSALES PRODUCTS Keep your equipment performing at its best and protect your investment’s value with the extensive offering of high-quality CASE Parts. Optimize your performance and add value to your machine with high-quality genuine parts. Ensure your machine’s performance beyond warranty and manage your budget with CASE’s quality secondline range of parts. Add versatility to performance with CASE attachments designed for CASE machines and tested by CASE engineers. Choose sustainable quality with remanufactured parts designed for CASE equipment of all ages....

STANDARD AND OPTIONS STANDARD EQUIPMENT ENGINE + FPT NEF4 (F4HGE413A*V) -cylinder turbocharged diesel (CX130E) + FPT NEF4 (F4HGE413B*V) -cylinder turbocharged diesel (CX160E / CX180E) + Stage V + Selective Catalytic Reduction on Filter (SCRoF) + Diesel Oxidation Catalyst (DOC) + EGR-free + VGT turbocharger + Electronic fuel injection + High pressure common rail system + Neutral safety start + Auto engine warm up, emergency stop + Glow-plug pre-heat + EPF (Engine Protection Feature) + Dual-stage fuel filtration + Dual element air filter + Remote oil filter + Green plug oil drain + 1,000 hour engine...

HYDRAULIC SYSTEM Main pumps_ _2 variable displacement axial piston pumps with regulating system _2 x 129 at 2000 min-1 Working circuit pressure (MPa) _ Blade pump (CX130E Blade) _ Max. oil flow (l/min)_ Working circuit pressure (MPa) _ Boom cylinders Type_Water-cooled, 4-cycle diesel, 4-cylinder in line, High pressure common rail system (electric control), turbocharger with air cooled intercooler, SCRoF, EGR free. Number of cylinders / Displacement (l)_4 / 4.5 Rated flywheel horse power Working circuit pressure Boom/Arm/Bucket (MPa)_34.3 - 36.3 with auto power boost Pilot pump_1 gear pump Bucket...

FronttJide REACH GENERAL DIMENSIONS Arm 5.30 m A Overall length (without attachment) A1 Overall length (with attachment) B Overall height (to top of boom) D Overall height (to top of handrail) E Upper structure overall width F Swing (rear end radius) G Clearance height under upper structure H Minimum ground clearance I Wheel base (center to center of wheels) L Crawler overall length M Crawler tracks height J Track gauge K Undercarriage overall width (with 700 mm shoes) PERFORMANCE DATA Arm 5.30 m Boom length mm 7400 Bucket wrist action 180° DIGGING FORCE (ISO 6015) Arm 5.30 m Arm digging force...
