Canaletas drinking fountains Series 6

Product catalog summary

Overview: The Source of Life Series 6 drinking fountains are designed for high durability, hygiene, and versatility. Made entirely of stainless steel, these fountains are robust, vandal-proof, and recyclable. They are suitable for various applications and are a leader in sales.

Specifications: The fountains offer a cooling power of 400W and consume 200W of power. They operate on a 230V 50Hz single-phase voltage. The continuous cooling capacity is 35 liters per hour, with a water output speed of 60 liters per hour. The water tank capacity is 4.5 liters, and the cold water output temperature is adjustable between 4-11ºC. The refrigerant gas used is R290, which is CFC-free and environmentally friendly.

Design Features: The fountains feature a patented bubbler designed for maximum hygiene, with an inclined nozzle base to prevent stagnant water. The water jet height is adjustable via a high precision membrane valve, and the push button is separate from the water jet for greater hygiene. Models with cup/bottle fillers (LV models) allow for drinking with cups or small bottles.

Models and Options: Various models are available, including those with wheelchair accessibility (M-6APULVMV) and hands-free operation (M-6ALVPE). The fountains offer three water temperature options: cold (pedal), room temperature (push button), and mixed (pedal + button). Optional features include carbon block, sediment, UV, or RO water filters.

Compliance and Warranty: The fountains comply with the ADA (Americans with Disabilities Act) and Institut Guttmann standards. They come with a warranty, ensuring durability and economical use.

Installation: Installation drawings are provided, with dimensions for models with LV being 1030 x 360 x 360 mm. The fountains are equipped with a mechanical thermostat, waste water outlet, and water inlet.

Catalog excerpts

Drinking fountains PEDAL VALVE MECHANICAL THERMOSTAT MECHANICAL THERMOSTAT Oﬀer the most durability, robustness and economical use WATER INLET JG 8mm" WASTE WATER Ø28mm CURRENT ENTRANCE Superior quality, made entirely of stainless steel, a 100% recyclable and highly durable material. Installation drawings Series 6 High quality drinking fountains with many application possibilities. Leader in sales. Technical data Larger dimensions, together with a robust internal chassis, provide excellent stability and durability. High hygienic protection Voltage 230V 50Hz single-phase (A) (Other options available)...

Open the catalog to page 2

98/83/EC HEADQUARTERS AND FACTORY Ronda de Llevant, 10 08820 El Prat de Llobregat Barcelona (Spain) www.canaletas.com www.canaletas.es i nfox@ca na letas.es reserves the right to make changes considered opportune to the Information contained In the catalogue without prior notice, with the aim to Improve Its products.
