Product catalog summary

Washbasins
This section describes various washbasin designs primarily made from Cristalplant® and Corian®. Key models include:

A45: Versatile, available as top-mounted or suspended, with optional drain-hole covering in Cristalplant® or solid wood.
B15: Monoblock unit with a marble top and integrated basin.
BOX: Wall-mounted with an anodized aluminum structure and Cristalplant® basin.
ICELAND: Available in all white or with an anthracite grey paint coating.
I FIUMI Series: Includes models like ADIGE and PIAVE, crafted from solid natural stone or Corian®.

Bathtubs, Sanitary Fixtures, and Showers
This section covers a range of bathtubs and sanitary fixtures, emphasizing materials like Cristalplant® and Corian®. Notable products include:

GOBI SMALL: Monoblock bathtub in Cristalplant®, available in white or with an anthracite grey coating.
I FIUMI: PO: Made from solid natural stone or thermoformed Corian®.
SABBIA: Monoblock bathtub in Cristalplant®.
SWIM C: Features a double backrest slope, entirely in white Cristalplant®.

Technical Drawings
This section likely includes detailed technical drawings for the products listed, providing specifications for installation and design.

Specifications

Toilet Bowls: Various models with dimensions L. 380, P. 660, H. 420 mm, and L. 380, P. 510, H. 420 mm, featuring ceramic cisterns with double-flow drainage mechanisms and soft-closing toilet seats.
Bidets: Suspended bidets with a single tap hole, dimensions L. 380, P. 510, H. 300 mm, and weight 17 kg.
Shower Trays: Made of matt white Ceramilux®, available in fixed sizes or customizable dimensions, with anti-drop treated glass shower boxes.
Shower Heads: Ø 300 mm, with satinised plexiglass diffuser, silicone nozzles, and RGB LED lighting options.

Procedures

Installation: Products are designed for both floor and wall drainage, with specific models for recessed wall installation.
Assembly: Components such as mixers and diverters are available for horizontal or vertical assembly.

Standards and Recommendations

Materials: Use of high-quality materials like stainless steel AISI 304 for mixers, ensuring durability and adjustable temperature control.
Design: Products are designed for easy installation and maintenance, with features like soft-closing mechanisms and anti-drop treatments.

Key Data from Tables and Diagrams

Dimensions: Detailed measurements for each product type are provided, ensuring compatibility with various installation settings.
Configurations: Multiple configurations are available for shower trays and boxes, allowing for customization based on client needs.

Critical Information

Requirements: Ensure correct installation of water connections, with specified dimensions and orientations for hot and cold water.
Limitations: Weight and size constraints are specified for each product to ensure proper support and functionality.
Best Practices: Follow installation guidelines to maintain product integrity and performance, particularly for recessed and suspended installations.

Specifications

Wall-Connection for Shower Plate: Model RRDM01 features a 1/2” wall connection suitable for various shower setups.
Thermostatic Bath/Shower Mixer Tap: Wall-mounted, built-in with dimensions of 130 mm width and 160 mm height. Available without a diverter, with recessed part RHDM01I and external part RHDM01E. Compatible with diverter kit RVDM01.
Single Spout for Washbasin: Available in three heights (260 mm, 110 mm, 355 mm) with a 500 mm hose and 3/8 - 1/2” connection.
Ceiling Connection for Shower Head: 1/2” connection with extension and water connection options RRDM02 and RRDM11.
Floor-Mounted Bathtub Unit: Includes mixer, spout, diverter, and hand-shower, model RESL17.
Deck-Mounted Bathtub Group: Features 3/4” screw disks for cold/hot water, high water supply, and hand-shower controlled by a mixer, model RGDM10.
Wall-Mounted Spout for Washbasins: 1/2” connection, Ø 20 mm, with lengths of 250 mm (RIDM06) and 210 mm (RIDM07).

Procedures

Installation: Ensure compatibility of parts and follow manufacturer guidelines for installation of wall-mounted and floor-mounted units.
Maintenance: Regularly check connections and seals to prevent leaks and ensure optimal performance.

Standards

Material: Taps are made from satin stainless steel AISI 304, ensuring durability and resistance to corrosion.

Recommendations

Compatibility: Verify compatibility of diverter kits and spouts with respective models to ensure proper functionality.
Customization: Choose finishes and dimensions that best suit the design and functional requirements of the bathroom space.

Overview
This document provides detailed specifications and descriptions of various plumbing fixtures, including mixers, spouts, and showers, primarily made from satin stainless steel AISI 304. The document is structured into sections based on the type of fixture and its intended use.

Specifications

Floor-Mounted Fixtures: Includes fixed floor showers with progressive ceramic cartridge mixers and floor-mounted spouts for washbasins and bathtubs. Key models include RFFP03 and RFFP02, with 1/2” floor connections for hot/cold water.
Wall-Mounted Fixtures: Features fixed wall-mounted showers and wall-mounted spouts for washbasins and bathtubs. Notable models are RFFP01 and RIFP03/04, with 1/2” wall connections.
Top-Mounted Fixtures: Includes mixers and spouts for washbasins and bidets, such as REFP01 and RIFP07, with various height specifications and connection sizes.
Built-In Fixtures: Describes built-in mixers and diverters for washbasins, showers, and bathtubs, including models like REFP02 and RGFA03I/E, with ceramic screw disks and 90° opening mechanisms.

Materials and Finish
All fixtures are made from satin stainless steel AISI 304, ensuring durability and a sleek finish.

Key Features

Progressive ceramic cartridge mixers for precise temperature control.
Various mounting options including floor, wall, and top-mounted configurations.
Revolving spouts and lockable swivel aerators for enhanced functionality.
Compatibility with specific codes for seamless integration with existing plumbing systems.

Recommendations
The document suggests matching specific components with designated codes to ensure compatibility and optimal performance. It also highlights the importance of selecting the appropriate fixture based on installation type and water supply requirements.

Specifications
Taps are made from stainless steel AISI 304, available in satinised or polished finishes. The product range includes built-in groups for washbasins, showers, and bidets, as well as floor-mounted and countertop-mounted spouts.

Procedures
Installation requires matching with specific recessed wall containers and spouts, which must be ordered separately. The built-in groups come with hot and cold levers, and some models include a hand shower with a dedicated mixer.

Norms and Recommendations
Ensure compatibility with the correct codes for recessed wall containers and spouts. The finishes available are satin (RHNS03, RHNS05, RHNS07, RHNS09, RHNS13) and polished (RHNS04, RHNS06, RHNS08, RHNS10, RHNS14).

Key Features
- Built-in groups for various applications (washbasin, bidet, shower, bathtub).
- Floor-mounted spouts for washbasins and bathtubs.
- Countertop-mounted spouts for washbasins and bidets.
- Ceiling showers with one or two shower heads.
- Deck-mounted groups with hand showers and mixers.

Critical Information
- Ensure all components are ordered separately as needed.
- Follow installation guidelines for recessed wall containers and spouts.
- Choose the appropriate finish to match the design requirements.

Specifications

Storage Tray: Dimensions are 300 mm width, 40 mm height, and 120 mm depth. Model: KERGG01.
Wall-mounted Cabinet: Features 3 compartments with dimensions of 560 mm width, 325 mm height, and 195 mm depth. Model: KNYBX01.
Floor-mounted Cabinet: Contains 3 compartments, measuring 292 mm width, 800 mm height, and 370 mm depth. Model: KNYBY01.
Towel Rail: Available in two sizes: 500 x 90 x 40 mm (KERSV01) and 600 x 90 x 40 mm (KERSV02).
Shelf: Measures 600 mm width, 40 mm height, and 120 mm depth. Model: KERME01.

Complementary Items

Ceiling Fan: Available with wood or black varnished blades, diameter 1600 mm, Vortice engine, without infrared remote. Operates at 220-240 V, 50 Hz, with AISI 304 stainless steel finish. Models: GRCB07, GRCB08, GRCB09. Compliance with EU 61/28 requires the lower part of the blade to be at least 2300 mm above the floor.
Ceiling Fan with Remote: Features black or white matt painted blades, diameter 1600 mm, Vortice engine, with infrared remote, 5 speeds. Models: GRDP01 to GRDP04 (white), GRDQ01 to GRDQ04 (black). Compliance with EU 61/28 requires the lower part of the blade to be at least 2300 mm above the floor.

Regulatory Compliance

All ceiling fans must comply with EU regulation 61/28, ensuring the lower part of the fan blades is at least 2300 mm above the floor.

Specifications

Modular Wall Units: Available in white solid surface or black PaperStone®, these units are reversible and can be mounted with the open compartment on either side. They come in various sizes with 5, 6, or 7 shelves, some including a mirror.
Radiators: Available in hot water and electric versions, made of 95% aluminum and 5% steel, painted with epoxy powders. They offer thermal performance of 507 watts for hot water and up to 500 watts for electric versions. Optional towel holders are available.
Glass Wall Units: Open-faced units made of tempered transparent glass with painted back panels, available in various sizes and compartment configurations.
Fire Extinguisher: A domestic extinguisher with a stainless steel casing and wall fixing bracket, containing 2 kg of halogenous hydrocarbons.

Procedures and Recommendations
- Ensure the lower part of the blade is at least 2300 mm above the base to comply with CEE 61/28 standards.
- Radiators can be combined to create compositions, and towel holders can be mounted according to the designer's choice.

Key Data from Tables and Diagrams
- Dimensions for modular units and radiators are provided, highlighting height, width, and depth for each model.
- Thermal performance and material composition details are specified for radiators.

Critical Information
- Compliance with safety standards is emphasized for installation heights.
- The modularity and reversibility of units allow for flexible installation options.
- Optional accessories enhance functionality and customization.

Modular Low Voltage Lighting System
This system operates at 12 V and includes modules of 1200 mm. Each module can accommodate up to 4 movable, magnetically attached spots (3 for the US market) and 1 spot for 500 mm modules. The lighting options include concentrated light (24° beam) and diffused light (45° beam). The system is available in ceiling or hanging versions with tension rods. Various configurations are available, each with specific voltage and frequency requirements (110 V, 60 Hz).

Mirror Products
The document describes several mirror products, including:

KAJA: A 200 x 200 x 63 mm mirror made of transparent plexiglass with a stainless steel wall mount.
INDEX: A double-sided mirror with a satin stainless steel cylindrical structure, featuring a plane mirror on one side and a 2x magnifying mirror on the other.
LOTUS: A back-illuminated mirror with LED lighting and remote control, available in various sizes for European and US markets.
MERCURY: Square and round mirrors with specific dimensions.
OUTLINER: A suspended lamp with a black fiberboard structure and red woven fabric cable, available in small, medium, and large sizes for different markets.
TOAST: A metal lamp with frosted glass surfaces, available in different voltage configurations for European and US markets.

Complementary Items
The document also lists complementary items such as back-illuminated mirrors with finished frames and mirror cabinets with anodized aluminum compartments, available in various configurations and dimensions.
