2018/19 General Catalogue - System 44 Wiring Accessories

2018/19 General Catalogue - System 44 Wiring Accessories

Product catalog summary

Specifications and Installation Requirements
Ave materials must be installed by qualified personnel and tested by an expert in compliance with current standards. Installers should provide their contact information and details of the local technical support center to the customer.

Product Overview
The document introduces various series of wiring accessories under the System 44 brand, including NEW STYLE, ENGLAND STYLE, AVE TOUCH, LIFE, ALLUMIA, DOMUS, and TEKLA. Each series offers unique design and technological features suitable for different aesthetic preferences and functional needs.

Innovative Solutions
NEW STYLE and ENGLAND STYLE series feature innovative solutions with "hidden" modules sensitive to touch on surfaces made of glass, aluminum, or technopolymer, catering to those who appreciate a blend of vintage and contemporary styles.

Product Details
The document provides detailed descriptions of various products, including toggle controls, socket outlets, and front plates. It specifies materials used, such as glass, aluminum, wood, and Corian®, and highlights product availability for export and compatibility with British standard rectangular boxes.

Technical Features
Technical specifications for toggle switches and socket outlets are provided, including module dimensions and packaging details. The document advises contacting the sales department for product availability.

Design and Aesthetics
The series emphasizes refined designs that combine tradition and innovation, celebrating the personality of users who integrate these accessories into their home interiors as a signature of style.

AVE Touch System
The document provides detailed information on the AVE Touch wiring accessories, focusing on design, specifications, and installation of various front plates and control devices. It highlights different materials, colors, and configurations available for the AVE Touch system.

Installation Procedures
Installation instructions for both horizontal and vertical placements of the AVE Touch and Vera44 front plates are provided, emphasizing the importance of setting maximum sensitivity on devices for proper functionality.

Technical Features
The AVE Touch system supports various configurations, including multi-touch modules and customizable light signal modules, with emphasis on device sensitivity and operational voltage adherence.

Design and Customization
Design contributions by B. Dall’Eco and L. Merletti are noted, with special colors and "Giugiaro" version of front plates available upon request. Customization guidance for easier control by disabled users is provided.

Recommendations
For optimal performance, follow installation guidelines and sensitivity settings. Contact the AVE sales department for special orders and delivery terms.

Electronic Touch Switches and Controls
The document provides technical specifications and installation instructions for electronic touch switches and controls designed for integration with Ave "Touch" front plates, offering features like monostable and bistable operating modes, low power consumption LEDs, and memory retention of relay states during power outages.

Specifications
The switches operate on a 230V~ power supply and are compatible with various load types, including incandescent and halogen lamps, as well as ferromagnetic and electronic transformers.

Key Features

Monostable or bistable operation modes.
Low consumption LED for dark identification.
Relay state memory in case of power failure.
Compatibility with Ave "Touch" front plates.
Adjustable sensitivity for activation by touch or proximity (up to 4mm).

Installation and Compatibility
Connection diagrams and installation examples for various configurations are included, with devices suitable for use with British standard rectangular boxes.

Warnings and Recommendations
Adhere to specified operational voltage to prevent device damage. Home automation versions for certain models are available in additional documentation.

Conclusion
These electronic touch switches and controls offer versatile and energy-efficient solutions for modern electrical installations, focusing on user-friendly operation and seamless integration into existing systems.

Specifications
The document describes various electrical components designed for hidden installation, compatible with Ave "Touch" front plates, operating on 230V~ and including dimmers, push buttons, and light signals.

Procedures
Installation guidelines emphasize not installing more than one dimmer in the same box and setting device sensitivity either by touching the plate or at a 4mm distance.

Standards and Recommendations
Adhere to operational voltage specified in product instructions to prevent device damage. Compliance with various international standards for interchangeable films used in light signals is mentioned.

Key Features

Dimmers and push buttons feature low consumption LEDs for identification in the dark and memorize output and level relay status in case of a blackout.
Components are designed for hidden installation and are compatible with Ave "Touch" front plates.
Customizable light signals can be personalized with interchangeable labels for various applications.

Warnings
Strict adherence to specified operational voltage is mandatory to avoid device damage.

Additional Information
Details on special frames for sliding front plates and blank inserts for hidden installations are included, along with product availability and sales department contact information.

Universal USB Chargers
Two types of universal USB chargers are described: one with two frontal USB outputs and another with a single USB output, suitable for charging mobile phones, audio players, and other electronic devices via standard USB inputs.

Data Socket Outlets
Details on various RJ45 data socket outlets, including category 5 enhanced and category 6 options, are provided, featuring insulation piercing terminals for universal wiring.

Telephone Socket Outlets
Descriptions of RJ11 telephone sockets and British standard "BT SECONDARY" sockets are provided, using screw terminals and available in single-module configurations.

TV and SAT Socket Outlets
Several TV and SAT socket outlets are described, supporting frequencies up to 2400 MHz and equipped with various connectors.

Optical Fibre Socket Outlets
An optical fibre duplex socket is described, featuring an SG standard 3M connector with a VF-45 double fibre.

Adaptors for Connectors
Adaptors for various RJ45 connectors are listed, designed for use with multiple connector types.

Specifications and Components
The document outlines various components and accessories for electrical installations, focusing on frames, volume controllers, emergency lights, and signalling lamps.

Volume Controllers
Two types of volume controllers are described: a mono volume controller for individual loudspeakers and a stereo volume controller for pairs of loudspeakers.

Emergency and Signalling Lights
Details on various emergency lights with high-efficiency white LEDs, rechargeable batteries, and self-diagnosis features are provided.

Dimmer Controls
Several dimmer models are available for resistive and inductive loads, featuring rotary potentiometers, built-in switches, and LED indicators.

Technical Features and Recommendations
Compatibility with various module frames and plates from different manufacturers is emphasized, along with recommendations for specific lamp types and installation procedures.

Catalog excerpts

2018/19 General Catalogue - System 44 Wiring Accessories-1

Serie Civili Sistema 44 System 44 Wiring Accessories Realizzazione 2017 Appartamento Sito in Milano photo: Alessandro Mombelli Il materiale Ave va installato da persona qualificata e l'impianto va collaudato da persona esperta; in conformità alla normativa vigente È fatto carico all'installatore di lasciare il suo nominativo e recapito al cliente e preferibilmente lasciare anche il nominativo e l'indirizzo del CAT di zona Ave material must be installed by qualified people and the plant must be tested by an expert; according to the current standards The installer takes care to leave his name and address to the customer and preferably also the name and address of the local technical support centre

Open the catalog to page 1

2018/19 General Catalogue - System 44 Wiring Accessories-2

SER1E C1UI LI ■■■■□□□□□□ WIRING ACCESSORIES Serie civile NEW STYLE e ENGLAND STYLE NEW STYLE and ENGLAND STYLE wiring accessories Soluzioni a scomparsa assolutamente innovative basate su moduli “invisibili” sensibili allo sfioramento della superfice della placca in vetro, alluminio o tecnopolimero. Absolutely innovative solutions based on "hidden" modules sensitive to the touch on the surface of glass, aluminium or moulded front plate. Serie civile AVE TOUCH AVE TOUCH wiring accessories Soluzioni a scomparsa assolutamente innovative basate su moduli “invisibili” sensibili allo sfioramento della...

Open the catalog to page 2

2018/19 General Catalogue - System 44 Wiring Accessories-3

Novità News IL TUO MONDO, INCONFONDIBILE. QUESTA COLLEZIONE È DEDICATA A CHI VUOLE DISTINGUERSI CON SEMPLICITÀ,COLTIVANDO UN GUSTO FLUIDO TRA DESIGN VINTAGE E CONTEMPORANEO, CON PASSI ELEGANTI CHE LASCIANO SEMPRE UN’IMPRONTA ORIGINALE. YOUR WORLD, UNMISTAKABLE THIS COLLECTION IS DEDICATED TO THOSE WHO WANT TO STAND OUT WITH SIMPLICITY, HAVING A FLUID TASTE BETWEEN VINTAGE AND CONTEMPORARY DESIGN, WITH ELEGANT STEPS WHICH ALWAYS LEAVE AN ORIGINAL MARK. IL VALORE DEL TEMPO. L’AMORE PER LA TRADIZIONE E IL FASCINO DI OGGETTI E ARREDI INTRAMONTABILI: LA PERSONALITÀ CHE INCARNA QUESTA LINEA RISCOPRE...

Open the catalog to page 3

2018/19 General Catalogue - System 44 Wiring Accessories-4

u n a so l a s e r i e , a d o g n u n o i l s u o s t i l e _ONLY ONE SERIES, EVERYBODY FINDS HIS STYLE _ F I R M A LA TUA CA SA . _ SIGN YOUR HOME. _ QUESTA NUOVA SERIE RAPPRESENTA UNA SCELTA PRECISA DA PARTE DI AVE, PER RISPONDERE AI NOSTRI CLIENTI PIÙ ESIGENTI E AMANTI DEI DETTAGLI. OLTRE ALL’IMPEGNO CONSOLIDATO NELLA TECNOLOGIA, CI SIAMO CONCENTRATI SULL’ESTETICA, PROPONENDO DESIGN RICERCATI, IN PARTICOLARE NEI MATERIALI, CHE UNISCANO TRADIZIONE, INNOVAZIONE E CHE, SOPRATTUTTO, ESALTINO LA PERSONALITÀ DI CHI LI ABBINA AGLI INTERNI DELLA PROPRIA CASA, COME UNA VERA E PROPRIA FIRMA DI STILE....

Open the catalog to page 4

2018/19 General Catalogue - System 44 Wiring Accessories-5

Serie Civili Sistema 44 System 44 Wiring Accessories

Open the catalog to page 5

2018/19 General Catalogue - System 44 Wiring Accessories-6

SER1E C1UI LI ■■■■□□□□□□ WIRING ACCESSORIES Serie civile NEW STYLE e ENGLAND STYLE NEW STYLE and ENGLAND STYLE pag' wiring accessories Placche NEW STYLE NEW STYLE front plates Vetro Glass Alluminio Aluminium Corian® Placche ENGLAND STYLE ENGLAND STYLE front plates Legno Wood

Open the catalog to page 6

2018/19 General Catalogue - System 44 Wiring Accessories-7

Soluzioni NEW STYLE e ENGLAND STYLE NEW STYLE and ENGLAND STYLE Solutions Comandi a levetta Toggle controls Sequenze di installazione Installation sequences Soluzione con placche NEW STYLE vetro e placche ENGLAND STYLE legno Solutions with glass NEW STYLE front plates and wood ENGLAND STYLE front plates Caratteristiche Tecniche Technical Features Comandi a levetta NEW STYLE e ENGLAND STYLE NEW STYLE and ENGLAND STYLE toggle controls 253X4 Scatola da incasso Flush mounted box 44A03 Supporto standard S44 S44 standard frame Mostrina per aggancio ghiera fornita in dotazione con i comandi a levetta...

Open the catalog to page 7

2018/19 General Catalogue - System 44 Wiring Accessories-8

NEW STYLE 44 {yNGiiAND Qtyjc 44 Deviatori a levetta 250V~ Toggle two-way switch 250V Dimensioni del modulo Module dimensions Descrizione Description *o 444002B 444002CR 444002OT 444002B Deviatore a levetta 1P 10AX illuminabile - levetta colore bianco - fornito con n. 1 ghiera in plastica colore bianco - 1 modulo 1P10AX lightable toggle two-way switch - toggle white colour - suppled wtth no. 1 plastic whte ring -1 module 444002CR Deviatore a levetta 1P 10AX illuminabile - levetta colore cromo - fornito con n. 1 ghiera in plastica cromata - 1 modulo 1P10AX lightable toggle two-way switch...

Open the catalog to page 8

2018/19 General Catalogue - System 44 Wiring Accessories-9

Soluzioni NEW STYLE e ENGLAND STYLE NEW STYLE and ENGLAND STYLE Solutions Prese di corrente Socket outlets Sequenze di installazione Installation sequences Soluzione per scatola tonda con placche NEW STYLE Vetro / Alluminio e placche ENGLAND STYLE legno Solution for round box with glass/aluminium NEW STYLE front plates and wood ENGLAND STYLE front plates Caratteristiche Tecniche Technical Features 44A02 Supporto standard S44 S44 standard frame Presa di corrente NEW STYLE / ENGLAND STYLE NEW STYLE / ENGLAND STYLE socket outlet 2501 Scatola da incasso Flush mounted box 44PVNT90... (Vetro Glass)...

Open the catalog to page 9

2018/19 General Catalogue - System 44 Wiring Accessories-10

Dimensioni del modulo Module dimensions Prese di corrente standard italiano 250V~ Italian standard socket outlets 250V 444090/15TSALS Presa schuko bipasso (UNIVERSALE) 2P+T 10/16A - alveoli schermati - fornita con n. 3 ghiere (n. 1 in ottone, n. 1 in plastica colore bianco, n. 1 in plastica cromata) colore Allumia - 2 moduli 2P+E 10/16A (UNIVERSAL) combined schuko+Italian standard socket - shuttered supplied with 3 rings (1 brass ring. 1 plastic white ring, 1 plastic chrome ring) - Allumia - 2 modules 444090/15TSB Presa schuko bipasso (UNIVERSALE) 2P+T 10/16A - alveoli schermati - fornita con...

Open the catalog to page 10

2018/19 General Catalogue - System 44 Wiring Accessories-11

Placche NEW STYLE 44 per scatola tonda e quadrata NEW STYLE 44 front plates for round and square box Descrizione Description Info  ❒ ❒ Vetro Glass Per 1 comando a levetta For 1 toggle control 44PVNT21BL Bianco finitura lucida Clear white 44PVNT21NAL Nero assoluto finitura lucida Clear absolute black Supporto da utilizzare To be used with Descrizione Description Info  ❒ ❒ Alluminio Aluminium Per 1 comando a levetta For 1 toggle control 44PANT21ALS Alluminio naturale spazzolato Natural brushed aluminium 44PANT21ALS 44PANT21ANS Alluminio antracite spazzolato Anthracite brushed aluminium Supporto...

Open the catalog to page 11

2018/19 General Catalogue - System 44 Wiring Accessories-12

ave Placche NEW STYLE 44 per scatola tonda e quadrata NEW STYLE 44 front plates for round and square box Descrizione Description Per 2 comandi a levetta For 2 toggle controls 44PVNT22BL Bianco finitura lucida Clear white I44PVNT22NAL Nero assoluto finitura lucida Clear absolute black Supporto da utilizzare To be used with Descrizione Description Info € □ H Per 2 comandi a levetta For 2 toggle controls ■ 44PANT22ALS 1 1 Alluminio naturale spazzolato Natural brushed aluminium ■ 44PANT22ANS 1 1 Alluminio antracite spazzolato Anthracite brushed aluminium Supporto da utilizzare To...
