Product catalog summary

Introduction
Antica Ceramica Rubiera introduces a new series of porcelain stoneware tiles designed for modern construction. These tiles are available in large formats (30x60 cm and 60x60 cm) and are inspired by natural colors ranging from grey to ochre, ivory, and tobacco. The series is ideal for contemporary architecture flooring and cladding, offering a blend of authenticity and elegance.

Specifications
The tiles are rectified porcelain stoneware, colored in mass, with dimensions of 60x60 cm and 30x60 cm. They are available in various designs named after New York City boroughs and neighborhoods, such as Bronx, Queens, Manhattan, Brooklyn, and Staten Island. The tiles have a PEI IV rating, indicating high resistance to wear.

Technical Features

Water absorption: ≤ 0.5% (UNI EN ISO 10545-3)
Bending strength: ≥ 35 N/mm (UNI EN ISO 10545-4)
Frost resistance: Frost proof with no alteration (UNI EN ISO 10545-12)
Wear resistance: PEI IV (UNI EN ISO 10545-7)
Stain resistance: As declared (UNI EN ISO 10545-14)
Color stability: No change (DIN 51094)
Mohs surface hardness: Minimum 3 (UNI EN 101)

Dimensional Characteristics

Length and width tolerance: ± 0.6% max
Thickness tolerance: ± 5% max
Edge warpage: ± 0.5% max
Wedging: ± 0.6% max
Flatness: ± 0.5% max (UNI EN ISO 10545-2)

Weights and Measures

60x60 cm tiles: 4 pcs/box, 1.44 sqm/box, 29 kg/box
30x60 cm tiles: 6 pcs/box, 1.08 sqm/box, 22.5 kg/box

Contact Information
Antica Ceramica Rubiera S.r.l., Via Salvaterra 18/A, 42048 Rubiera (R.E.), Italy. Phone: +39 0522 628841, Fax: +39 0522 628976, Website: www.anticaceramica.it, Email: [email protected]

Catalog excerpts

THE BIG APPLE 002310 Bronx Rett. 60x60 78 PEI IV R96002361 002338 Queens Rett. 60x60 77 PEI IV R9 002311 Bronx Rett. 30x60 78 PEI IV R9 002339 Queens Rett. 30x60 77 PEI IV R9 002380 Fascia Chelsea2x60 07 Pz.24xbox Fascia Dumbo 10x60 79 Pz.12xbox >

Open the catalog to page 5

THE BIG APPLE 002103 Staten Island Rett. 60x60 77 PEI IV R96002360 002336 Brooklyn Rett. 60x60 78 PEI IV R9 002101 Staten Island Rett. 30x60 77 PEI IV R9 002337 Brooklyn Rett. 30x60 78 PEI IV R9 Fascia Harlem 5x60 08 002357 Fascia Soho 4x60 65 Pz.12xbox Pz.24xbox 002358 Angolo Soho 4x40 11 Pz.12xbox >

Open the catalog to page 9
