Product Overview

This document presents technical specifications and product details for a range of glazed porcelain stoneware tiles produced by Antica Ceramica Rubiera. The product line includes various collections named Rock, Antipodi, India, Rubiera, and others, with tile dimensions primarily 30.5 x 61 cm.

Product Range and Codes

The tiles are available in multiple color variants such as Polvere, Carbone, Ghiaia, Terra, Kilda, Avalon, Kripton, Salomone, Tahiti, Bombay, Calcutta, Bangalore, and Delhi. Each variant is identified by a unique article code (e.g., 002405 for Polvere) and shares common dimensions and technical ratings.

Technical Specifications

• Dimensions: Tile size 30.5 x 61 cm; battiscopa (baseboard) 7.5 x 61 cm.
• Thickness: 9 mm for tiles and battiscopa.
• Packaging: 7 pieces per box for tiles, covering 1.30 m² and weighing 23 kg; 20 pieces per box for battiscopa, covering 12.20 linear meters and weighing 16 kg.
• Boxes per Europallet: 60 boxes for tiles, covering 78 m² and weighing 1400 kg.

Performance Characteristics

Dimensional Tolerances

• Length and Width: ±0.6% max
• Thickness: ±5% max
• Edge Straightness (Warpage): ±0.5% max
• Orthogonality (Wedging): ±0.6% max
• Flatness: ±0.5% max

These tolerances ensure minimal deviation from manufacturing dimensions, guaranteeing product consistency and quality.

Standards Compliance

The products conform to the UNI EN 14411 B1a Annex G (ISO 13006) standard for glazed porcelain tiles, ensuring high quality and performance suitable for various applications.

Manufacturer Information

Antica Ceramica Rubiera S.r.l.
Via Salvaterra 18/A, 42048 Rubiera (RE), Italy
Phone: +39 0522 628841
Fax: +39 0522 628976
Website: www.anticaceramica.it
Email: [email protected]

Summary of Critical Information

• Glazed porcelain stoneware tiles sized 30.5 x 61 cm with 9 mm thickness.
• Multiple color options with consistent technical performance.
• High resistance to water absorption, bending, frost, abrasion, stains, and color fading.
• Strict dimensional tolerances for quality assurance.
• Compliance with international ceramic tile standards (UNI EN ISO and ISO 13006).
