Overview: The Altman Medium Theatre Lighting Layout Guide provides comprehensive information for implementing stage lighting in medium-sized theatres. It includes a complete lighting design package, equipment list, and examples of fixture usage, serving as a starting point for budgeting and planning.

Specifications: The layout is designed for theatres with a stage approximately 40’ wide and 30’ deep, utilizing 125 control channels and 96 – 2.4Kw dimmers, with additional 6 – 6.0Kw dimmers. The stage is divided into 15 areas, each approximately 8’-0” in diameter, with various lamps assigned for different angles and colors.

Lighting Techniques: The guide details various lighting techniques including area light, front diagonal, back light, back diagonal, down light, cyc light, pipe end, low side, head high, shins, template wash, and special lights. Each technique is designed to enhance the stage's visual depth and texture.

Fixtures and Accessories: The guide lists various fixtures such as ellipsoidal spotlights, Fresnel lights, and follow spots, along with accessories like snoots, pattern holders, and barn doors. All fixtures are U.L. and c.U.L. listed for specified wattage.

Distribution and Control: The guide includes details on raceways, cable cradles, floor pockets, and dimming and control systems, specifying the use of a 125 channel control console and dimmers.

Additional Resources: Altman offers a free Theatre Kit containing all necessary specifications and materials for professional presentations, ensuring proper theatre lighting and aiding in project funding.

Catalog excerpts

your imag-ination to light. A large part of effectingsparkling creative vision is having the right tools to projectwhat the mind sees. This brochure is equipped with all theinformation necessary to imple- ment your next stage project. It includes a complete lightingdesign package,light plot andequipment list,the latest in Altman equipment and provides an example of how the different fixtures are used. It is meant toserve as a starting point forbudgeting and planning and to bring Formore information,contact your localAltman sales representative. > BRINGING IMAGINATION TO LIGHT size="-1">

Open the catalog to page 1

DISTRIBUTION DIMMING & CONTROL 7300-138GF30-0ҔRACEWAY WITH 12 CIRCUITS AND 24 PIGTAILS ON 1-6ҔCENTERS (FOH #1,#2,1st,2nd,3rd,4th. & 5th. elec.) 2300-138GF9-0ҔRACEWAY WITH 6 CIRCUITS AND 12 PIGTAILS ON 1-6ҔCENTERS (Box Boom L&R) 54-512-LCABLE CRADLE FOR MOVING ELECTRICS 10FF-701-4-GPCFLOOR POCKET WITH 4 CIRCUITS 1125 CHANNEL CONTROL CONSOLE BY OTHERS 962.4Kw DIMMERS BY OTHERS 66.0Kw DIMMERS BY OTHERS 4PLUG-IN STATIONS BY OTHERS FOLLOWSPOTS 2COMETCOMET FOLLOWSPOT 360/410WHARDWARE10509-24-224DOUBLE TEE SIDE ARM 36509-18-118ԔSINGLE TEE SIDE ARM > FIXTURES ALL FIXTURES ARE U.L. AND c.U.L. LISTED FOR...
