CLEAR

Product catalog summary

Overview: This document is a technical catalog section presenting a series of lighting fixtures designed by Sam May. The products are characterized by their clear glass shades, glass and steel structures, matt nickel finishing, and G4 lampholders. The catalog details various models differentiated by the number of lamps, transformer types, dimensions, and additional features such as adjustable height and dimmer compatibility.

1. Product Specifications

Lamps: All models use 12V-20W lamps, with quantities ranging from 2 to 6 lamps included per fixture.
Lampholder: G4 type across all models.
Materials and Finishing: Shades made of glass; structure composed of glass and steel; finished with matt nickel.
Dimensions: Heights vary from approximately 41 cm to 122 cm depending on the model and lamp count.
Ingress Protection (IP): Rated IP20 for all fixtures, indicating protection against solid objects greater than 12.5 mm but no protection against liquids.

2. Transformer Types

Toroidal Transformer: Used in models with fixed height; typical maximum height around 150 cm.
Electronic Transformer: Used in models with adjustable height; supports maximum height up to 300 cm.

3. Features and Functionalities

Adjustable Height: Certain models feature adjustable height, enhancing installation flexibility.
Dimmer Compatibility: Models equipped with electronic transformers include dimmer functionality for light intensity control.

4. Design and Aesthetic Details

Consistent design language emphasizing transparency and modern materials.
Matt nickel finishing provides a subtle, elegant metallic look.
Clear glass shades allow for maximum light diffusion and aesthetic appeal.

5. Summary of Model Variants

Number of Lamps	Transformer Type	Height (cm)	Features
6	Toroidal	122	Fixed height
5	Toroidal	103	Fixed height
4	Toroidal	83	Fixed height
6	Electronic	Up to 300	Adjustable height, with dimmer
5	Electronic	Up to 300	Adjustable height, with dimmer
4	Electronic	Up to 300	Adjustable height, with dimmer
3	Electronic	64	With dimmer
2	Electronic	45	With dimmer

Critical Information and Recommendations

Ensure installation environments are compatible with IP20 rating (no exposure to moisture).
Use only specified 12V-20W G4 lamps to maintain product performance and safety.
For adjustable height models, verify compatibility with electronic transformers and dimmer controls.
Consider the maximum height limitations when planning installation to ensure proper fit and function.

All designs maintain a consistent aesthetic and technical standard, suitable for modern interior lighting applications requiring both style and functional versatility.
