ADQUIO MINI

Product catalog summary

Ordering Information
The Adquio Mini is a programmable controller, actuator, and datalogger. The model ADQ-4MBBN-1ETH is currently active and features Java Script programmability, 1 WAN, 4 RS485 ports, and 1 USB port.

Dimensions
Details on dimensions are not provided in the document.

Technical Data

Process Voltage: Nominal value is 24 VDC, with a maximum of 28 VDC. It includes protection against voltage reversal and a nominal protection fuse up to 3 To.
Consumption: From a 24V power supply, it consumes 90-150 mA, with a maximum consumption peak at start-up of 150 mA.
Caution: Exceeding maximum power supply voltage or improper connection cables can cause irreparable damage.

System Data

Environmental Conditions: Operating temperature is 0°C to +60°C, storage and transport temperatures range from -40°C to +70°C. Humidity is max 95% non-condensing, and air pressure for operation is >800 hPa / <2000 m.
Mechanical Data: The device is mounted horizontally with a protection level of IP20. Housing material is ABS UL-94-HB Dark gray.
Protocols: Supports Modbus RTUClient, TCPClient and server, BACnet TCP, and MSTP.
Communications: Features 4 RS485 ports with speeds from 1200 bps to 115,200 bps, 1 Ethernet WAN port with 100 Mb/s speed, and 1 USB 2.0 port. Wireless access point operates at 2.4 GHz.

Certifications
The device complies with various safety, health, EMC, and radio standards including EN ISO 13849-1:2015, EN 62061:2005 + A1:2013 + A2:2015, EN 60950-1:2006, and others.

Contact Information
Neuronal Innovation Control SL, Rúa Ánade Real 11, 15172 Oleiros, La Coruña, Spain. Telephone: 881246255, Email: [email protected], Website: adquio.com

Catalog excerpts

DATA SHEET ADQUIO MINI Programmable controller, actuator and datalogger 1 Ordering information Reference Life cycle * Adquio Mini, Java Script programmable controller, 1 WAN, 4 485, 1 USB * For planning and commissioning In new installations, use modules in Active state only Adquio Mini V 1.5 en_us

Open the catalog to page 1

3 Technical data Parameter Process voltage Connections Nominal value Maximum supported Protection against voltage reversal Nominal protection fuse up to Removable terminal block 5.08 Pitch 2 contacts Adquio Mini V 1.5 en_us

Open the catalog to page 2

Consumption From a 24V power supply Maximum consumption Maximum consumption peak at start-up CAUTION! Exceeding the maximum power supply voltage for the process or supply voltages could cause irrecoverable damage to the system. The system could be destroyed. CAUTION!! Improper connection cables cause overheating at the terminals. Acquio pro, they can be destroyed if the wrong cable type, cable size or cable temperature rating is used. 4 System data 4.1 Environmental conditions Parameter Temperature Operation 0 ° C ... + 60 ° C (Horizontal mounting on DIN rail) Adquio Mini V 1.5 en_us

Open the catalog to page 3

4.2 Mechanical data Parameter Protection level Housing material Mounting alternatives Rail DIN EN 50022 DIN mounting screws Screw with a diameter of 4 mm tightening torque RTUClient TCPClient and server Adquio Mini V 1.5 en_us

Open the catalog to page 4

Communication speed Wireless access point For installation only if the device does not detect a WAN connection. Neuronal Innovation Control SL Rúa Ánade Real 11 15172 Oleiros, La Coruña Spain Telephone: 881246255 E-mail: [email protected] https://adquio.com © 2020-2021 Neuronal Innovation Control SL We reserve all rights over this document and the information contained therein. The reproduction, use or disclosure to third parties without express authorization is strictly prohibited. Adquio Mini V 1.5 en_us

Open the catalog to page 5
