Overview: The PIGGY ALU radiator is a modern reinterpretation of the traditional 'piggy' radiator, designed for installation under windows and glass panels. It can be equipped with a wooden surface to serve as a seat or with wall-mounted shelves.

Specifications: The radiator operates based on the characteristic equation Φ=KmΔtn, with thermal power values subject to approval. It is crucial to use an automatic valve with an air vent and avoid isolating the battery by closing its valves. The guarantee is valid if the installation's working pressure does not exceed 20 bar, and the maximum working temperature is 120°C. The hub diameter is 1/2”, and the radiators have a 10-year guarantee on painting.

Technical Specifications Per Element:

• Model: 300PIGGY ALU
• Height: 240 mm
• Centres: 250 mm
• Depth: 45 mm
• Water Capacity: 0.17 litres
• Unloaded Weight: 1.4 kg
• Thermal Power Δt (50°C): 52 Kcal, 60 W
• Exponent: 1.309

Technical Specifications Per Battery:

• Model: 300PIGGY ALU
• Height: 240 mm
• Centres: 250 mm
• Depth: 250 mm
• Width varies from 540 mm to 1395 mm depending on the number of elements (12 to 31)
• Water Capacity ranges from 2.04 to 5.27 litres
• Unloaded Weight ranges from 16.8 to 43.4 kg
• Thermal Power Δt (50°C) ranges from 619 to 1600 Kcal, 720 to 1860 W

Contact Information: Gruppo Ragaini S.p.A., S.S. 77 Val di Chienti, 14 - 60025 Loreto (AN), Tel. +39 071 7500740, Fax +39 071 978814, Email: [email protected], Website: www.grupporagaini.com
