03 comfort Archimedes provides system layouts, technical data on the appliances selected and a technical description for their specification. All this information can then be printed or transferred to a Word document or AutoCAD file. .This tool allows engineers to calculate hot water requirements in a wide variety of applications (hotels, hospitals, sports centres, campsites, health units, industrial processing, ), and to propose several con- figurations that meet the design requirements. Finally Archimedes Excellencein hot water Heating needs havechanged over the last 30 years and the demands...

05 HOTEL NOVOTEL SURF Anse Vata BeachNEW CALEDONIA KANGLELIPRIMARY SCHOOLBeijingCHINA HOTEL PARCO DEI PRINCIPISorrentoITALY LES PAVILLONS HOTELMAURITIUS SPORT CENTER with sauna,climbing wall,internet cafe. SłupskPOLAND CLUB AQUA MAXBuzau ROMANIA REEBOK STADIUM Bolton UK NATHALIE HOUSING DEVELOPMENT Condeixa PORTUGAL LA PEDRERA Barcelona SPAIN SAUNA & BEAUTY CENTER DE DIJK Dendermonde BELGIUM HOTEL CARLINA Belle Plagne FRANCE OLYMPIC STADIUM Athens GREECE Individual housesApartment blocks Hotels Camp sites Restaurants Spa resorts Fast food outlets Canteens Schools Sport grounds Swimming pools...

For all cases where an ample hot water supply is desirable: simultaneous bath and shower, Jacuzzi, hydro-massage bath. The Smart Duplex is the ideal solution for thalassotheraphy solutions (spas, Jacuzzi, mini-pools) and all applications with highly chlorinated water. Battery formation Several ACV tanks can be used in battery formation for the tertiary and industrial applications that demand a high rate of hot water generation. Hydraulic kits are available to interconnect primary circuits of 2 or 3 tanks from 320 liters (SMART or HR) to 1000 liters (JUMBO).Three Jumbo 1000s installed in battery...

201 & 200 N (with gas burner) Small hydraulic pressure drop (< 0,3 mbar) Minimum space required ή to 108 % Ideal for large commercialapplications Payback period of 2 years Available for all new units of HeatMaster ή Booster HeatMaster BOOSTER 3585 1025 6162 4647 419855 99.098.5 13123005 10572580 108.6108.5 105.0105.0 105.9105.9 + TOTAL CONDENSING EXTERNALCONDENSING UNIT HeatMaster 35 TC Middle range gas condensing combination boiler Air/gas modulating pre-mix gas burner as standard: very easy to install, adjust and maintain, low NOx emissions, safe and quiet. Suitable for connection to existing...

one, two, three or four boilers, the commissioning procedure is the same, simple and easy when undertaken by a qualified engineer. any one boiler in a cascade can be serviced and maintained easily whilst the other boilers are operational. This enables the servicing to be carried out at any time of the year and not just during the traditional summer shut down period. a cascade system allows modulation of the heating power, from the minimum output of one boiler up to the maximum output of all the boilers. Which, in the case of a four-boiler cascade, gives a modulation ratio of 16:1, and of course...

Delta Performance: for large family houses and compounds Alfa is appropriate when a bath and a shower are used simultaneously Delta Performance: for installations with large consumption of domestic hot water: jacuzzi, hydromassage baths, multiple head showers When to installa combination ACV boiler ? SSMM t 30C) Ў t 30԰C) Δ ALFA SPRINTS - SV - M - MV Natural gas or propane- 35 kW input ACV premix burner BG 2000, on/off 35 kW (S, SV) or modulating from 10 to 35 kW (M, MV) Chimney (S, M) or balanced flue combustion (SV, MV) Domestic hot waterproduction: 192 litres in 10' ( ALFA modelsSSVMMV Exclusive...
