EDUCATIONAL FACILITIES • ATHLETIC VENUES • HOSPITALITY DECOR WASHROOM SYSTEMS

1 A C O R N E N G I N E E R I N G C O M P A N Y - 5 0 Y E A R S Acorn Engineering Headquarters City of Industry, California San Diego State University Jenny Craig Athletic Center San Diego, California About Acorn Engineering Company Established in 1954, Acorn Engineering Company is a world leader in the design and manufacturing of engineered plumbing products. Headquartered in Southern California, in over 700,000 square feet of manufacturing space, Acorn Engineering’s facilities include one of the largest fabricating presses in North America. Combining precision engineering with...

w w w. a c o r n e n g . c o m 2 Joe’s Garage (Automotive Museum) Tustin, California Model# M3713-1-SO-DMJ Available in stainless steel or Corterra® (solid surface material), Meridian washroom systems will offer years of trouble-free service. With fewer connections than traditional basin designs, Meridian washroom systems are designed with a single P-trap, mixing valve and water supply set for multiple basin configurations. The result: lower installation and maintenance costs. Push button metering valves or sensor activation option ensures lower operating costs while conserving water and...

3 A C O R N E N G I N E E R I N G C O M P A N Y - 5 0 Y E A R S Stainless Steel Smart Enough for Schools. Durable Enough for Prisons. Contemporary Enough for Hospitality Decor. Practical Enough for Office Environments. Model# 3702-1-SO-DML-EB-IB Dodger Stadium Los Angeles, California Model# 3713-1-SO-DMJ-IB (Multi-Units) Easy to install, repair and maintain. Ideal for a multitude of applications - available in single or multi-station as a continuous flow of decks for on or off-the-floor configurations. Stainless steel is 100% recyclable.

w w w. a c o r n e n g . c o m 4 Flander’s St. Rail Station, Melbourne, Australia Model# 3714-1-H-EB-DB The cost effective choice - each multi-station unit is served by one hot or cold water supply, one waste connection and one thermostatic mixing valve (can be modified for waste at each bowl). Air controlled metering valves are included in all Meridian installations. Choice of hands-free sensor operated valve or other selections available. Model# 3711-1-H-DMJ-IB With Chronomite Heater (concealed in trap enclosure). See Page 12.

5 A C O R N E N G I N E E R I N G C O M P A N Y - 5 0 Y E A R S Stainless Steel Contemporary design that is durable and vandal resistant. Basins are generously sized and spouts are available in a variety of user-friendly, ergonomic configurations. Model# 3714-1-SO-DMJ-EB-PDM-OF

w w w. a c o r n e n g . c o m 6 Optional Enviro-Glaze® powder coat colors allow for a choice of color to add to stainless steel. (See Page 11) Stainless steel enclosures hide the P-traps, waste outlets, and water supply lines for an aesthetically pleasing appearance. Our stainless steel products have had a reputation for durability and reliability for more than 30 years. Model# 3703IB-1-SO-DMJ-DP-SSN-PDM

7 A C O R N E N G I N E E R I N G C O M P A N Y - 5 0 Y E A R S Kurve® Three-station Model# 3793 Kur ve™ Washbasins Engineered for Commercial Use. Designed for Everyday Living. Meets ADA, TAS, UFAS, and ANSI requirements. Available in one, two or three-station washbasins. Corterra® Solid Surface with integral shelf design, individual washbasins and drains. Heavy-gage, stainless steel mounting frame and trap enclosures. Infrared sensor or pushbutton controlled metered valve with one-piece stainless steel sprayhead. Anti-scald pressure balancing mixing valve. Gravity soap system with filler...

w w w. a c o r n e n g . c o m 8 Kurve® Two-station Model# 3792 Spray nozzle Soap dispenser

9 A C O R N E N G I N E E R I N G C O M P A N Y - 5 0 Y E A R S CORTERRA® Solid Surface Mater ial An Aesthetic, Alternat ive Choice. Meridian Corterra is an alternative aesthetic specification choice to stainless steel. It is a tough, lightweight solid surface material that resists stains and burns. When minor surface damage occurs, it can be easily repaired with fine grit abrasives or cleaners. Corterra’s continuous surface design is ideal for easy cleaning. Corterra is available in a variety of configurations and designer colors. Configuration options include one, two, three or multiple...

w w w. a c o r n e n g . c o m 1 0 Model# M3772-1-SO Multiple washbasins modified for joining S e n s o r N o z z l e Spray Head Section Unique sensor design reads the presence of the hands in the washing zone, thus eliminating the possibility of accidental activation. Model# M3773-1-H-DMJ Multiple section washbasins modified for joining

1 1 A C O R N E N G I N E E R I N G C O M P A N Y - 5 0 Y E A R S ENVIRO-GLAZE® An Aesthetic, Alternat ive Choice. What is Enviro-Glaze®? Enviro-Glaze® is a durable, electro-statically sprayed powder applied to the outside of a stainless steel fixture, then cured at temperatures in excess of 400oF. Enviro-Glaze® is a smooth, hard coating available in various textures. Vigorous inspections at every step of production assures that each fixture meets Acorn's high quality standards. Enviro-Glaze® endures impact, will not bubble and is chip-resistant. Optional Enviro-Glaze® powder coat colors...

Chronomite's microprocessor technology provides solutions for traditional remote storage tank heating specifications and retrofits that are vital to today's engineer. Heater is concealed under or behind the trap cover. CHRONOMITE® Instant-Flow Micro tankless water heater benefits: Ideal hot water delivery solution for current low-flow standards in public and commercial restrooms. Easy to install. Use with single or two station configurations. No mixing of hot and cold water - eliminates the cost of mixing valves and hot water rough-in. Digital microprocessor controls hot water temperatures...

1 3 MOUNTING INSTRUCTIONS Ease of Instal lat ion Installation of the mounting wall plate entails a simple two-step process. A C O R N E N G I N E E R I N G C O M P A N Y - 5 0 Y E A R S Step 2: Place deck assembly on frame, securing angle behind frame joggle (as shown). Step 1: Level and mount stainless steel frame to the designated wall. (3792 unit shown, refer to installation instructions for every unit.) Mounting frame is manufactured from heavy gage stainless steel. A special feature to the mounting wall plate is the frame joggle that supports the deck once assembly is complete -...
