High Security with Low Impact
28Pages

TABLE QF CONTENTS 04 Penal-Ware® Comby 17 Custom Engineering / Enviro-Glaze® Option 06 Fixture Configurations 18 Drinking Fountains / Coolers / Drains 07 Stainless Steel Toilets 19 Case Study: Stainless Steel vs. Porcelain 08 Suicide Resistant Products / Detox Toilets 20 Master-Trol® - Electronic Water Management System 09 Bariatric / International Toilets 21 Valve Options 10 Stainless Steel Lavatories / Basins 22 AcornVac® Vacuum Plumbing 11 Stainless Steel Urinals 25 Case Study: Western Virginia Jail 12 Correctional Accessories 26 Chronomite® Instantaneous Water Heaters 14 Stainless Steel...

PENAL-WARE® COMB Penal-Ware® Comby (1 Penal-Ware® ADA Comby (1432-AR-2- qver a million combinations of comby Acorn Engineering's Penal-Ware® accounts for every demand in a correctional facility with a vandal-resistant, sanitary, func-tional, and economical line of combys. Plumbing fixtures are manufactured in several configurations and modified with a wide variety of options. They are also highly-customizable. For a facility looking to retrofit for added security or switch from porcelain to stainless steel, Acorn Engineering will provide a product tailored to match existing rough-ins and...

PENAL-WARE® COMBY

FIXTURE CONFIGURATIONS ^enal-Ware® Comby withstands 5,000 pounds of force without permanent deformatior MODEL NUMBER LAVATORY BOWL STYLE Multi-Sided Oval Rectangle 1415 - 15" Comby 1418 - 18" Comby Optional 1420 - 20" Comby Optional 1426 - 26" Comby ANSI Compliant ^ cUPC Certified WASTE QUTLETS -1 Off-Floor, Wall Outlet -2 On-Floor, Wall Outlet -1- -3 On-Floor, Floor Outlet -1 Off-Floor, Wall Outlet -1 Off-Floor, Wall Outlet Penal-Ware Combys and Toilets Service Sinks, Lavatories, and Drinking Fountains 6 acorn engineering Correctional Applications www.acorneng.com 800.488.8999 626.336.4561

ar mounted, and a variety of other options to choose from, there is a toilet option to fit every setting (some toilet bowl options show PERFORMANCE LONGEVITY Toilets are available in blowout or siphon jet, on- or off-floor design, with ditterent waste outlet and mounting options trom which to choose. 14-gage, type 304 stainless steel Օ Seamless weldingno accessible voids or crevices where contraband can be concealed. Satin finish on exposed surfaces ו Off-floor (wall mounted) models withstand up to 3,000 lbs. of pressure; On-floor (floor mounted) withstand up to 5,000 pounds without...

SUICIDE RESISTANT & DETQX TOILETS Suicide Rsistant Comby (1440-AR-2-BPH-03-M-LPI Penal-Ware® Detox Toilet (1699-W-3) SUICIDE RESISTANT PRODUCTS Suicide-resistant hemispherical and rounded design 镕 Suicide-resistant skirt Bariatric models (to accommodate weight requirements) Օ Custom plumbing roughs Custom-manufactured modifications DETOX TOILET Detox toilets are useful in situations where a conventional toilet may present a hazard, such as in detoxification, safety, and isolation cells. Օ Welded heavy-gage stainless steel construction Recessed in ground with no sharp edges Օ Exclusive...

ARIAtRIC TQILETS & SQUAT PAN HW-2125-A Bariatric on-floor with toilet seat. White powdercoat shown. Not suitabie for high-security settings. 2105BAR-W-1-CN Front-mount, off-floor bariatric toilet model features a Bariatric Adjustable Fixture Support from Jay R. Smith Mfg. Co. (Figure Number 0210Y-M54-XK Bariatric Duty, 1000 LBS; Figure Number 0210Y-M54-XX Extra Heavy Duty, 750 LBS). BARIATRIC TOILET INTERNATIONAL SQUAT PAN Morbidly obese patients are a growing part of the correctional population; however, their physical needs are highly specialized. Acorn Engineering's Bariatric toilets and...

Penal-Ware® Lavatory shown with front push button and bubbler Penal-Ware® Lavatory (1652-1-BPH-O4-M-DMB_BPH) LAVATORIES/BASINS 14-gage, type 304 stainless steel Օ Seamlessly hand-welded with a satin finish ADA-compliant models available S Օ 100% lead free bubbler Pb A variety of shape, inset dimensions, and options from which to choose Available Lavatory Valve: Air-Control pneumatically operated, pushbutton valve with additional bubbler control valve as an option Comby with an oval basin 10 acqrn engineering Correctional Applications www.acorneng.com 800.488.8999 626.336.4561

STAINLESS STEEL URINALS ■a-Ware® Pint-Flow Urinal (2158- )ura-Ware® Waterless Urinal (215* URINALS pint-flqw urinal (0.125 gpf) Heavy-gage, type 304 stainless steel Seamless weldingno accessible voids or crevices where contraband can be concealed Satin finish on exposed surfaces ו Vandal-resistant, seamless welded construction Heavy gage, type 304 stainless steel Օ Reduces facility's overall water consumption and contributes toward LEED certification points Easy access for service and installation Օ IAPMO certified standard washout urinal (1.0 GPF) Vandal-resistant, seamless welded...

PENAL-WARE®/CORRECTIONAL ACCESSORIES

PENAL-WARE®/CORRECTIONAL ACCESSORIES AUT-RELEASE HOۛKS support garments, towels, and other lightweight accesso-ries, but break away into a downward position should excessive weight be applied GRAB BARS are optionally available with a heavy-gage closure plate welded to the bottom of the bar for suicide resistance (-GBC) Grab bars are ADA-compliant and meet or exceed ANSI, UFAS, and ADA Q requirements for structural strength 626.336.4561 800.488.8999 www.acorneng.com Correctional Applications ACORN ENGINEERING

STAINLESS STEEL SHQWERS Penal-Ware® Penal Pak Shower Custom Penal-Ware® Penal Pak Shower (1743-04-M-RD) V V I I \ Penal-Ware® showers have been used consistently in correctional facilities for over 45 years Showerhead is threaded into rear-mounted body and locked in place. Spray pattern can only be changed with an allen wrench Hand shower available as an ADA option, and features a stainless steel quick disconnect hose ES WATER-SAVING SHOWERHEAD OPTIONS & Low-flow 1.4, 1.6, and 2.0 gpm optionally available Custom Correctional Shower Cabinets 14 ACORN ENGINEERING Correctional Applications...
