| | | Xpelair Premier DX180, DX200 & CF20 Centrifugal extract and condensation control garden fans | | |
| | | [new] | | |
| | | |
| | | |
| | | Key features | | |
| | | The Range The efficient and stylish Premier range of pressure developing fans is designed specifically for domestic applications, including bathrooms, shower rooms, home toilets and utility rooms where longer building duct runs are required. They are also suitable for commercial applications such as garden hotel rooms, office toilets, commercial restrooms and for coastal installations. All models have a gloss white casing with clean and sleek appearance. A two part casing means Premier fans can easily be recessed or surface mounted. They can be fitted into contract ceilings or studwork walls in recesses as little as 50mm deep using the side entry knockout provided, an FDA adaptor and Profile 29 flat duct. Alternatively 100mm circular ducting | | |
| | | |
| | | | | | | | | | Type: | DX centrifugal extract and CF condensation control fans | | | | Application: | Domestic bathrooms, shower rooms, toilets and utility rooms | | | | Control options: | Pull cord, timer and humidistat | | | | Legislation: | Conforms to Building Regulations | | | | Hole diameter: | | | | | | | | | | |
| | | can be used. All feature an automatic air operated back draught shutter manufacturer and the CF20 range are supplied with a brown 100mm external outlet design grille for wall or soffit fixing. The clip off front cover and removable fan blade on all models allow easy cleaning and maintenance. All also have a neon indicator (except DX180/T). DX200 and CF20 models are IPX5 rated where-as the DX180 models are IPX4. All are BEAB approved. They are all suitable for 220-240Vac 50Hz mains operation. Motors are totally enclosed and maintenance free for life, with self aligning bearings and a thermal cutout. All electronics and wiring terminals are fully protected. | | |
| | | |
| | | |
| | | BEAB Approved | | |
| | | |
| | | |
| | | Select the right product for your application | | |
| | | |
| | | | | | | | | | | | | | | | | | | DX180 | DX180T | DX180H | DX200 | DX200T | CF20 | CF20T | | | | Reference number | | 91181AW | 91182AW | 91183AW | 91013AW | 91014AW | 91015AW | 91016AW | | | | | | | ■ | | ■ | | ■ | | | | Integral pullcord | | | | | | ■■ | | | | Integral adjustable run-on timer (30s to 20 mins) | | | | | ■■ | | | | Integral fixed run-on timer (20 mins) | | | ■ | | | | | | | | | Humidity sensor (50-90% RH) | | | | ■ | | ■ ■ | | | | Quick visit facility (2 minutes) | | | | | | ■■ | | | | Speeds | | 1 | 1 | 1 | 2 | | 5 | 5 | | | | | | | | | | | ■ | ■ | | | | Extract performance (FID, m3/h) | boost | - | - | - | - | - | 108 | 108 | | | | | speed 3 | - | - | - | - | 108 | 102 | 102 | | | | | speed 2 | - | - | - | 108 | 79 | 79 | 79 | | | | | speed 1 | 94 | 94 | 94 | 50 | 50 | 50 | 50 | | | | | trickle | - | - | - | - | 36 | 36 | 36 | | | | Extract performance (FID, l/s) | boost | - | - | - | - | - | 30 | 30 | | | | | speed 3 | - | - | - | - | 30 | 28 | 28 | | | | | speed 2 | - | - | - | 30 | 22 | 22 | 22 | | | | | speed 1 | 26 | 26 | 26 | 14 | 14 | 14 | 14 | | | | | trickle | - | - | - | - | 10 | 10 | 10 | | | | Sound pressure level (dB(A)@3m) | boost | - | - | - | - | - | 50 | 50 | | | | | speed 3 | - | - | - | - | 50 | 48 | 48 | | | | | speed 2 | - | - | - | 50 | 42 | 42 | 42 | | | | | speed 1 | 49 | 49 | 49 | 32 | 32 | 32 | 32 | | | | | trickle | - | - | - | - | 26 | 26 | 26 | | | | Electrical power rating (W) | | 26 | 26 | 26 | 34 | 34 | 34 | 34 | | | | IP rating | | IPX4 | IPX4 | IPX4 | IPX5 | IPX5 | IPX5 | IPX5 | | | | Weight (kg) | | 2.0 | 2.0 | 2.0 | 1.75 | 1.75 | 1.75 | 1.75 | | | | Guarantee (years, UK) | | 3 | 3 | 3 | 3 | 3 | 3 | 3 | | | | | | | | | | | | | | | | |
| | | |
| | | 10 | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | |
