TOPAZ - 2 Pages
| TOPAZ | |||||||||||||||||||||||||||||
| Dimensions | |||||||||||||||||||||||||||||
| -1/2"--» | |||||||||||||||||||||||||||||
| 27-3/8" | |||||||||||||||||||||||||||||
| 29-1/2" | |||||||||||||||||||||||||||||
| Shown in matte black with Solitaire front | Gold door trim for Solitaire front | ||||||||||||||||||||||||||||
| Fran- L-27-3/4---J | |||||||||||||||||||||||||||||
| Our largest cast iron gas burning stove, the Topaz represents a stylish alternative in warming your home. The Topaz is more than just a heating device i t's a piece of art. You have a choice of color and two different fronts. Optional warming shelves with beautiful accent brackets can add to the individuality of your stove. The Topaz is a wonderful way to heat your home and add an artistic touch to any room in your home. A number of options are available to suit your personal tastes. The unique Quartet front looks great with the doors opened or closed; or choose the cleaner open style of the Solitaire front (matte black only). Select from clasic black, porcelain mahogany, or baked enamel sienna bronze or willow to accentuate your dשcor. Add warming shelves for extra charm and functionality, a blower for improved heat circulation, and even a remote control with a thermostat for convenience. And, with both top and rear direct-venting options, you can install your new Topaz almost anywhere. Standard Features Strength & beauty of cast iron Օ Matte black finish Top vent (optional rear vent) Օ Natural convection heater Heats without power Օ Bedroom/mobile home approved Limited Lifetime Warranty Options Օ Porcelain mahogany finish Baked enamel sienna bronze & willow finish Օ Solitaire or Quartet fronts | |||||||||||||||||||||||||||||
| 18" | |||||||||||||||||||||||||||||
| Clearai | |||||||||||||||||||||||||||||
| A Side of stove top to side wall...............6-1/2" B Rear of stove top to back wall....................6" C Corner of stove top to side wall.................1" D Minimum alcove height..........................54" E Maximum alcove depth..........................36" F Minimum alcove width...........................40" G Mantle clearance from stove top.............23" | |||||||||||||||||||||||||||||
| Technical & Performance Data Width.......................27-3/8" Flue Size.....................6-5/8" Height......................29-1/2" Standing Pilot Ignition.....Yes Depth.......................22-1/2" Mobile Home Approved ..Yes Weight (quartet front) .... 275 lbs. Bedroom Approved.........Yes Heating Capacity*...................................................up to 2,000 sq. ft. Btu/Hour Input NG*...................................26,500 - 39,500 Top Vent Btu/Hour Input LP*.....................................30,500 - 38,000 Top Vent Efficiency**.........................................................................up to 85% Convection Blower.................................................................160 cfm | |||||||||||||||||||||||||||||
| CanadS | |||||||||||||||||||||||||||||
| ener(3|uide | |||||||||||||||||||||||||||||
| Gas Fireplace Energy Efficiency Rating 63% NG/64% LP | |||||||||||||||||||||||||||||
| Baaed on CSA P.4.1-02 | |||||||||||||||||||||||||||||
| The strongest in the industry, Quadra-Fire provides a limited lifetime warranty on gas-burning products for their most important aspects: firebox and heat exchanger. For full warranty details go to www.quadrafire.com | |||||||||||||||||||||||||||||
| WARRANTY J | |||||||||||||||||||||||||||||
| IMPORTANT - READ BEFORE YOU INSTALL! Refer to the Owner/Installation Manual for complete clearance requirements and specifications. The images and descriptions in this brochure are provided to assist you in product selection only. *Heating capacity rating and Btus are to be used as a guideline only. Actual performance may differ slightly due to climate, building construction and condition, amount and quality of insulation, location of the heater, and air movement in the room. Quadra-Fire is a registered trademark of Hearth & Home Technologies. Product specifications and pricing subject to change without notice. The Quadra-Fire Topaz direct vent gas appliance listed to ANSI standard Z21.88a-2000/CSA 2.33a-M00 Vented Gas Fireplace Heaters and applicable sections of UL307b Gas Burning Heating Appliances for Manufactured Homes and Recreational Vehicles, CAN/CBA 2.17-M91 "Gas Fired Appliances for Use at High Altitude," by OMNI-Test Laboratories, Inc., Beaverton, OR. | |||||||||||||||||||||||||||||
| (Solitaire in matte black only) | Black | ||||||||||||||||||||||||||||
| Mahogany | |||||||||||||||||||||||||||||
| Decorative firescreen (Quartet only) Gold trim (Solitaire only) Warming shelves Օ Variable speed blower Rear vent conversion kit Օ Wall thermostat Thermostatic remote controls | |||||||||||||||||||||||||||||
| Sienna bronze Willow | |||||||||||||||||||||||||||||
| Available From: | |||||||||||||||||||||||||||||
| 1445 North Highway, Colville, WA 99114 www.quadraflre.com Օ 800-926-4356 QDF-1007U-1108 | |||||||||||||||||||||||||||||
