Important Information

or diamond edged saw. This has the effect of shortening the surface of the tile in contact with the wall.Therefore, to maintain a consistent vertical joint line, all non-moulded tiles furniture laid above and below the moulding must also be cut to the shorter width. However this does not apply to the Skirting, Victoria and Albert External Corners which have been designed specifically for use on outside corners. Victoria dados should not be used on any wooden surfaces due to thermal expansion of the wood which may crack the dado.

Fixing / Installation

Detailed fixing/installation methods for internal applications are specified in BS5385 Part 1 and ANSI A108. Original Style tiles are not recommended for external application. For detailed advice on the particular adhesives to use in a variety of circumstances please ask your supplier for the Original Style leaflet Ceramic Architectural wall tiles - Fixing and Cleaning Instructions (applicable in United Kingdom only). In the USA please follow the recommendations and instructions of a reputable adhesive manufacturer. In particular we recommend that the American National Standards Specifications are followed.

Always comply with American National Standards Institute (ANSI) specifications as set out in the Handbook for Ceramic Tile Installation published by the Tile Council of America.

Do not install Original Style tiles directly into wet cement or sand and cement.

Seahngjoints

In all installations, especially shower cubicles, joints should be sealed with an impervious grout such as BAL Supergrout or an epoxy type. Joints between tiles and shower basins should be sealed with silicone sealant. If joints are not completely watertight moisture can be absorbed into the tile body causing stains to show through the translucent glaze. Silicone expansion joints should be incorporated under Victorian dados.

Fixing Moulded Tiles to Outside Corners

To fix cornice and other moulded tiles to an outside corner one end of the tile must be carefully mitred at 45° with a carborundum

Technical Specifications

Original Style 7mm tiles conform to BS 6431 Part 9 - specification for dust-pressed tiles with a water absorption of E>10% Group B111.

Limits of Liability

Original Style accepts no liability for the faulty installation of its tiles. In the case of any claim relating to the tiles themselves, Original Style's liability, to the extent permitted by law, is limited to either the replacement of the product or a refund of the cost of the product, and does not extend to cover any consequential loss. Tiles must be inspected prior to installation and claims cannot be considered after the tiles have been installed.

Please be advised that installation constitutes

acceptance of the quality, colour, texture,

shade and size of tiles.

Original Style warrants that its tiles conform

to their description and are fit for their

purpose.

Original Style makes no other express or implied warranty as to fitness or suitability of the products for particular installations. We extend no guarantees, express or implied, as to wear resistance or maintenance procedures.

Please note, the use of certain acid based cleaning products may cause some of the tiles to react and change in character.

Original Style gratefully acknowledges the assistance of the following companies with the photographic settings: FURNISHING & ORNAMENTS

Cleaning

Wash down tiled surfaces with either clean water or a neutral (i.e. not acidic or alkaline) detergent. Dry off and polish with a dry duster.

Victorian Green tiles have a copper-based glaze which is prone to discolouration by very mild acids often found in the home. To avoid such discolouration they should be cleaned only with pure water and should always be wiped dry immediately after cleaning. These tiles should never be used in wet areas such as showers, bath surrounds or basin splashbacks.

Shading

Some shade variation between tiles of the same stated colour is inherent in the production of decorative ceramics. For all the coloured tiles except whites, we have produced Variglaze, a special glaze formula which produces a unique colour effect. Therefore, before fixing tiles, it is important to lay them out in good light to ensure that any shade difference is evenly distributed.

, IKtt IINILKIUKS

Scratching

01392 876688 www.orangetreeinteriors.co.uk ECLECTIQUE

01392 250799 www.eclectique.co.uk

ANTIQUE BATHS OF IVYBRIDGE 01752 698250 www.antiquebaths.com

FAGINS ANTIQUES

01392 882062 www.faginsantiques.com HABITAT www.habitat.com

INTERIOR BUILDING PAINTS

NATURAL COLOURS ORIGINAL STYLE LTD

01392 473000 www.originalstyle.com

TAPS & SHOWERS _BRISTAN

01827 304050 www.bristan.com FLOORING

VICTORIAN FLOORING TILES ORIGINAL STYLE LTD 01392 473000 www.originalstyle.com

Some photography reproduced in this brochure is courtesy of Horus S.A. www.horusfrance.com

It should be noted that with all glazed surfaces, some wearing or scratching may occur over a period of time. Care should therefore be taken to select the proper tile for a given use. The wall tiles shown in this brochure are not recommended for surfaces subject to heavy wear.

Crazing

Highly glazed ceramic tiles manufacturers may craze with time, and no guarantee can be given against this occurring.

Measurements

Due to size fluctuations, all measurements given are nominal. Where strict accuracy is

required, please refer to current samples. All dimensions are subject to a tolerance of +2.5mm or 3/32".

| Tiles used in this setting: 6085A Blue Iris Border Tile, half size, 6084A Blue Iris 6 tile building panel, A9000 Brilliant White Field tile, A9911 Brilliant White External Corner Trim, GJB9900 Albert, GJB9902 Rope, GJB9909 Omega (all Jade Breeze).
