Garden window Type

Model_LWG0761QAG_LWC076GGMM0_LWG0960QAG_LWC096GGMM0_LWG0961PAG_LWC1265PAG_LWC126AQAG

Model

LWG0761BAG LWC076GGAB0 LWG0761BCG LWG0960BCG LWC096GGAB0 LWG0960ACG LWC1264AAG LWC1264BAG


	Cooling	IBtu/hrl	7,000	7,000	7,000	9,000	9,000	9,000	12,000	12,000

	Voltage,Freguency,Phase	IV.Hz.o)	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1
	Power Input	IWattl	775	775	775	1,000	1,000	1,000	1,260	1,260
	Running Current	(A)	3.4	3.4	3.4	4.2	4.2	4.2	5.6	5.6
	E.E.R	IBtu/hr.Wl	9.0	9.0	9.0	9.0	9.0	9.0	9.5	9.5
	Air Circulation, IN/Out	ICMMl	5.8/11.5	5.8/11.5	5.8/11.5	5.8/11.5	5.8/11.5	5.8/11.5	7.9/18	7.9/18
	Moisture Removal	If /hrl	0.80	0.8	0.8	1.0	1.0	1.0	1.3	1.3

Cooling_IBtu/hrl _7JT00__7JT00__9,000__9JT00__9,000__12,000__12,000


	Voltage, Freguency, Phase	IV.Hz.0l	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1
	Power Input	IWattl	775	775	1,000	1,000	1,000	1,260	1,260
	Running Current	IAl	3.4	3.4	4.2	4.2	4.2	5.6	5.6
	E.E.R	IBtu/hr.Wl	9.0	9.0	9.0	9.0	9.0	9.5	9.5
	Air Circulation, IN/Out	ICMMl	5.8/11.5	5.8/11.5	5.8/11.5	5.8/11.5	5.8/11.5	7.9/18	7.9/18
	Moisture Removal	l!/hrl	0.80	0.80	1.00	1.00	1.00	1.3	1.3


	Temperature Control		Thermistor	Thermistor	Thermistor	Thermistor	Thermistor	Thermistor	Thermistor
	Gold Fin
	Auto-swinglLefr & Right)		•	•	•	•			•
	Remote Controller		•	•	•	•	•	•	•
	Auto Restart		•	•	•	•	•	•	•
	Reversible Open Design grille		•	•	•	•	•	•	•
	Timerl12-Houroff)	I12hr)	•	•	•	•	•	•	•
	#Fan/Cool	(design steps)	3/3	3/3	3/3	3/3	3/3	3/3	3/3
	Air Deflection		4-Way	4-Way	4-Way	4-Way	4-Way	4-Way	4-Way
	Air Discharge		Side by Side	Side by Side	Side by Side	Side by Side	Side by Side	Side by Side	Side by Side
	AirVentilation		•	•	•	•	•	•	•
	Home slide in/out	(Chassis)	•	•	•	•	•	•	•
	Compressor	(type)	Rotary	Rotary	Rotary	Rotary	Rotary	Rotary	Rotary

	Net Dimensions.(mm)	[WxHxDI	469x353x525	469x353x525	469x353x525	469x353x525	469x353x525	600x380x567	600x380x567
	Net Weight	IKgsl	30	30	31	31	31	43	43
	Stuffing Q'ty Without S/Parts	I20ft/40ft)	200/419	200/419	200/419	200/419	200/419	135/300	135/300


	Temperature Control		Adjustable Thermostat	Adjustable Thermostat	Adjustable Thermostat	Adjustable Thermostat	Adjustable Thermister	Adjustable Thermostat	Adjustable Thermostat	Adjustable Thermostat
	Gold Fin
	Auto-swinglLefr & Right)		•	•	•	•	•			•
	Remote Controller
	Auto Restart
	Reversible Open Grille		•	•	•	•	•	•	•	•
	Timer(12-Houroff)	I12hr)
	#Fan/Cool	(steps)	2/3	2/3	2/3	2/3	2/3	2/3	2/3	2/3
	Air Deflection		4-Way	4-Way	4-Way	4-Way	4-Way	4-Way	4-Way	4-Way
	Air Discharge		Side by Side	Side by Side	Side by Side	Side by Side	Side by Side	Side by Side	Side by Side	Side by Side
	AirVentilation		•	•	•	•	•	•	•	•
	Slide in/out	(Chassis)	•	•	•	•	•	•	•	•
	Compressor	(type)	Rotary	Rotary	Rotary	Rotary	Rotary	Rotary	Rotary	Rotary

	Net Dimensions.(mm)	[WxHxDI	469x353x525	469x353x525	469x353x525	469x353x525	469x353x525	469x353x525	600x380x567	600x380x567
	Net Weight	IKgsl	30	30	30	31	31	31	43	43
	Stuffing Q'ty Without S/Parts	(20ft/40ft)	200/419	200/419	200/419	200/419	200/419	200/419	135/300	135/300

Model_LWM186AQAG_LWJ0561AAG_LWJ0561ACG_LWG0761AAG_LWG0960AAG_LWG0960BAG_LWG0761ACG

Model_LWC1264BCG LWM1863BAG LWM2260BAG LWN1862BAG LWN2263BAG LWM1863BCG LWN1862BCG LWN2263BCG

Cooling_IBtu/hrl | 12,000 | 18,000 | 21,000 | 18,000 | 20,500 | 18,000 | 18,000 | 20,500

Cooling_IBtu/hrl _18,000__bflOO__5T300__7JT00__9,000__9,000__7,000


	Voltage, Freguency, Phase	IV.Hz.Bl	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1
	Power Input	(Watt)	2,250	625	625	775	1,000	1,000	775
	Running Current	(A)	10.1	2.8	2.8	3.4	4.2	4.2	3.4
	E.E.R	IBtu/hr.Wl	9.1	8	8	9.0	9.0	9.0	9.0
	Air Circulation, IN/Out	ICMMl	12/23	3.8/8.5	3.8/8.5	5.8/11.5	5.8/11.5	5.8/11.5	5.8/11.5
	Moisture Removal	If/hrl	2.10	1.4	1.4	0.80	1.00	1.00	0.80


	Voltage,Freguency,Phase	IV.Hz.Bl	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1	220-240,50,1
	Power Input	(Watt)	1,260	2,250	2,470	2,460	2,520	2,250	2,460	2,520
	Running Current	(A)	5.6	10.1	10.4	12.0	13.5	10.1	12.0	13.5
	E.E.R	IBtu/hr.Wl	9.5	9.1	8.5	7.3	9.3	9.1	7.3	9.3
	Air Circulation, IN/Out	ICMMl	7.9/18	12/23	13/23	12/23	13.2/24	12/23	12/23	13.2/24
	Moisture Removal	If /hrl	1.3	2.10	2.4	1.8	2.4	2.10	1.8	2.4


	Temperature Control		Thermistor	Adjustable Thermostat	Adjustable Thermostat	Adjustable Thermostat	Adjustable Thermostat	Adjustable Thermostat	Adjustable Thermostat
	Gold Fin		•	•		•	•	•
	Auto-swinglLefr & Right)		•					•
	Remote Controller		•
	Auto Restart		•
	Reversible Open Grille		•	•	•	•	•	•	•
	Timer(12-Houroff)	I12hr)	•
	#Fan/Cool	(steps)	3/3	2/2	2/2	2/3	2/3	2/3	2/3
	Air Deflection		4-Way	4-Way	4-Way	4-Way	4-Way	4-Way	4-Way
	Air Discharge		Side by Side	Side by Side	Side by Side	Side by Side	Side by Side	Side by Side	Side by Side
	AirVentilation		.	.	.	.	.	.	.
	Slide in/out	(Chassis)	•	•	•	•	•	•	•
	Compressor	(type)	Rotary	Rotary	Rotary	Rotary	Rotary	Rotary	Rotary

	Net Dimensions.(mm)	(WxHxDI	660x428x675	472x312x380	472x312x380	469x353x525	469x353x525	469x353x525	469x353x525
	Net Weight	IKgsl	65	20	20	30	31	31	30
	Stuffing Q'ty Without S/Parts	I20ft/40ft)	84/192	317/664	317/664	200/419	200/419	200/419	200/419


	Temperature Control		Adjustable Thermostat	Adjustable Thermostat	Adjustable Thermostat	Adjustable Thermostat	Adjustable Thermostat	Adjustable Thermostat	Adjustable Thermostat	Adjustable Thermostat
	Gold Fin			•	•	•	•
	Auto-swinglLefr & Right)		•	•	•	•	•	•	•	•
	Remote Controller
	Auto Restart
	Reversible Open Grille		•	•	•	•	•	•	•	•
	Timer(12-Houroff)	I12hr)
	#Fan/Cool	(steps)	2/3	2/3	2/3	2/3	2/3	2/3	2/3	2/3
	Air Deflection		4-Way	4-Way	4-Way	4-Way	4-Way	4-Way	4-Way	4-Way
	Air Discharge		Side by Side	Side by Side	Side by Side	Side by Side	Side by Side	Side by Side	Side by Side	Side by Side
	AirVentilation		.	.	.	.	.	.	.	.
	Slide in/out	(Chassis)	•	•	•	•	•	•	•	•
	Compressor	(type)	Rotary	Rotary	Rotary	Rotary	Rotary	Rotary	Rotary	Rotary

	Net Dimensions.(mm)	[WxHxDI	600x380x567	660x428x675	660x428x675	660x428x770	660x428x770	660x428x675	660x428x770	660x428x770
	Net Weight	IKgsl	43	65
