| | | Outrigger Feed/Mechanical Support Flex 12TM may be mounted parallel to the wall and electrically fed when installed over a wall-mounted outlet box that is wired to the transformer secondary Specify: (1) TF530SL or (1) TF529SL | | |
| | | Wall Feed/Mechanical Support Flex 12TM may be mechanically supported perpendicular to the wall and electrically fed through a wall- mounted outlet box that is wired to the transformer secondary Specify: (1) TF45SL | | |
| | | |
| | | |
| | | Wall Mount Electrical Feeds & Mechanical Supports | | |
| | | Canopies & Pendant Stems | | |
| | | |
| | | |
| | | TF45SL Wall Feed/Support Canopy Electrically feeds and/or mechanically supports the trac perpendicular to wall. Mounts directly to wall or over standard 4" outlet boxes. 25-amp capacity 5" diameter | | |
| | | Feed/Support Canopies Used in conjunction with pendant stems for electrical feed and mechanical support of trac. 43/i" diameter | | |
| | | |
| | | Mounts onto T-bar runner and can be fed via flexible metal conduit or non-metallic cable entering into the top of the ceiling mounting plate. TF91SL Canopy for Rigid Ceilings Mounts over standard ceiling outlet boxes. | | |
| | | |
| | | Outrigger Electrical Feed and Mechanical Support Used to mechanically support and electrically feed power to the trac in a parallel to wall installation. Extends 5/2" from wall. One electrical feed outrigger per circuit is required. | | |
| | | |
| | | |
| | | TF529SL Electrical Feed Outrigger Requires 5/16" hole drilled in trac. 25-amp capacity. Mounts over standard 4" wall outlet boxes. 5" diameter | | |
| | | Mini-Canopies (Support only) Used in conjunction with pendant stems or 10-24 threaded rod (not supplied) for mechanical support of trac. Secures to ceiling with toggle bolt (supplied), wood screw or optional T-bar attachment clip. 2Vi" diameter | | |
| | | |
| | | TF530SL Mechanical Support Outrigger Requires 5/16" hole drilled in trac. Canopy fastens to wall with toggle bolts (supplied) or wood screws (not supplied). 3" diameter | | |
| | | |
| | | TF92SL TF93SL | | Mini-Canopy for Pendant Stems Mini-Canopy for 10-24 Threaded Rod | | |
| | | |
| | | |
| | | R37F* T-Bar Attachment Clip_ R37D* T-Bar Attachment Clip with spacer for ceilings using dropped tiles *T-Bar clips must be ordered separately T94SL Sloped Ceiling Adapter Permits pendant stems to be hung vertically from sloped ceilings. Used In conjunction with TF91 or TF92 Celling Canopies (not Included). Allows feeding of wires to trac at up to a 60 degree angle. Accommodates a maximum of two 12 gauge solid THHN copper wires. 20-amp capacity. | | |
| | | |
| | | |
| | | Pendant Stems Threaded top and bottom permit attachment at the top to canopy assemblies, and at the bottom to electrical feed/support cylinders. Inside diameter accommodates two 10 gauge solid THHN copper wires. | | |
| | | |
| | | | | | | | | | TF903SL | 3/2" | | | | TF912SL | 12" | | | | TF918SL | 18" | | | | TF924SL | 24" | | | | TF936SL | 36" | | | | TF948SL | 48" | | | | T96SL | Pendant Stem Coupling | | | | | | | | | |
| | | |
| | | 121 | | |
