| | | Project . Item _ | | |
| | | |
| | | Quantity _ CSI Section 11400 _ Approval _ Date - | | |
| | | Delta 5 | | |
| | | |
| | | |
| | | Models □ Delta 5 | | |
| | | |
| | | Standard Features • Energy Star® qualified (292 mm) high Push-button start Automatic fill, cycle and drain Solid-state timer Easily accessible controls 3-way dispensing system for detergent, rinse additive and sanitizer Stainless steel wash pump Lower rotary wash arm and fixed upper jets Door-safety switch Adjustable bullet feet Swing-out control box for easy service and access Side control panel for easy access to switches Dial temperature gauge for constant monitoring of temperature | | |
| | | • Side skirt panels • Latch-type front (lower) panel • Delime/manual wash switch Optional Features □ 50 Hz cycle Accessory Items □ 36 Compartment Racks 4-1/8", 5-5/8", or 7" (105 mm, 143 mm, 178 mm) □ Combination Rack □ Peg Rack □ Flat Rack □ Half Rack □ Scaltrol □ Water Hammer Arrestor | | |
| | | |
| | | |
| | | Specifications | | |
| | | |
| | | Uses only 1.16 gallons (4.39 liters) of water per cycle Cleans 40 racks per hour 1,000 glasses per hour 90-second operating cycle Powerful 3/4 HP wash pump motor Built-in chemical pumps Air-gap water inlet 11-1/2" (292 mm) wash chamber clearance | | Gravity drain Built-in waste accumulator Sustaining heating element maintains final rinse between 120°F (49°C) and 140°F (60°C) Removable end plugs on lower wash arm and removable upper jets Durable 304 stainless steel construction | | |
| | | |
| | | |
| | | www.jacksonmsc.com E-mail: customerservice@jacksonmsc.com 07610-003-61-07 (10/08) | | |
| | | Tel: 606-523-9795 Tel: 1-888-800-5672 Fax: 606-523-1799 | | |
| | | SHIPPING ADDRESS 6209 North US Highway 25E Gray, KY 40734 | | MAILING ADDRESS P. O. Box 1060 Barbourville, KY 40906 | | |
