PHOTOVOLTAIC POWER SYSTEMS

Installing a photovoltaic power system is a RESPONSIBLE CHOICE because it respects the environment, contributes to reducing the exploitation of natural resources and decreases gas emissions causing air From an economic perspective it is a long- term investment, as it has a fixed cost which is not influenced by economic or energetic crises, or can even provide a fixed income if the energy produced is sold to an electricity Advantages of a photovoltaic power system: • Reliability and small amount of maintenance. • Self-production of electric energy if necessary, or alternatively, handover to the...

CONTENTS THE IDEA OF A PHOTOVOLTAIC SYSTEM Solar radiation and territory 5 ISOPAN INTEGRATED ROOFING SYSTEMS Isopan technology offer Advantages Fields of application 6 FIXING SYSTEMS 1st xing system: xing to the frame 2nd xing system: xing to the external frame 8 METALWORK Supporting metalwork and nish 10 ISOPAN ENGINEERING SERVICES 12 MONOCRYSTALLINE AND POLYCRYSTALLINE SILICON MODULES The photovoltaic effect and different typologies of solar cells The best solution 13 FURTHER COMPONENTS OF A PHOTOVOLTAIC POWER SYSTEM Photovoltaic system Inverter Photovoltaic system typologies Electricity production...

PV modules installed on an Isopan LG 40 corrugated sheet roong (Project PV: Gesuina Energy of Oristano) PV modules installed on an Isopan LG 40 corrugated sheet roong (project PV: OMD solar power systems of Bergamo): detail of a construction site

THE IDEA OF A PHOTOVOLTAIC SYSTEM SOLAR RADIATION AND TERRITORY Sunlight is a vital source of energy which can provide our planet with an amount of power, in the form of solar radiation, about 1.100 times greater than what it actually needs and with an average solar irradiance of 1367 Watts per square meter, which is called “solar constant” . Europe’s geographical position is characterized by an excellent insolation, which makes it an ideal area for the adoption of photovoltaic systems. Solar electricity (kWh/kWp) Yearly sum of global incident solar radiation on optimally-inclined south-oriented...

ISOPAN INTEGRATED ROOFING SYSTEMS ISOPAN TECHNOLOGY OFFER Isopan produces integrated roong systems with photovoltaic modules. Proprietary technologies enable the company to produce integrated roong systems both with insulated panels and with corrugated sheets. PV system with Isopan corrugated sheet LG 28 (project PV: Energetics s.r.l.) ADVANTAGES • Warranted watertight integrated roong with photovoltaic system. • The system can be applied regardless of the size of photovoltaic modules. • Fixing systems and side closing proles of roofs, which can be applied on any roof regardless of covering,...

ISOPAN INTEGRATED ROOFING SYSTEMS FIELDS OF APPLICATION Industrial and commercial domain: roongs for commercial buildings and industrial hangars. PV system with Isopan corrugated sheet LG 28 (PV project: Energetics s.r.l.) Civil domain: roongs for domestic and private buildings. PV system with Isopan corrugated sheet LG 40 (PV project: OMD solar power systems): detail of a construction site Livestock domain: roongs for agricultural sheds and livestock farms. PV system with Isopan insulated panel ISOCOP 7

FIXING SYSTEMS FIRST FIXING SYSTEM: FIXING TO THE FRAME Advantages • Simplyed replacement of photovoltaic modules. • Gap between two panels so that electrical cables can pass in the middle. Isopan xing system 8

FIXING SYSTEMS SECOND FIXING SYSTEM: FIXING TO THE EXTERNAL FRAME Advantages • Quickness and cheapness of panel tting: lack of proles and mechanical xing components between proles and panels. • Tensile strength equal to 200 kilograms per square meter *. • Long-lasting reliability warranted by the use xing systems and screws made of stainless steel and by the watertight property of EPDM and neoprene rubber gasket. • Excellent architectural and structural PV system integration. * This value is determined on a PV module whose sizes are 160x100 cm and which is xed with four screw anchors. This gure...

METALWORK SUPPORTING METALWORK AND FINISH OF PHOTOVOLTAIC MODULES made of pre-painted natural aluminium or natural steel FV – L 1 FV – L 2 PUNCHING PUNCHING PUNCHING PUNCHING 20 14 14 41 41 19 FV – L 3 A FV – L 3 B PUNCHING 20 20 13 13 FV – L 4 16 FV – L 5 PUNCHING PUNCHING 41 37 20 10 0 ° 15 10 * The sizes which are not present can change according to the module size, prior previous check by the Product Development Department.

METALWORK FV – L 6 A FV – L 6 B 22 40 17 17 13 FV – L 7 for corrugated sheet 13 FV – L 8 26 MICRO-DRILLING 40 39 22 CUTTING 16 16 16 16 FV – L 9 FV – L 10 157,1 R4 9 210,8 MICRO-DRILLING CUTTING 12 * The sizes which are not present can change according to the module size, prior previous check by the Product Development Department. 40 11

ISOPAN ENGINEERING SERVICES In collaboration with several specialized companies Isopan can offer its customers both engineering installation services and post-installation management and maintenance services: • Consultancy and technical assistance for the choice of products. • Design of roongs with insulated panels and integrated photovoltaic tiles. • Design of photovoltaic roong systems and, if necessary, design, testing and tting of carrying skeleton structures. • Electricity network design for photovoltaic systems. • Planning and implementation of turnkey projects. • Management of connection...

MONOCRYSTALLINE AND POLYCRYSTALLINE SILICON MODULES THE PHOTOVOLTAIC EFFECT AND DIFFERENT TYPOLOGIES OF SOLAR CELLS The photovoltaic effect is the creation of voltage by a device, called “solar cell” (mainly made of silicon) which converts solar radiation (power from sunlight) into electricity. The solar cell is the photovoltaic module key element, able of turning solar energy into electricity. When the cell is hit by sunlight, solar radiation photons release their power creating a ux of electric charges. Silicon is the most used material in the production of solar cells and in Earth’s crust...
