Woodburning contemporary stoves and cauldrons


Product	Power kW	Recommended sauna supplier room size min-max m³	Dimensions (W x D x H) mm	Adjustable height ca mm	Weight Stone space Fire space ca kg max. kg *) cover mm			Diameter of smoke outlet mm	Location of smoke outlet mm (pictures 1 and 2) ABC			Alternatives for chimney hole location Picture 3 Picture 4 Picture 5 Picture 6 AAAA
Harvia M3	13	4,5-13	390 x 430 x 710		45	30	5	115	560	640	120	830	1000	1380	1570
Harvia 20 Pro	18	8-20	430 x 510 x 760	+30	60	40	10	115	560	670	120	850	980	1410	1540
Harvia 20 ES Pro	18	8-20	430 x 650 x 760	+30	75	40	10	115	560	670	120	850	980	1410	1540
Harvia 26 Pro	22	10-26	430 x 510 x 810	+30	65	50	6	115	690	750	130	930	1070	1490	1630
Harvia 36	30	14-36	510 x 510 x 810	+30	70	60	6	115	680	750	130	930	1070	1490	1630
Harvia 50	40	20-50	510 x 720 x 1050		160	120	10	140	890	1090	130	1230	1370
Cauldron 50 L			480 x 520 x 730		65			120	600
Cauldron 80 L			0590x760	+30	80			140	670

*) The amount of stones varies depending on the consistency and shape of the stones as well as how they have been piled.

Safety distances for the stoves

The safety distance from combustible materials:

- 500 mm to the sides and back. A space of one meter must be left in front of the stove for the user.

- 1200 mm upwards

The wooden floor under the stove must be protected by at least 60 mm of concrete or protective bedding and sheath.

Note! The safety distance for the non-isolated smoke pipe is 1000 mm. If you have questions regarding the safety distances,

contact for example your local fire inspector.

Examples of connecting a stove to a masonry chimney:

Location of smoke outlet on top/at the rear, dimensions (pictures 1 and 2). Alternatives for chimney hole location (pictures 3-6). Note! The distance between the back wall of the stove and the wall made of non combustible material affects the location of the chimney hole.

Smoke outlet on top (B) -Smoke outlet at rear (a)_

i/i/ii/i/n/ii/i/iif//,

Picture 3

mimmiimmiiM

Picture 2

i///iiii//i/i/in/i/7//r

Picture 4

//////in/////////

Picture 5

77777m

mrnmrnmrmfmrmmn

Picture 1

Picture 6

Duo, SL and Boiler stoves

Recommended sauna room Power size Product kW min-max m³

Dimensions Adjustable Weight Stone space Diameter of Size of installation hole mm Safety distance Flange size mm

(W x D x h) mm height ca mm ca kg max. kg *) smoke outlet mm A B mm min C D E


M3 SL	13	4,5-13	390 x (430 + 220) x 710		50	30	115	210 390	500
20 Duo	18	8-20	430 x (510 + 280) x 760	+30	80	40	115	405 485	500	560 600
20 SL	18	8-20	430 x (510 + 220) x 760	+30	70	40	115	210 390	610
20 Design boiler	18	8-20	430 x 510 x 760	+30	65	40	115
20 SL Boiler	18	8-20	430 x (510 + 220) x 760	+30	75	40	115	210 390	610
36 Duo	30	14-36	510 x (510 + 280) x 810	+30	80	60	115	405 485	540	560 600

*) The amount of stones varies depending on the consistency and shape of the stones as well as how they have been piled.

Installing Duo and SL stoves

mma 9
