www.hadleygroup.co.uk 38
38
HORIZONTAL CLADDING INSET SYSTEM AND VERTICAL RAIL SYSTEM
UltraBEAM
Horizontal Rail
VERTICAL
VR SERIES VERTICAL RAILS
Vertical Rails for use with Horizontally Laid Cladding
Systems are fitted between Horizontal Side Rails as
detailed. The standard Vertical Rail is 145 Series
UltraBEAM. Connecting holes in horizontal rails are
punched at centre line position of vertical rail and due to
the unique method of attaching diagonal tie assemblies:-
No handing or length adjustment of the vertical rail is
necessary. When used with counter formed holes reduce
VR by 5mm.
Vertical Rails are normally supplied as factory
assembled items, but cleats and rails may be
ordered for ‘on-site’ assembly if required.
Diagonal Tie Assembly
HD-DTB
Horizontal Rail
Vertical Rails
VRSC
VRLC
VRSC (Short)
Cleat
Std. 14ø Holes
for Diagonal Tie
Attachment and/or
on-site assembly
Counter
form
depth
5mm
15mm
VRLC (Long)
Cleat
UltraBEAM
Horizontal Rail
145 UltraBEAM
25
25
HORIZONTAL CLADDING
The details shown offer a simple method of
construction which incorporates UltraBEAM Horizontal
Rails and Vertical Rail Assemblies.
Horizontal Rail capacities should be taken from the
published load tables using the Wind Suction (-ve)
values for both Wind Pressure and Suction.
NB: To simplify detailing VRLC and VRSC
Cleats are suitable for use with UltraBEAM
Channel Rails only - not UltraZED.
145 UltraBEAM SERIES VERTICAL RAIL ASSEMBLY
20mm
15mm
CL
** Denotes section gauge dependant on selection
taken from relevant load tables.
HOR. VERT. SHORT LONG
RAIL RAIL CLEAT CLEAT
14550** VR145/145 VRSC145 VRLC145
17050** VR145/170 VRSC170 VRLC170
20063** VR145/200 VRSC200 VRLC200
22563** VR145/225 VRSC225 VRLC225
25575** VR145/255 VRSC255 VRLC255
28575** VR145/285 VRSC285 VRLC285
VERTICAL RAILS ARE SUPPLIED
AS FACTORY ASSEMBLED
ITEMS UNLESS ORDERED
OTHERWISE.
Std. 14ø Holes
for Diagonal Tie
Attachment
ANGLE
BRACKET
AB1
45 x 45 ANGLE
ADJUSTMENT
VERTICAL
RAIL
HD-DTB
VERTICAL RAIL/DIAGONAL TIE ASSEMBLIES
MAXIMUM UNRESTRAINED LENGTH OF HORIZONTAL RAIL = 3050mm
(SEE ALSO HEAVY DUTY STRUTS FOR FULL DIAGONAL TIE ASSEMBLY DETAILS)
NOTE: CONSTRUCTION/DETAILS
To ensure correct selection
of Diagonal Tie Assemblies
during construction of
Side Rail System all HDS
Struts and VR Rails should
be orientated as detailed
above.
ie:- Open side of vertical
section to left when viewed
from outside of building.
30º - 65º
COUNTER FORMED HOLE DETAIL
UltraBEAM®
