MULTIDIRECTIONAL DIFFUSEREE300

-- - - --600

Installation dimensions

525 -- - - -525600

EE300 + ET010 + GT007

450 -- - -450525600 375 -- -375 450525600 300 --300 375 450525600

2

225

Application Technical information

The diffuser type EE300 is used forthe supply and exhaust of cooled or heated air in facilities such as offices,shopping centres,confe- rence rooms,... The diffuser can be mounted in the ceiling and has a fixed 3-way hori- zontal air pattern. -225 300 375 450525600 H (mm)L (mm)150 150225 300 375 450525600 • completely in extruded alumini-um; natural tone anodised. Construction: Characteristics : •Square or rectangular diffuseravailable in multiples of 75mm as well in height as in length min L = 150 mm,max L = 900 mm min H = 150 mm,max H = 600 mm•Fixed 3-way horizontal air pattern. •Removable core consisting ofseveral air distribution elements. It is possible to replace the core with that of EE100,EE200 and EE400,in accordance with the desired air pattern. Dimensions LxH: L = nominal length, H = nominal height.All dimensions in mm. Dimension A With flow equalizer ET010With damper GT007With flow equalizer and damper ET010 + GT007 7682114
Specifications subject to change © 6-2006

E 2 110
