INTERNATIONAL

FIXED CIRCULAR DIFFUSERDR160

Installation dimensions

DR160 DR170S

Application Technical information

The diffuser type DR160 is used forthe supply and exhaust of cooled or heated air in facilities such as offices,shopping centres,… The diffuser can be used for ceiling or exposed duct mounting and has a fixed horizontal air pattern. DR170

2

Characteristics : •fixed horizontal air pattern,flatmounted rings• available with side entry plenum,with or without damper in side entry Construction: •steel; painted white (RAL 9010)•plenum with or without insulation;galvanised steel sheet Size ∅ A ∅ BC ∅ DEFGH ∅ N 160200250315 248298 363448190230 2803503636 3636123158 198 248345395470 520216234264 289185220270 310305340390440158198248313 All dimensions in mm.
Specifications subject to change © 6-2006

E 2 030
