FIXED STEEL DIFFUSERD-400

Installation dimensions

DD400 + DT008 + GR002 D-400T

2

Application Technical information

The diffuser type D-400 is used forthe supply and exhaust of cooled or heated air in facilities such as offices,shopping centres,confe- rence rooms,... The diffuser can be mounted in the ceiling and has a fixed 4-way hori- zontal air pattern. ØD Characteristics : •Square diffuser with fixed 4-wayhorizontal air pattern•Available in multiples of 75mmfrom 150 up to 450 mm.•Fixing with plenum possible; withor without damper in inlet collar•plenum delivered seperately D-400S N
45 150225 300 375 450
1 • galvanised steel,painted white(RAL9010) B
ø D Construction:
1 210280 360 430 510
H A ØD H H 294369 444 519 594
A Size150225 300 375 450
1 2 1 2 (1) 125200 200 315 315 125200 250 315 355 240315 315 430 430 100150 150 210 210 All dimensions in mm.(1): Size H
2 with damper; without damper, H
2 =120mm. B= min. ceiling opening
Specifications subject to change © 6-2006

E 2 050
