GR002 :Steel mounting support (only for DD400).

AccessoriesFixingSpecifications description

DT008 :Opposed blade damper for DD400 or DF400. Construction out of galvanised sheet steel,painted black. Operated by a key through the dif- fuser core.• • GT007 : Opposed blade damper forDE400. Construction out of galvanised sheet steel,painted black. Operated directly at the damper after removing the core. For further information,see p.1 290.• DD400 : fixed core with central screw fixing.DD408DD420S - DD420SG DD420T - DD420TG DD421S - DD421SG DD421T - DD421TG DD428S - DD428SG DD428T - DD428TG• DE400 : removable corewithout screw holes.DE407DE400S - DE400SG DE401S - DE401SG DE407S - DE407SG DE400T - DE400TG DE401T - DE401TG • DF400 : fixed core with screwfixing in the margin.DF408DF400S - DF400SG DF408S - DF408SG DF400T - DF400TG DF408T - DF408TG• DD/DE400P : DD/DE400 integrat-ed in false ceiling plate 594 x 594 mm.For further information,see p.2 500. DD400 size 300 x 300 mm with damper DT008 ,mounting support GR002 and insulated plenum DP100SG

Possible deliveriesHow to order

a) Diffuser b) Mounting support

DD428SG03000300

LH -: non insulated plenumG: insulated plenum

GR002--03750375

Size For DD400 0 : without damper1 : with damper in inlet spigot of plenum 7 : with damper GT007 for DE400 8 : with damper DT008 forDD/DF400- : without plenum S : plenum with side entry T : plenum with top entry0 : without mounting support 2 : with mounting support in plenum (for DD400)D: fixed core with central screw E : removable core for lay-on T-bar F : fixed core with screws in the margin *REMARK : For further information about plenum box see p.8 010

E 2 050
