GYMNASIUM FLOOR GRILLEAG800

Installation dimensions

AG800

1

Application Technical information

The floor grille type AG800 is usedfor the supply and exhaust of cooled or heated air in rooms requiring a solid construction,such as sports centres,industrial halls,... The grille is purpose-made for inte- gratedfloor mounting. L: nominal length (mm) H: nominal height (mm) All dimensions in mm. Characteristics : •special solid construction for floormounting,with fixed horizontal straight bars•trimmed edges •bars on 16
2/3 centres•available in multiples of 1 mm inlength and 25 mm in height min L = 100 mm,max L = 1500 mm min H = 50 mm,max H = 450 mm•linear grilles (= grilles in multiplepiecesconsisting of intermediateand end pieces) only available in heights 100,150,200,300 mm•Succesfully tested to complywith the specification and struc- tural integrity requirements of European test standard EN13264 - medium structural classification (with a load of 3 kN over 25 x 25mm
2 area
) Construction : •flanges and bars out of extrudedaluminium,satin anodised
Specifications subject to change © 6-2006

E 1 220
