Example: Aluminium floor grille in a solidconstruction with trimmed edges and removable core. Margins for floor integration. Standard construction,satin anodised. Type:AG800 nom.dim.(LxH) ...x ...(mm)

INTERNATIONAL

AccessoriesFixingSpecifications description

• GT007 : Damper with verticalopposed blades. Construction of galvanised sheet steel,painted black. (For details,see p.1 290)•flow equalizer consisting of vanesmade of aluminium sheet,satin anodised•the grille is anchored in the floorby means of straps on the flange.

Corner sections

How to order: AG800 corner section,height = 200 mmThe corner sections are being manufactured in one piece in aninner size of 300 x 300 mm nominal (see drawing). The corner sections are standard 90°.

A G 8 0 0C -0 3 0 0 0 2 0 0

Inner sizeH

Possible deliveries

AG800 Grille with front bars.

How to order

AG810 Grille with front bars and flow equalizer. AG800,dimension 600 x 200 mm,with damper GT007 AG807

AG807--06000200

Grille with front bars and opposed blade damper. LH AG817 Grille with front bars,flow equalizer and opposed blade damper. -:grille in one pieceE:end piece M:intermediate piece0:with bars only1:with flow equalizer0:without damper7:with damper

E 1 220

Specifications subject to change © 6-2006
