TRANSFER GRILLE WITH FIXED VANES WITH 45°DEFLECTIONA-250

Installation dimensions

AD250AE250 AF250 For a detailed selection see p.1 111

1

The transfer grille type A-250 is usedfor wall mounting. The grille can be used for supply or exhaust of small air volumes in heat- ing,ventilating or air treatment sys-tems.

Application Technical information

Characteristics: • horizontal vanes with 45°deflec-tion• distance blades = 20 mm •can be used as supply,exhaustand transfer grille•available in multiples of 25 mm inlength and 25 mm in height min L=100 mm,max L=1575 mm min H=75 mm,max H=800 mm•GT007: only available in multiplesof 25 mm as well in length as in height Construction: •margin and vanes in extrudedaluminium,naturel tone anodised L = nominal length (mm)H = nominal height (mm) All dimensions in mm
Specifications subject to change © 6-2006

E 1 110
