Elementi Elements Elements Elementos

Dimensione Dimension Dimension Dimensiòn


	A mm	B 400	500	600	700	800	900	i.000	i.i00	i.200	i.300
4	1481	75	90	i05	i20	i35	i50	i65	i80	i95	2i0
5	185H	93	ii2	i3i	i50	i 68	i87	206	225	244	262
6	222	ii2	i34	i57	i80	202	225	247	270	292	3i5
7	259	i3i	i57	i83	209	236	262	288	3i5	34i	367
8	296	i49	i79	209	239	269	300	330	360	390	420
9	333	i68	202	236	269	303	337	37i	405	438	472
10	370	i87	224	262	299	337	374	4i2	450	487	525
11	407	205	247	288	329	371	4i2	453	495	536	577
12	444	224	269	3i4	359	404	449	494	539	585	630
13	48il	243	29i	340	389	438	487	536	584	633	682
14	518H	26i	3i4	366	4i9	472	524	577	629	682	735
15	555	280	336	393	449	505	562	6i8	674	73i	787
16	592	298	359	4i9	479	539	599	659	7i9	779	840
17	629	3i7	38i	445	509	573	637	700	764	828	892
18	666	336	403	47i	539	606	674	742	809	877	944
19	703	354	426	497	569	640	7ii	783	854	926	997
20	740	373	448	523	599	674	749	824	899	974	i.049
21	777	392	47i	550	628	707	786	865	944	i.023	i.i02
22	8i4	4i0	493	576	658	74i	824	906	989	i.072	i.i54
23	85i	429	5i6	602	688	775	86i	948	i.034	i.i20	i.207
24	888	448	538	628	7i8	808	899	989	i.079	i.i69	i.259
25	925	466	560	654	748	842	936	i.030	i.i24	i.2i8	i.3i2
26	962	485	583	680	778	876	974	i.07i	i.i69	i.267	i.364
27	999	504	605	707	808	910	i.0ii	i.ii2	i.2i4	i.3i5	i.4i7
28	i036	522	628	733	838	943	i.048	i.i54	i.259	i.364	i.469
29	i073	54i	650	759	868	977	i.086	i.i95	i.304	i.4i3	i.522
30	iii0	560	672	785	898	i.0ii	i.i23	i.236	i.349	i.46i	i.574
31	ii47	578	695	8ii	928	1.044	i.i6i	i.277	i.394	i.5i0	i.627
32	ii84	597	7i7	837	958	i.078	i.i98	i.3i8	i.439	i.559	i.679
33	i22i	6i6	740	864	988	1.112	i.236	i.360	i.484	i.608	i.732
34	i258	634	762	890	i.0i8	i.i45	i.273	i.40i	i.529	i.656	i.784
35	i295	653	784	9i6	i.047	1.179	i.3i0	i.442	i.574	i.705	i.837
36	i332	672	807	942	i.077	i.2i3	i.348	i.483	i.6i8	i.754	i.889
37	i369	690	829	968	i.i07	1.246	i.385	i.524	i.663	i.802	i.94i
38	i406	709	852	994	i.i37	i.280	i.423	i.566	i.708	i.85i	i.994
39	i443	728	874	i.02i	i.i67	1.314	i.460	i.607	i.753	i.900	2.046
40	i480	746	897	i.047	i.i97	i.347	i.498	i.648	i.798	i.949	2.099
41	i5i7	765	9i9	i.073	i.227	1.381	i.535	i.689	i.843	i.997	2.i5i
42	i554	784	94i	i.099	i.257	i.4i5	i.573	i.730	i.888	2.046	2.204
43	i59i	802	964	i.i25	i.287	1.448	i.6i0	i.772	i.933	2.095	2.256
44	i628	82i	986	i.i52	i.3i7	i.482	i.647	i.8i3	i.978	2.i43	2.309
45	i665	840	1.009	i.i78	i.347	1.516	i.685	i.854	2.023	2.i92	2.36i
46	i702	858	1.031	i.204	i.377	i.550	i.722	i.895	2.068	2.24i	2.4i4
47	i739	877	1.053	i.230	i.407	1.583	i.760	i.936	2.ii3	2.290	2.466
48	i776	895	1.076	i.256	i.437	i.6i7	i.797	i.978	2.i58	2.338	2.5i9
49	i8i3	9i4	1.098	i.282	i.466	1.651	i.835	2.0i9	2.203	2.387	2.57i
50	i850	933	i.i2i	i.309	i.496	i.684	i.872	2.060	2.248	2.436	2.624

hego line
