VAC/ Phase
Unit Model Number: Capacity, Amperage, Kilowatts
Factor
UE 001
UE 003
UE 005
UE 008
UE 009
UE 010
UE 015
UE 025
UE 035
UE 045
UE 045
UE 065
UE 090
UE 130
208/1 (U)
lbs/hr (kg/hr)
3.3 (1.5)
6.6 (3)
11.0 (5)
19.1 (8.7)
Amps
5.4
10.8
18.0
31.3
KW
1.12
2.25
3.75
6.52
230/1 (D)
lbs/hr (kg/hr)
3.3 (1.5)
6.6 (3)
11.0 (5)
19.8 (9)
Amps
4.9
9.8
16.3
29.3
KW
1.12
2.25
3.75
6.75
208/3 (W)
lbs/hr (kg/hr)
6.6 (3)
11.0 (5)
17.6 (8)
22 (10)
33 (15)
55 (25)
77 (35)
99 (45)
Amps
6.2
10.4
16.7
20.8
31.2
52.0
72.9
93.7
KW
2.25
3.75
6.0
7.50
11.25
18.75
26.25
33.75
230/3 (K)
lbs/hr (kg/hr)
6.6 (3)
11.0 (5)
17.6 (8)
22 (10)
33 (15)
55 (25)
77 (35)
99 (45)
Amps
5.6
9.4
15.1
18.8
28.2
47.1
65.9
84.7
KW
2.25
3.75
6.0
7.5
11.25
18.75
26.25
33.75
460/3 (M)
lbs/hr (kg/hr)
6.6 (3)
11.0 (5)
17.6 (8)
22 (10)
33 (15)
55 (25)
77 (35)
99 (45)
132 (60)
198 (90)
286 (130)
Amps
2.8
4.7
7.5
9.4
14.1
23.5
32.9
42.4
61.2
84.7
122.4
KW
2.25
3.75
6.0
7.5
11.25
18.75
26.25
33.75
48.75
67.5
97.5
575/3 (N)
lbs/hr (kg/hr)
11.0 (5)
17.6 (8)
22 (10)
33 (15)
55 (25)
77 (35)
99 (45)
132 (60)
198 (90)
286 (130)
Amps
3.8
6.0
7.5
11.3
18.8
26.4
33.9
49.0
67.8
97.9
KW
3.75
6.
7.5
11.25
18.75
26.25
33.75
48.75
67.5
97.5
Height
24.4" (620mm)
28" (710mm)
35" (890mm)
37.2" (945mm)
37.2" (945mm)
Width
14.4" (365mm)
14.4" (365mm)
21.9" (555mm)
25.6" (650mm)
45.5" (1156mm)
Depth
10.8" (275mm)
10.8" (275mm)
14.2" (360mm)
17.9" (455mm)
17.9" (455mm)
Dry Weight
35.3 lbs (16 kg)
44 lbs (20 kg)
75 lbs (34 kg)
97 lbs (44 kg)
160 lbs (73 kg)
Wet Weight
41.9 lbs (19 kg)
59.5 lbs (27 kg)
133.4 lbs (60.5 kg)
207.2 lbs (94 kg)
330 lbs (150 kg)
Max. Water Feed
0.16 gpm (0.6 l/m)
0.32 gpm (1.2 l/min)
1.06 gpm (4.0 l/min)
l.85gpm(7 l/min)
4 gpm (15 l/min)
Water Feed Connection
3/4" MPT (19mm) bushed to 1/4" O.D. compression
Max. Drain Rate
1.32 gpm (5 l/min)
6.0 gpm (22.5 l/min)
l2gpm(45 l/min)
Drain Connection
1.6" hose (40 mm)
Min. Drain Piping
3/4" (19 mm)
1 1/2" (38 mm)
No. Cylinders
1 2
Steam Outlet (No. x size)
1 x 22/30 mm
1 x 30 mm
1 x 40 mm
2 x 40 mm
4 x 40 mm
Control Voltage
24 VAC 50/60 Hz.
Ambient Conditions
34-I40°F (l-40°C), 0-80% RH, up to 8" W.C. duct static pressure (200 mm WC.)
15-116 psi (1-8 bar), 125-1250 MicroMhos conductivity
Feed Water Conditions
VSDU0A
VRDXL (One (1) required for each steam outlet. i.e. four (4) for UEI30)
Power: 24 Volt powered by unit
Power: 220/1/50-60, 35 Watts
AirVolume: 112 cfm (192 m3/hr)
Air Volume: 380 cfm (646 m3/hr)
Height/Remote: 6.3/10.75" (160.273 mm)
Height: 10.5" (267 mm)
Weight: 13.2 lbs. (6 kg)
Weight: 63 lbs. (24 kg)
Noise: 30 dBA (50)
Noise: 40 dBA
Ventilated Steam Distributors
Model Selection
UE
025
H
D
0
U
1
0
UE =
humiSteam
Electrode Home humidifier
Steam Output
025 = 55 lbs/hr See selection contract table above for unit model no.
H Control
For use with: On/off, Modulating, DDC
Power Supply
U = 208/1 D= 230/1 W = 208/3 K = 230/3 M = 460/3 N = 575/3
Version Number
Internal Use Only
USA
Cylinder Type
1 = Disposable Standard Conductivity
2 = Disposable Low Conductivity
Optional Equipment
0 = Standard B = Direct Mount Blower
CAREL
CAREL USA
385 South Oak Street, Manheim, PA 17547 - Tel. (717) 664-0500 - Fax (717) 664-0449 www.carelusa.com - e-mail: sales@carelusa.com
+30U240405 Rev.1.0
CAREL reserves the right to modify or change its products without prior notice.
