Product Category D PUMPING STATIONS >

D.1 INTRODUCTION 3 D.1.1 WHO IS BORALIT? 3 D.1.2 BORALITS ACTIVITIES 3 D.2 PUMPING STATIONS 4 D.2.1 SPECIFICATIONS 4 D.2.2 WORKING 4 D.2.3 HOW TO DETERMINE THE TYPE OF PUMP NEEDED 5 D.2.3.1 Determination of the manometric height 5 D.2.3.2 Type of liquid 5 D.2.3.3 The maximum flow rate 5 D.2.3.4 Determination of the correct pump table and pump curve 6 D.2.4 TECHNICAL DATA OF PUMPING STATIONS 6 D.2.5 TYPES OF STANDARD PUMPS 8 D.2.6 DEMAND FOR CALCULATION OF YOUR PUMPING STATION 9 D.2.7 TECHNICAL FORM 9 D.2.8 INSTALLATION PROCEDURES 10 D.2.9 MAINTENANCE 10 D.2.10 WARRANTY 11 D.3 DIRECT NUMBERS 11...

Boralit is a fast expanding company with a motivated team of young people who aim for a customer-oriented approach. Boralit never stops searching for new techniques and products (R&D) and concentrates on competitive quotations and optimal timely delivery. Every worker is committed to high quality and excellent service. Boralit has made superior quality its goal for all its products, and has earned a strong reputation for quality in the international market. Boralit is the only Benelux rotational moulding company which holds several important quality certificates and is expanding its European...

Boralit product category D Pumping Stations Version 2008/1 4 Boralit N.V. - Nijverheidslaan 12 ֖ 9880 AALTER Belgium Tel.: (09) 375 11 11 ֖ Fax: (09) 375 22 22 Site: www.boralit.be - E-mail: [email protected] >

In order to determine the right type of pump for your project, the following data are of great importance: The vertical distance (height) over which the liquid should be pumped The horizontal distance (length) over which the liquid should be pumped The type of liquid that should be pumped (rainwater, wastewater, faecal water, ) The maximum flow rate 1 or 2 pumps Then, follow the steps as stated below: > Depending on the type of liquid that should be pumped, different pumps can be chosen. a) Rainwater, slightly polluted water or pretreated water: For these types of liquids, the OMUA pumps can...

Depending on the type of pump (see 2) a) or 2) b)) you should find the right pump table below. Choose your manomatric height on the vertical axis (see 1)). Draw a horizontal line, starting from this point. Choose your maximum flow rate the on the horizontal axis (see 3)). Draw a vertical line, starting from this point. Now choose a pump curve which lies above the point where your vertical and horizontal lines meet. In case you cant find the adequate pump for your project, please contact our sales department. > Types of pumps in combination with types of tanks: TP40S is a pump with cutting system,...

Table 3: Pump type TP50 Table 3.1 Table 3.2 Table 4: Pump type TP65 Type 4.1 Type 4.2 Image 2 Image 3 > Boralit product category D Pumping Stations Version 2008/1 7 Boralit N.V. - Nijverheidslaan 12 ֖ 9880 AALTER Belgium Tel.: (09) 375 11 11 ֖ Fax: (09) 375 22 22 Site: www.boralit.be - E-mail: [email protected] size="-1">

In order to determine the correct type of pumping station for your project, a calculation which takes into account your personal requirements is always necessary. If wanted, Boralit can take care of the calculation which will result in a pumping station that will fit your needs. What does Boralit need to offer you this service? Please fill out the form below and note down the technical requirements which are important for your project. Send the form to our sales department and we will provide you with a detailed offer that describes the pumping station you need. > A.What TYPE OF LIQUID does your...

ATTENTION: The pumping station can be installed in sand, this at a maximum depth of 1 meter below the ground surface. In case the pumping station should be installed at a greater depth, installation in consolidated sand is obligatory. Dig a hole which is at least: - 15 to 20 cm wider than the tank, - 15 to 20 cm deeper than the distance between the entry of the pumping station and the bottom of the tank.In case there is groundwater or rainwater in the pit, it should be pumped out before (consolidated) sand is provided in the pit. Cover the bottom of the pit with a layer of (consolidated) sand...

We offer a 50-year warranty on all our products for manufacturing defects, except the pumps and mechanical, electric, parts which carry 2 years warranty. Failure to comply with installation procedures and guidelines will void the warranty. >
