Hugo Boss store, New York CityLighting Design by JKLD, Inc >

Lighting for the retailenvironment is a key in helping a store enhance the retail experience in an effort to draw customers back to their stores. >

Rosa Mexicano restaurant, New York CityLighting Design by Johnson Schwinghammer >

North Carolina Museum of Natural Sciences, Raleigh, NCLighting Design by Available Light >

Smart-Track > TM is a comprehensive system of components thatoffers innovative solutions for transporting control signals as well as power to individual luminaires. Whether using simple architectural control stations; a laptop; or a DMX-based theatrical lighting console, you are in control with Smart-Track. This heavy-duty extruded aluminum track is ideal for demandingapplications where a low-profile look is desired but numerous and/or heavy luminaires are needed. The three 20-amp circuits combined with an innovative data bus offer endless design opportunities. For total flexibility,you can choose...

Global trac eco | Catalog number : ASL-E1, ASL-E2 When you need a compact solution, this track series from NordicAluminum fills this requirement. Depending upon the model, you can have one or two 20-amp circuits so that one or two groups of luminaires can be operated on this track. Global tracή tek | Catalog number : ASL-2 When you need dimming with your track lighting, this system gives you aseparate neutral grounding conduit for each circuit. This guaranteed circuit isolation eliminates cross-circuit interference, giving you the best results when operating two separate groups of luminaires...

Mounting Methods In addition to standard mounting hardware, Altman offers componentsfor quick installation. The easy-to-use Twist-Lock Mounting Clips (for one and two-circuit eco) and track Mounting Clips (for 3-circuit pro and 2-circuit tek .) Compatible finishes are available. Suspension Methods Stem kits allow you to hang track below the mounting surface. Stemlengths of 12Ҕ, 18, 24Ԕ, and 48. (30.5, 45.7, 61.0, and 121.9 cm) are available. Compatible finishes are available. tek and 3-circuit pro .Inaddition, the Conduit End Feed allows for connections around obstacles. Compatible finishes are...

IQ20 CDM | Catalog number :IQ20C This compact IQseries luminaire is designed for medium throws andaccepts 39-watt CDM PAR20 lamps. At a distance of 20 (6.1m), the IQ20 CDM typically produces a pool of light 3Ғ 6 (1.1 m) in diameter with aspot lamp, and 10Ԓ 6 (3.2 m) in diameter with a flood lamp. This luminaire uses 3Ԕ-diameter accessories.Lamp type :CDM PAR20 חWattages : 39 Voltages : 120, 240, & 277 חAvg. lamp hours : 9,000 Dimensions (in) :6.125 W x 9.875 H x 4.75 D חDimensions (Cm) : 15.56 W x 25.08 H x 12.06 D Weight :5 lb / 2.3 kg IQ30 CDM | Catalog number IQ30C The PAR30 IQseries CDM luminaire...

IQ20 MR16 | Catalog number :IQ20MR16 For use with 20- to 75-watt MR16 and standard 3.25 (8.3 cm)accessories. From 15Ԓ (4.6 m), this luminaire can produce a pool of light 4 5Ҕ to 12 (1.3 to 3.7 m) in diameter. This luminaire uses 3Ҕ-diameter accessories.Lamp type : MR16 חWattages : 20, 37, 50, & 75 Voltages : 120, 240, & 277חAvg. lamp hours : 2,000 Dimensions (in) : 4.88 W x 7.75 H x 4.75 D חDimensions (cm) : 12.4 W x 19.7 H x 12.06 D Weight : 1.5 lb / .7 kg IQ20 Quartz | Catalog number : IQ20 For use with PAR20/PAR16 lamps. From 10ג (3.0 m), can produce a poolof light 2 1Ҕ (64 cm) across with...

IQ36 Quartz / AR111 | Catalog number :IQ36 For use with 12-Volt PAR36 and AR-111 screw terminal lamps up to 75-watts. From 20Β (6.1 m), can produce a pool of light 2 8Ҕ (.812 m) across with a 75-watt AR-111 spot lamp. This luminaire uses 3-3/4 accessories.ԗLamp type : PAR36 &AR111Wattages : 35, 50, & 75חVoltages : 120, 240, & 277 Avg. lamp hours : 3,000 חDimensions (in) : 5 W x 8.625 H x 6.125 DDimensions (cm) : 12.7 W x 21.9 H x 15.6 D חWeight : 3 lb / 1.4 kg IQ38 Quartz |Catalog number IQ38 For 45- to 250-watt PAR38 lamps. From 20 (6.1m), can produce a poolof light 12Ғ 6 (3.81 m) across with...

IQ64 Quartz | Catalog number : IQ64 The largest of the IQseries PAR luminaires, this unit is ideal when youneed maximum punch for dramatic highlighting applications. For 500- watt PAR64 lamps. From 20 (6.1 m) can produce a pool of light 4Ғ 6 (1.37 m) high x 7Ԓ 2 (2.16 m) wide with a 500-watt Narrow Spot lamp. This luminaire uses 7-7/16Ԕ-diameter accessories.Lamp type :PAR64חWattages :500Voltages :120 חAvg. lamp hours :2,000Dimensions (in) :8.625 W x 14.69 H x 8.625 DחDimensions (cm) :21.9 W x 37.3 H x 21.9 DWeight :2.5 lb / 1.13 kg Wall Wash | Catalog number :IQWW When you need to wash a wall...

Mounting Stem Mount for securely positioning the luminaire at a fixed distancebelow the mounting point. Unistrut Mount for installation on standard gauges of Unistrut metal struts. Canopy Mounts tomount the luminaire as a typical ceiling or wall fixture. Malleable Iron Pipe Clamp to install the fixture on a thicker pipe. Forpipe .75 Ԗ 1.5 in diameter. Baby Pipe Clamp for a low-profile mounting on thinner pipes. For pipes.25Ԕ 1֔ in diameter. Beam Shaping Cylindrical Hood to control spill and glare. (Shown at left.) Sparkle Cylindrical Hood tocontrol spill and glare adding a decorativesparkle effect....

Smart-Track > TM |Catalog number : TLA-GAC100UL This adapter will allow a Smart IQseries luminaire to be controlled onAltman Smart-Track, which has three 20-amp circuits of control along with built in DMX or DALI control capabilities. (For more on Smart-Track > TM ,see page 7.) Global trac eco Catalog number :ASL-E166 (one- and two-circuit) This will adapt luminaires to work with the Nordic Aluminum Global tracήeco series track. The eco track is available in one- and two-circuit versions. Global trac tek | Catalog number : TLA-TEK100 This will adapt track luminaires to the Nordic Aluminum Global...

The Children's Museum ofIndianapolis, Indianapolis, IN Lighting Design by Dale Chihuly >

PAR lenses as well. NOTE: Separate power supply is required. (See next page.)Lamp type :RGB 1-watt LEDחWattages : 50-watts total Voltages : 24 DC via separate power supplyחAvg. lamp hours :100,000 Dimensions (in) : 13.68 W x 12.5 H x 4.75 DחDimensions (cm) : 34.75 W x 31.75 H x 12.06 DWeight : 9 lb /4.08 kg SpectraPAR | Catalog number :SS-PAR64 The SpectraPARי, an LED color-mixing PAR64, uses 36 one-watt LEDsfor high-output color-mixing. This indoor/outdoor PAR is constructed of cast aluminum and utilizes non-corroding hardware and fittings. Three interchangeable lenses, NSP, MFL, and WFL, are...
