ÂCOVA

acova


ïam 1
	*smt*
Tl If
1-'-^Œ-]		H t

O0H Ir-,

The dîagram opposite shows a contemporary bathroom divided înto four clear zones: 0,1,2,3 Zone 0 is inside the bath. Zone 1 is the area above the bath or modern shower tray to a height of 2.25m from the flooring. A minimum rating of IP44 shouLd be used. If water jets wiLL be used in Zone 2 a fitting with a minimum rating of IP65 should be used. If the fitting is 240V, a 30ma RCD (residuaL current device) must aLso be used to protect the circuit in this zone. Zone 2 is an area stretching 0.6m outside the perimeter of the bath and to a height of 2.25m from the fLoor. In this zone an IP rating of at Least IP44 is required. In addition, it is good practice to consider the area around a wash basin within a 60cm radius of any tap to be considered as Zone 2. Zone 3 is anywhere outside Zones 0, 1 and 2 (subject to spécifie Limits), and where no water jet is LikeLy to be used. No IP rating is required in this zone.


Escale •						•
Spectra						•
Régate	•	•	• •	• •	• •	•
Cala chrome	•	•			• •	•
Atoll electrlc				• •	• •
Palma electrlc				• •
Allzea	•	•					•
Neptune	•	•				•
Solea							•
Yucca Asymmetrical					••
Yucca Symmetrlcal					••
Yucca Mlrror					••
Fassane mlrror
Status CH & electrlc •
Fassane vertical electrlc			• •	•
Fassane Vertical HX & HXD •			• •	•
Fassane Horizontal VX & VXD			• •
Strlane HT & VT •			• •
Stralne Wave (HWT) •			• •
Keva vertical single & double				•
Keva horizontal single & double
Altla vertical single & double			• •
Altaï horizontal double wlth cover			• •

IP65 - CompLeteLy protected against jets of water from aLL directions IP55 - Protected against Low pressure water jets from aLL directions IP44 - Protected against spLashing water from aLL directions

Anteo and Anteo Pllnth

ACOM

ïïï

ÀCOM

mmmmmmsm

B1BBBI

Set 1 Set 2 Set 3 (straight) Set 4 (angled) Set 5 (mixed set for dual

Traditional Fixing Kits

Jft

energy installations)

Yucca vaLve and cover pLate for use with duaL energy instaLLions. (OnLy suitabLe for piping entering from wall behind the building radiator) White, coLour or chrome

Chrome Assessory Kit

DE Pack Class 1 (IP55) (Zone 1) ELectricaL eLement and chromium pLated t-piece for eLement and radiator vaLve connection. (No controLs)

DBM (CLass 2 IP44) (Zonel bath, Zone 2, shower) ManuaL and programmabLe opérations, 2 température settings, 2 hour programmabLe timer. Chromium pLated t-piece incLuded with duaL energy version.

Irvar-0 (IP65) (Zone 1) (infra red controL) Remote infra red température and programme controL 35°C to 70°C. Safety eut out faciLity. (Unit extends 150mm beLow radiator).

Chromax Valves

* ¹

Minimalistic Valves

Valve and Cover Plate

ÂCOffî

Winter use:

• De-activate the immersion heater

• Open the flow valve

Garden electric radiators and towel rails

• Year-round simplicity and flexibility

• No plumbing required

• Easy to install

• Time and température control facilities at point of use

Ener

Towel rails installer! with dual energy heating options Information for dual energy installations:

HCL: 8 heat settings pLus option to reduce the set comfort LeveL by 3.5co for night -time use. CentraL programming faciLity.

Utilizes existing central heating pipework Optional heating facilities when central heating is off

Warm dry towels in summer

Time and température control at point of use

The immersion heater should be inserted on the return header

The immersion heater should not be used simultaneously with the central heating

Summer use:

• Switch off the central heating and vent the radiator

• Close the flow valve (only)

Activate the immersion heater as required.

Timerprog (IP44) (Zone 2) Energy saving eLectronic room température controL with programmabLe or manuaL température boost for toweL drying.

Cadir (CLass 2 IP44) (Zonel bath, Zone2, shower) ProgrammabLe infrared eLectronic reguLation System with constant, economy, boost and automatic settings.
